Basic Info.
Model NO.:
Basic Info.
Model NO.:30202 30230 30302 30326 32205 32222
Rolling Body:Roller Bearings
The Number of Rows:Single
Outer Dimension:Small and Medium-Sized (60-115mm)
Material:Bearing Steel
Load Direction:Radial Bearing
Separated:Separated
Brand: IKC s
ample Date:3-5 Days
Tolerance:Abec1(P0) Abec3(P6) Abec5(P5) Abec7 Abec9
Delivery Detail:2-15 Days After Contract
Export Markets:Global
Additional Info.
Trademark:IKC
Packing:Box, Pallet, Rustproof Paper, Carton, Single
Standard:ISO 9001, BV
Origin:Hebei Handan
HS Code:8482200000
Production Capacity:8, 000, 000PCS/Year
Product Description
Tapered Roller Bearing (30202 30230 30302 30326 32205 32222)
Single row tapered roller bearing axial load depends on the ability of contact Angle, the outer ring raceway Angle, the Angle, the greater the axial load capacity.Most dosage in tapered roller bearing is single row circular cone roller bearings.In the car's front wheel hub, using the small size of double row circular cone roller bearings.Four row circular cone roller bearings used in large cold, hot rolling mill, and other heavy machinery.
Specification | Boundary dimensions(mm) | Mass(kg) | Specification | Boundary dimensions(mm) | Mass(kg) |
d | D | B | d | D | B |
30202 | 15 | 35 | 11.75 | 0.053 | 32207 | 35 | 72 | 24.25 | 0.456 |
30203 | 17 | 40 | 13.25 | 0.079 | 32208 | 40 | 80 | 24.75 | 0.549 |
30204 | 20 | 47 | 15.25 | 0.127 | 32209 | 45 | 85 | 24.75 | 0.602 |
30205 | 25 | 52 | 16.25 | 0.157 | 32210 | 50 | 90 | 24.75 | 0.644 |
30206 | 30 | 62 | 17.25 | 0.238 | 32211 | 55 | 100 | 26.75 | 0.860 |
30207 | 35 | 72 | 18.25 | 0.340 | 32212 | 60 | 110 | 29.75 | 1.180 |
30208 | 40 | 80 | 19.75 | 0.438 | 32213 | 65 | 120 | 32.75 | 1.550 |
30209 | 45 | 85 | 20.75 | 0.488 | 32214 | 70 | 125 | 33.25 | 1.660 |
30210 | 50 | 90 | 21.75 | 0.558 | 32215 | 75 | 130 | 33.25 | 1.720 |
30211 | 55 | 100 | 22.75 | 0.736 | 32216 | 80 | 140 | 35.25 | 2.130 |
30212 | 60 | 110 | 23.75 | 0.930 | 32217 | 85 | 150 | 38.5 | 2.640 |
30213 | 65 | 120 | 24.75 | 1.180 | 32218 | 90 | 160 | 42.50 | 3.410 |
30214 | 70 | 125 | 26.25 | 1.300 | 32219 | 95 | 170 | 45.50 | 4.220 |
30215 | 75 | 130 | 27.25 | 1.430 | 32220 | 100 | 180 | 49.00 | 5.050 |
30216 | 80 | 140 | 28.25 | 1.690 | 32221 | 105 | 190 | 53.00 | 6.260 |
30217 | 85 | 150 | 30.50 | 2.120 | 32222 | 110 | 200 | 56.00 | 7.350 |
30218 | 90 | 160 | 32.50 | 2.600 | 32304 | 20 | 52 | 22.25 | 0.241 |
30219 | 95 | 170 | 34.50 | 3.130 | 32305 | 25 | 62 | 25.25 | 0.376 |
30220 | 100 | 180 | 37.00 | 3.780 | 32306 | 30 | 72 | 28.75 | 0.570 |
30221 | 105 | 190 | 39.00 | 4.520 | 32307 | 35 | 80 | 32.75 | 0.765 |
30222 | 110 | 200 | 41.00 | 5.280 | 32308 | 40 | 90 | 35.25 | 1.050 |
