Synthetic Fiber Plank Pre-Filter

Name: Synthetic Fiber Plank Pre-Filter
Brand: ibuyautoparts.com
SKU: 715977245
Availability: InStock
Rating: 4.8 (105 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	5/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Plank coarse efficiency filter mesh

The filter material is the coarse efficiency filter media; Good ventilation property, small resistance. Metal frame. Conform to European and American classification for nonflammability(e. G DIN 53438-F1, UL900 class 2 with flameout)
Humidity resistance: 100%;
Temp resistance: 80%;

Using:
Pre-filtration and second filtration for the ventilation system of the air condition;
The filtration for entering or returning the air in the clean-room

Class	WHD(mm)	Raied air flow(m³/h)	Initial resistance(Pa)	Recommended resistance(Pa)
G3	595x595x20mm	1900	35	180
G3	290x595x20mm	1000
G3	595x595x46mm	3400
G3	290x595x46mm	1700
G4	595x595x25mm	1900	45	220
G4	290x595x25mm	1000
G4	595x595x46mm	3400
G4	290x595x46mm	1700

Prod Model:	G3
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Item:	Plank Coarse Filter
Class:	G3-G4
Frame:	Galvanization Frame
Temp Resistance:	80ºC
Type:	Air Filter
Function:	Spray Booth Filter
Transfer Function:	High Pass
Structure:	Panel Filter
Type11:	Synthetic Fiber
Material:	The Coarse Efficiency Filter Media

Guangzhou Clean-Link Filtration Co., Ltd. is a wealth of the industry has many years of experience, Specializing in the production of air filter and has remarkable achievements enterprises, We occupy 6000 square meters of the area of our workshop, 3 import production lines, With research and development, manufacturing powerful technical force. Our products sell well to Japan, South Korea, Australia, the US, and so on many countries and the area.
