Spray Booth/Painting Room for All Kinds of Autoes

Spray Booth/Painting Room for All Kinds of Autoes
Price: US $ 3000-19800/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: CE certificate
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Outside Dimension: 7050 * 5500 * 3500(L*W*H)
Inside Dimension: 6900 * 4000 * 2800mm
Front Door(mm): 3200*2600(W*H), 4 Folded
Service Door (mm): 2000*650(W*H)
Wall Panel: 75mm Rock-Wool Panel, 0.6 Steel
Basement: 300mm Depth with Grids, 3 Rows Grilles
Inlet Fan(Turbo): 1X7.5kw
Outlet Fan(Turbo): 1X7.5kw
Heating System: Riello G20 Diesel Oil/Gas Burner
Lightening System: 4X8units Ceiling, 4X12units Side
Certification: UL
Airflow Direction: Lateral Undershot-type
Heating Mode: Diesel
Paint Mist Treatment: Dry-type
Condition: New
Substrate: Sandwich Panel
Brand: Captain

Product Description

Products Description


ItemDetailed  specification
Inside dimension6900×4000×2800 mm(L×W×H)
Outside dimension7050×5500×3500 mm(L×W×H)
Front doorFolding door, 4 folds, 3200×2600 mm(W×H), without frame cover, color : blue.
Emergency door1 unit, 650×2000mm(W×H), color: white
BasementGalvanized steel assemble, 300mm high, quadrate steel support, 3 rows grilles made by flat bar and twisted steel, galvanized, 2 rows diamond plate , galvanized; 3ramps, 900×2000mm/pc.
Wall panel
Thickness: 75mm, width:950mm, tongue and groove structure, 0.6mm color steel with rock wool inside, color: white.
Light
Ceiling Lights: 8Units×4Pcs=32Pcs×36W, Side Lights: 12Units×4Pcs=48Pcs×18W, with electronic ballasts, lighting boxes open outside, illumination≥1200Lux
Generator cabinetIntake from back upper, exhaust from back upper, white coated steel outside covered, galvanized steel inside, filled with heat preservation material inside.
Intake and Exhaust systemInlet: 1×7.5KW turbo fan, power: 7.5KW, air capacity: 25000m3/h.
 Outlet: 1×7.5KW turbo fan, power: 7.5KW, air capacity: 25000m3/h.
 Water based paint drying system60 units ceiling nozzles with 3 sets of centrifugal fans for drying the Water Based Paint.
Heating systemRIELLO RG5S diesel burner, stainless steel heat exchanger, pneumatic damper actuates from spraying to baking cycle. Max. heating productivity: 260000Kcal/h.
 Spray to baking switchOne manual damper
 Chimney ducting304 Stainless ducting and one safe fireproof chimney elbow.
Purification systemPre-filter, ceiling filter, fiberglass filter, activated carbon filter
Roof
Galvanized steel
Control system
Spraying, heat spraying, baking, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop, hour meter, temperature limit controller, pressure gauge.
Total power 22.5KW
UNIT PRICE (FOB QINGDAO) $9860

Captain Advantages

*The same price higher quality, the same quality lower price! ! !
*2 years quality warranty! ! !
*Fast and stable supply capability! ! !
*Personalized design to meet customer various needs! ! !

Captain Spray Booth(Qingdao Hua Yushun Commercial Co., Ltd)
Is a professional leading factory in China, who is specializing in manufacture kinds of paint spray room system. And also offering full garage equipments, such as

Car care equipment.

Car spray&baking room system

Bus spray&baking room system

Furnitue spray&baking room system

Industrial painting&baking room system

High temperature baking room system

Customized spray&bake booth and Offer car spray baking booth accossories


Services We Supply

Customized service

More Than 90% Of Our Spraying Booth Is Customized.

1. We can design the machines according your requirements. At the same time, our engineers will give you our professional suggestions.

2. We can give you free technical support and consultation such as design your factory, make the factory layout drawing and so on.

After-sales service

1. Our fast and professional after service engineer team can go to your factory and install the machine, give you the operating guidance, and train your employees until they can operate the machine well.

2. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.

3. We provide 2 years warranty.





Competitive Price and High Quality Spraying Booth with Perfect Service Is From Here.
Qingdao Hua Yushun Commercial Co., Ltd belongs to Captain Auto Equipment Group, which is responsible for exporting for all the products of Captain Group. And Captain is a professional designer and manufacturer of mechanical equipment, which is developed from SK spray booth built in 1992. Captain developed day by day, and established Shandong painting production base and sandwich panel production base. Now it can produce painting equipments more than 3000 sets, about 2, 000, 000 square meters different kinds of sandwich panels, and various kinds of steel ducting 800, 000 meters one year. Also Captain established Zhucheng sandblasting production base in 2002, and injection pieces production base in 2005. And in 2006, Captain established Qingdao Commercial Center, which is operated by Qingdao Hua Yushun Commercial Co., Ltd who is responsible for all the global importing and exporting business. Formed a good industry pattern that is the sells presses to production, and production streghten sales.

· Now the products of Captain group refer to auto repair quipments, furniture spray booth, preparation bay, shot blasting machine, antiseptic treatment production line, injection pieces, all kinds of EPS panel, rock wool panel, glass fiber panel and decorative panel outside, commercial kitchen equipment, etc.

· After all these years, high-quality products and good service won wide reputation for our group from our buyers, and our products are exported to Germany, the United States, Sweden, the Netherlands, Denmark, Romania, South Africa, Australia, Canada, Italy, New Zealand, Nigeria, Zambia, Thailand, Chile and other countries and regions.

Face to the ever-changing market, Captain looks providing more secure, reliable, energy conservation and environmental protection products as it's responsibility, listens to the buyer's comments carefully, improve the quality of products and service, Continue to increase the research and development ability of enterprise innovation and equipment; We will paste with the future, and slipped through the waves.