30224 | 120 | 215 | 43.50 | 6.280 | 32309 | 45 | 100 | 38.25 | 1.420 |
30226 | 130 | 230 | 43.75 | 6.830 | 32310 | 50 | 110 | 42.25 | 1.880 |
30302 | 15 | 42 | 14.25 | 0.098 | 32311 | 55 | 120 | 45.50 | 2.390 |
30303 | 17 | 47 | 15.25 | 0.134 | 32312 | 60 | 130 | 48.50 | 2.960 |
30304 | 20 | 52 | 16.25 | 0.172 | 32313 | 65 | 140 | 51.00 | 3.600 |
30305 | 25 | 62 | 18.25 | 0.270 | 32005X | 25 | 47 | 15 | 0.116 |
30306 | 30 | 72 | 20.75 | 0.403 | 32006X | 30 | 55 | 17 | 0.172 |
30307 | 35 | 80 | 22.75 | 0.538 | 32007X | 35 | 62 | 18 | 0.230 |
30308 | 40 | 90 | 25.25 | 0.758 | 32008X | 40 | 68 | 19 | 0.280 |
30309 | 45 | 100 | 27.25 | 1.010 | 32009X | 45 | 75 | 20 | 0.354 |
30310 | 50 | 110 | 29.25 | 1.280 | 32010X | 50 | 80 | 20 | 0.380 |
30311 | 55 | 120 | 31.50 | 1.630 | 32011X | 55 | 90 | 23 | 0.567 |
30312 | 60 | 130 | 33.50 | 2.030 | 32012X | 60 | 95 | 23 | 0.608 |
30313 | 65 | 140 | 36.00 | 2.510 | 32013X | 65 | 100 | 23 | 0.646 |
30314 | 70 | 150 | 38.00 | 3.030 | 32014X | 70 | 110 | 25 | 0.869 |
30315 | 75 | 160 | 40.00 | 3.630 | 32015X | 75 | 115 | 25 | 0.925 |
30316 | 80 | 170 | 42.50 | 4.270 | 32016X | 80 | 125 | 29 | 1.320 |
30317 | 85 | 180 | 44.50 | 5.080 | 32017X | 85 | 130 | 29 | 1.380 |
30318 | 90 | 190 | 46.50 | 5.670 | 32018X | 90 | 140 | 32 | 1.780 |
30319 | 95 | 200 | 49.50 | 6.550 | 32019X | 95 | 145 | 32 | 1.880 |
30320 | 100 | 215 | 51.50 | 7.940 | 32020X | 100 | 150 | 32 | 1.950 |
32204 | 20 | 47 | 19.25 | 0.160 | 32021X | 105 | 160 | 35 | 2.480 |
32205 | 25 | 52 | 19.25 | 0.187 | 32022X | 110 | 170 | 38 | 3.090 |
32206 | 30 | 62 | 21.25 | 0.297 | | | | | |
Brand Name | YCZ or famous brand or according to your requirement |
Clearance | C2 C0 C3 C4 C5 |
Tolerance | ABEC1(P0) ABEC3(P6) ABEC5(P5) ABEC7(P4) ABEC9(P2) |
Vibration | Z1V1 Z2V2 Z3V3 Z4V4 |
Material | carbon steel, chrome, stainless steel, plastic, ceramic |
Sample Date | 3-5 days |
Delivery Detail |
|
Shipping | Express: DHL/EMS/By Sea |
Advantage | 1).Excellent and high quality control |
2).Prompt delivery |
3).Competitive price |
4).Small order accepted |
5).Customers' drawing or samples accepted |
6).OEM service |
Payment Term: | A: 30% T/T In Advance, 70% T/T Against Copy Of B/L |
B: 100% L/C At Sight |
Packing: | Industrial package or according to buyers requirement |
Rolling Body:Roller Bearings
The Number of Rows:Single
Outer Dimension:Small and Medium-Sized (60-115mm)
Material:Bearing Steel
Load Direction:Radial Bearing
Separated:Separated
Brand:Ycz
Sample Date:3-5 Days
Tolerance:Abec1(P0) Abec3(P6) Abec5(P5) Abec7 Abec9
Delivery Detail:2-15 Days After Contract
Export Markets:Global
Additional Info.
