Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Cage: |
Steel,Brass |
Model Number: |
608z 604z 605z 607z 609z |
Bore Size: |
3 - 2390 Mm |
Outside Diameter: |
9 - 2690 Mm |
Presicion: |
P0,P6,P5,P4,P2 |
Fuction: |
Low Cost&Low Noise |
Key Words: |
Ball Bearings |
Structure: |
Single Row |
Original: |
USA China |
Certification: |
QS9000 |
Type: |
Wheel Hub Bearing |
Material: |
Chrome Steel |
ABS: |
With ABS |
Tolerance: |
P5 |
Clearance: |
C5 |
Product Description
Deep groove ball bearings are the most widely used bearing type. It has deep, uninterrupted raceway grooves. These raceway grooves have the close osculation with the balls, enabling the bearings to accomodate radical and axial loads in both directions.
In addition to open type bearings, these bearings often have steel shields or rubber seals installed to one or both sides and are pre-lubricated with grease. Also, snap rings are sometimes used on the periphery. As to cages, pressed steel ones are the most common ones. For big deep groove ball bearings, machined brass cages are used. Machined cages are also used for high speed applications.
Maximum type ball bearings
These bearings are single-row deep groove ball bearings with a filling slot on both the inner and outer rings. They feature an enhanced radial load rating as they can contain more balls of larger diameter.
Not suitable for applications that involve axial loading or high-speed rotation.
When the bearing is installed, the filling slot on the fixed bearing ring should be in a no-load area
N0. |
Bore |
O.D |
Width |
Chamfer |
Load Rating |
Maximuum Seed |
Weight |
mm |
mm |
mm |
mm |
Dynamic
Cr |
Static
Cor |
Grease
r/min |
Oil
r/min |
Kg/pcs |
604 |
4 |
12 |
4 |
0.2 |
0.97 |
0.36 |
36000 |
44000 |
0.0021 |
605 |
5 |
14 |
5 |
0.2 |
1.33 |
0.505 |
32000 |
40000 |
0.0035 |
606 |
6 |
17 |
6 |
0.3 |
2.19 |
0.865 |
30000 |
38000 |
0.006 |
607 |
7 |
19 |
6 |
0.3 |
2.24 |
0.91 |
28000 |
36000 |
0.008 |
608 |
8 |
22 |
7 |
0.3 |
3.35 |
1.4 |
26000 |
34000 |
0.012 |
609 |
9 |
24 |
7 |
0.3 |
3.4 |
1.45 |
24000 |
32000 |
0.014 |
6000 |
10 |
26 |
8 |
0.3 |
4.55 |
1.96 |
22000 |
30000 |
0.019 |
6001 |
12 |
28 |
8 |
0.3 |
5.1 |
2.39 |
19000 |
26000 |
0.021 |
6002 |
15 |
32 |
9 |
0.3 |
5.6 |
2.83 |
18000 |
24000 |
0.03 |
6003 |
17 |
35 |
10 |
0.3 |
6.8 |
3.35 |
17000 |
22000 |
0.039 |
6004 |
20 |
42 |
12 |
0.6 |
9.4 |
5.05 |
15000 |
19000 |
0.069 |
6005 |
25 |
47 |
12 |
0.6 |
10.1 |
5.85 |
14000 |
18000 |
0.08 |
6006 |
30 |
55 |
13 |
0.6 |
13.2 |
8.3 |
12000 |
15000 |
0.116 |
6007 |
35 |
62 |
14 |
1.0 |
16 |
10.3 |
10000 |
14000 |
0.115 |
6008 |
40 |
68 |
15 |
1.0 |
16.8 |
11.5 |
8000 |
11000 |
0.19 |
6200 Series Miniature Deep Groove Ball Bearing
N0. |
Bore |
O.D |
Width |
Chamfer |
Load Rating |
Maximuum Seed |
Weight |
mm |
mm |
mm |
mm |
Dynamic
Cr |
Static
Cor |
Grease
r/min |
Oil
r/min |
