Spray Booth for Different Cars

Spray Booth for Different Cars
Price: US $ 3000-11800/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: CAPTAIN EX
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Outside Dimension: 7000 * 5400 * 3250(L*W*H)
Inside Dimension: 6900 * 3900 * 2600mm
Front Door(mm): 2800*2500(W*H)
Service Door (mm): 1800*650(W*H)
Total Power: 42kw
Wall Panel: 50mm Rock-Wool Panel, 0.5mm Steel
Basement: 300mm Depth with Grids
Ramp: Two 2000*900mm Ramps
Heating: 3*9 Units High Energy Infra-Red Lamp
Water Based Paint Drying System: 40 Ceiling Nozzles with 2 Centrifugal Fan
Certification: ISO
Airflow Direction: Fully Undershot-type
Heating Mode: Electric
Paint Mist Treatment: Dry-type
Condition: New
Type: Spray Painting
Substrate: Sandwich Panel
Brand: Captain

Product Description

Products Description


Outside Dimension (mm)7000 * 5400 * 3250(L*W*H)Inside Dimension(mm)6900 * 3900 * 2600(L*W*H)
Front Door(mm)2800*2500(W*H)Service door (mm)1800*650(W*H)
Total Power42KW
Cabin systemWall panel  50mm rock-wool panel, double face steel sheet thickness: 0.5mm
 Ceiling panel Galvanized steel sheet.
 Basement300mm depth, patented circumferential diamond plate design, middle with grids.
 RampTwo 2000*900mm ramps
 Glass6mm safety tempered glass
 WindowsSquare glass Windows
Air Make-up SystemAir Inlet fan system2 * 4 kw double-intake belt centrifugal fan, air capacity for each fan: 14500m3/h.
 Exhausted fan system1 * 5.5 kw double-intake belt centrifugal fan, air capacity 18000m3/h.
 Air Flowing speed0.45 m/s in empty booth, 0.35 m/s when painting.
 Exhausted ducting4 meters air duct, one flop damper, one weather hood, one anti-bird mesh
 Water based paint drying system40 units ceiling nozzles with 2 sets of centrifugal fans for drying the Water Based Paint.
Purification SystemPre-filterG3 grade, Air Inlet filter
 Ceiling filterEU5 / F5
 Floor filterGreen fiber glass filter / G3 grade
 Exhausted fan FiltersFiber glass filter.
 Heating        With 9 units high energy short wave infra-red lamps for heating. 3 pcs/ unit, each lamp 1 KW, total power of infra-red lamp:27KW
 Max heating temperature
Heating time
80 degree centigrade
4-6min(20-60 degree centigrade)
Lighting SystemCeiling lights8 Units, each 3 x 36W Philips lamps, Total 1152 W
 Illumination 900LUX
Controlling systemSwitched control panelSpraying & baking switch, lighting switch, emergency stop, breakdown alarm, failure alarm


Captain Spray Booth(Qingdao Hua Yushun Commercial Co., Ltd)
Is a professional leading factory in China, who is specializing in manufacture kinds of paint spray room system. And also offering full garage equipments, such as

Car care equipment.

Car spray&baking room system

Bus spray&baking room system

Furnitue spray&baking room system

Industrial painting&baking room system

High temperature baking room system

Customized spray&bake booth and Offer car spray baking booth accossories


Services We Supply

Customized service

More Than 90% Of Our Spraying Booth Is Customized.

1. We can design the machines according your requirements. At the same time, our engineers will give you our professional suggestions.

2. We can give you free technical support and consultation such as design your factory, make the factory layout drawing and so on.

After-sales service

1. Our fast and professional after service engineer team can go to your factory and install the machine, give you the operating guidance, and train your employees until they can operate the machine well.

2. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.

3. We provide 2 years warranty.


Captain Advantages

*The same price higher quality, the same quality lower price! ! !
*2 years quality warranty! ! !
*Fast and stable supply capability! ! !
*Personalized design to meet customer various needs! ! !


Competitive Price and High Quality Spraying Booth with Perfect Service Is From Here.
Qingdao Hua Yushun Commercial Co., Ltd belongs to Captain Auto Equipment Group, which is responsible for exporting for all the products of Captain Group. And Captain is a professional designer and manufacturer of mechanical equipment, which is developed from SK spray booth built in 1992. Captain developed day by day, and established Shandong painting production base and sandwich panel production base. Now it can produce painting equipments more than 3000 sets, about 2, 000, 000 square meters different kinds of sandwich panels, and various kinds of steel ducting 800, 000 meters one year. Also Captain established Zhucheng sandblasting production base in 2002, and injection pieces production base in 2005. And in 2006, Captain established Qingdao Commercial Center, which is operated by Qingdao Hua Yushun Commercial Co., Ltd who is responsible for all the global importing and exporting business. Formed a good industry pattern that is the sells presses to production, and production streghten sales.

· Now the products of Captain group refer to auto repair quipments, furniture spray booth, preparation bay, shot blasting machine, antiseptic treatment production line, injection pieces, all kinds of EPS panel, rock wool panel, glass fiber panel and decorative panel outside, commercial kitchen equipment, etc.

· After all these years, high-quality products and good service won wide reputation for our group from our buyers, and our products are exported to Germany, the United States, Sweden, the Netherlands, Denmark, Romania, South Africa, Australia, Canada, Italy, New Zealand, Nigeria, Zambia, Thailand, Chile and other countries and regions.

Face to the ever-changing market, Captain looks providing more secure, reliable, energy conservation and environmental protection products as it's responsibility, listens to the buyer's comments carefully, improve the quality of products and service, Continue to increase the research and development ability of enterprise innovation and equipment; We will paste with the future, and slipped through the waves.