Trademark:ycz
Packing:Box, Pallet, Rustproof Paper, Carton, Single
Standard:ISO 9001, BV
Origin:Hebei Handan
HS Code:8482200000
Production Capacity:8, 000, 000PCS/Year
Product Description
Tapered Roller Bearing (30202 30230 30302 30326 32205 32222)
Single row tapered roller bearing axial load depends on the ability of contact Angle, the outer ring raceway Angle, the Angle, the greater the axial load capacity.Most dosage in tapered roller bearing is single row circular cone roller bearings.In the car's front wheel hub, using the small size of double row circular cone roller bearings.Four row circular cone roller bearings used in large cold, hot rolling mill, and other heavy machinery.
Specification | Boundary dimensions(mm) | Mass(kg) | Specification | Boundary dimensions(mm) | Mass(kg) |
d | D | B | d | D | B |
30202 | 15 | 35 | 11.75 | 0.053 | 32207 | 35 | 72 | 24.25 | 0.456 |
30203 | 17 | 40 | 13.25 | 0.079 | 32208 | 40 | 80 | 24.75 | 0.549 |
30204 | 20 | 47 | 15.25 | 0.127 | 32209 | 45 | 85 | 24.75 | 0.602 |
30205 | 25 | 52 | 16.25 | 0.157 | 32210 | 50 | 90 | 24.75 | 0.644 |
30206 | 30 | 62 | 17.25 | 0.238 | 32211 | 55 | 100 | 26.75 | 0.860 |
30207 | 35 | 72 | 18.25 | 0.340 | 32212 | 60 | 110 | 29.75 | 1.180 |
30208 | 40 | 80 | 19.75 | 0.438 | 32213 | 65 | 120 | 32.75 | 1.550 |
30209 | 45 | 85 | 20.75 | 0.488 | 32214 | 70 | 125 | 33.25 | 1.660 |
30210 | 50 | 90 | 21.75 | 0.558 | 32215 | 75 | 130 | 33.25 | 1.720 |
30211 | 55 | 100 | 22.75 | 0.736 | 32216 | 80 | 140 | 35.25 | 2.130 |
30212 | 60 | 110 | 23.75 | 0.930 | 32217 | 85 | 150 | 38.5 | 2.640 |
30213 | 65 | 120 | 24.75 | 1.180 | 32218 | 90 | 160 | 42.50 | 3.410 |
30214 | 70 | 125 | 26.25 | 1.300 | 32219 | 95 | 170 | 45.50 | 4.220 |
30215 | 75 | 130 | 27.25 | 1.430 | 32220 | 100 | 180 | 49.00 | 5.050 |
30216 | 80 | 140 | 28.25 | 1.690 | 32221 | 105 | 190 | 53.00 | 6.260 |
30217 | 85 | 150 | 30.50 | 2.120 | 32222 | 110 | 200 | 56.00 | 7.350 |
30218 | 90 | 160 | 32.50 | 2.600 | 32304 | 20 | 52 | 22.25 | 0.241 |
30219 | 95 | 170 | 34.50 | 3.130 | 32305 | 25 | 62 | 25.25 | 0.376 |
30220 | 100 | 180 | 37.00 | 3.780 | 32306 | 30 | 72 | 28.75 | 0.570 |
30221 | 105 | 190 | 39.00 | 4.520 | 32307 | 35 | 80 | 32.75 | 0.765 |
30222 | 110 | 200 | 41.00 | 5.280 | 32308 | 40 | 90 | 35.25 | 1.050 |