Kg/pcs |
624 |
4 |
13 |
5 |
0.2 |
1.15 |
0.4 |
36000 |
45000 |
0.0032 |
625 |
5 |
16 |
5 |
0.3 |
1.76 |
0.680 |
32000 |
40000 |
0.0050 |
626 |
6 |
19 |
6 |
0.3 |
2.34 |
0.885 |
28000 |
36000 |
0.0080 |
627 |
7 |
22 |
7 |
0.3 |
3.35 |
1.400 |
26000 |
34000 |
0.0130 |
628 |
8 |
24 |
8 |
0.3 |
4.00 |
1.590 |
24000 |
32000 |
0.0170 |
629 |
9 |
26 |
8 |
0.3 |
4.55 |
1.960 |
22000 |
30000 |
0.0190 |
6200 |
10 |
30 |
9 |
0.6 |
5.10 |
2.390 |
19000 |
26000 |
0.0300 |
6201 |
12 |
32 |
10 |
0.6 |
6.10 |
2.750 |
18000 |
24000 |
0.0360 |
6202 |
15 |
35 |
11 |
0.6 |
7.75 |
3.600 |
17000 |
22000 |
0.0460 |
6203 |
17 |
40 |
12 |
0.6 |
9.60 |
4.600 |
16000 |
20000 |
0.0650 |
6204 |
20 |
47 |
14 |
1.0 |
12.80 |
6.650 |
14000 |
18000 |
0.1070 |
6205 |
25 |
52 |
15 |
1.0 |
14.00 |
7.850 |
12000 |
16000 |
0.1250 |
6206 |
30 |
62 |
16 |
1.0 |
19.50 |
11.300 |
10000 |
13000 |
0.2010 |
6300 Series Miniature Deep Groove Ball Bearing
N0. |
Bore |
O.D |
Width |
Chamfer |
Load Rating |
Maximuum Seed |
Weight |
mm |
mm |
mm |
mm |
Dynamic
Cr |
Static
Cor |
Grease
r/min |
Oil
r/min |
Kg/pcs |
6300 |
10 |
35 |
11 |
0.6 |
8.2 |
3.5 |
18000 |
24000 |
0.053 |
6301 |
12 |
37 |
12 |
1.0 |
9.7 |
4.2 |
17000 |
22000 |
0.06 |
6302 |
15 |
42 |
13 |
1.0 |
11.4 |
5.45 |
16000 |
20000 |
0.082 |
6303 |
17 |
47 |
14 |
1.0 |
13.5 |
6.55 |
15000 |
19000 |
0.115 |
6304 |
20 |
52 |
15 |
1.1 |
15.9 |
7.9 |
14000 |
17000 |
0.144 |
E-Asia was set up in 1996 and located at Jingjiang, a beautiful city in China. Our company is bearing manufacturer&bearing distributor. Since it was first established, E-AISA was dedicated in research, development and manufacture of bearings. Now, E-AISA has become main and one of the first grade suppliers of all kinds of bearings.
Our products include: Deep Groove Ball Bearings, Self-aligning Ball Bearings, Spherical Bearings, Tapered Roller Bearings, Cylindrical Roller Bearings, Needle Roller Bearings, Self-aligning Roller Bearings, Angular Contact Ball Bearings, Thrust Ball Bearings and Trust Roller Bearings and Special Bearings. We also provide OEM beaings.
E-Asia is a backbone enterprise for bearing production in China. With an area of 60, 000 square meters, more than 260 sets devices and machines, and around 200 employees, our company annually turns out more than 6 million sets bearings.
Our Bearings are exported to the USA, Canada, UK, Germany, Poland, Italy, Russia, the Middle East, Africa and other countries and regions of the world. E-Asia Bearing Co. Ltd. Is committed to the introduction of high-quality bearing products. Our company have more than 200 employees. Our brands include SKF bearings, NSK bearings, TIMKEN bearings, KOYO bearings, NTN bearings, IKO bearings and so forth.
Our belief is "Specialization is quality; Quality is the future. Any product with 0.01% defect is 100% reject" is our quality policy.