30224 | 120 | 215 | 43.50 | 6.280 | 32309 | 45 | 100 | 38.25 | 1.420 |
30226 | 130 | 230 | 43.75 | 6.830 | 32310 | 50 | 110 | 42.25 | 1.880 |
30302 | 15 | 42 | 14.25 | 0.098 | 32311 | 55 | 120 | 45.50 | 2.390 |
30303 | 17 | 47 | 15.25 | 0.134 | 32312 | 60 | 130 | 48.50 | 2.960 |
30304 | 20 | 52 | 16.25 | 0.172 | 32313 | 65 | 140 | 51.00 | 3.600 |
30305 | 25 | 62 | 18.25 | 0.270 | 32005X | 25 | 47 | 15 | 0.116 |
30306 | 30 | 72 | 20.75 | 0.403 | 32006X | 30 | 55 | 17 | 0.172 |
30307 | 35 | 80 | 22.75 | 0.538 | 32007X | 35 | 62 | 18 | 0.230 |
30308 | 40 | 90 | 25.25 | 0.758 | 32008X | 40 | 68 | 19 | 0.280 |
30309 | 45 | 100 | 27.25 | 1.010 | 32009X | 45 | 75 | 20 | 0.354 |
30310 | 50 | 110 | 29.25 | 1.280 | 32010X | 50 | 80 | 20 | 0.380 |
30311 | 55 | 120 | 31.50 | 1.630 | 32011X | 55 | 90 | 23 | 0.567 |
30312 | 60 | 130 | 33.50 | 2.030 | 32012X | 60 | 95 | 23 | 0.608 |
30313 | 65 | 140 | 36.00 | 2.510 | 32013X | 65 | 100 | 23 | 0.646 |
30314 | 70 | 150 | 38.00 | 3.030 | 32014X | 70 | 110 | 25 | 0.869 |
30315 | 75 | 160 | 40.00 | 3.630 | 32015X | 75 | 115 | 25 | 0.925 |
30316 | 80 | 170 | 42.50 | 4.270 | 32016X | 80 | 125 | 29 | 1.320 |
30317 | 85 | 180 | 44.50 | 5.080 | 32017X | 85 | 130 | 29 | 1.380 |
30318 | 90 | 190 | 46.50 | 5.670 | 32018X | 90 | 140 | 32 | 1.780 |
30319 | 95 | 200 | 49.50 | 6.550 | 32019X | 95 | 145 | 32 | 1.880 |
30320 | 100 | 215 | 51.50 | 7.940 | 32020X | 100 | 150 | 32 | 1.950 |
32204 | 20 | 47 | 19.25 | 0.160 | 32021X | 105 | 160 | 35 | 2.480 |
32205 | 25 | 52 | 19.25 | 0.187 | 32022X | 110 | 170 | 38 | 3.090 |
32206 | 30 | 62 | 21.25 | 0.297 | | | | | |
Brand Name | YCZ or famous brand or according to your requirement |
Clearance | C2 C0 C3 C4 C5 |
Tolerance | ABEC1(P0) ABEC3(P6) ABEC5(P5) ABEC7(P4) ABEC9(P2) |
Vibration | Z1V1 Z2V2 Z3V3 Z4V4 |
Material | carbon steel, chrome, stainless steel, plastic, ceramic |
Sample Date | 3-5 days |
Delivery Detail |
|
Shipping | Express: DHL/EMS/By Sea |
Advantage | 1).Excellent and high quality control |
2).Prompt delivery |
3).Competitive price |
4).Small order accepted |
5).Customers' drawing or samples accepted |
6).OEM service |
Payment Term: | A: 30% T/T In Advance, 70% T/T Against Copy Of B/L |
B: 100% L/C At Sight |
Packing: | Industrial package or according to buyers requirement |
