| Prod Model: |
VRC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Height (Mm: |
4000 - 6000 |
| Width (Mm): |
2000 - 3500 |
| Length Of Platfrom: |
4000-6000 Mm (on Request) |
| Width Of Platform: |
2000 - 3500 Mm (on Request) |
| Lifting Height: |
2500 - 5000 Mm (on Request) |
| Capacity: |
2000 - 5000 Kg (on Request) |
| Power Supply: |
380V 60Hz 3p |
| Finished Treatment: |
Spray Paint |
| Production Time: |
28 Days |
| Warranty: |
5 Years Structure and 1 Year Part |
| Lifting Capacity: |
≥5T |
| Certification: |
CE |
Product Description
About us:
-At the beginning, we started cooperate with a Japanese facilities. Company as their production base. At the moment, we growing into a company with 400 million annual sales revenue, 477 employees, with 40, 000 M2 production facilities
-In China domestically, we install more than 25, 000 parking space every year. We are holding 26 national patents, CE certificate, and ISO 9001.
-We are the only manufacturer who can provide hydraulic lift & slide parking system in China who can built up to 30 floors.
Characteristics:
1. High precision hydraulic driven system
2. Easy control and low failure rate
3. Equip high strength double chain for lifting system
4. Adjustable screw rod, guarantee the platfrom balanced
5. High-capacity pump tank, high lifting speed
6. Good looking and color customized by customers
7. Adopted car dealer, transportation lift and floor to floor lifter
Specifications:
| Model | FP-VRC |
| Lifting capacity | 2,000-10,000 kg*can be customized |
| Lifting height | 2,000-15,000mm*can be customized |
| Platform length | 2000mm-6000mm*can be customized |
| Platform width | 2000mm-5000mm*can be customized |
| No. of level | according to your requirement |
| Drive mode | Hydraulic(cylinder with double steel chains) |
| Operation | button switch (standard) / remote controller (optional) |
| Power pack | 4 kw hydraulic power pump |
| Lifting speed | 4m/min |
| Safety devices | Mechanical anti-falling lock |
| Finishing | Paint spray |
| Color | Customized according to your requirement |
QA:
1. Is this product can be used indoor or outdoor?
FP-VRC can be installed both indoor and outdoor as long as the site dimensions are enough.
2. What is the surface nishing for this product?
It's paint spray as standard treatment, and optional aluminum steel sheet can be covered above for better water-proof and looking.
3. What is the power requirements? Is single phase acceptable?
Generally speaking, a 3-phase power supply is a must for our 4Kw motor. If the usage frequency is low (less than one movement per hour), a single phase power supply can be used, otherwise it may lead to motor burnt out.
4. Can this product still operate if electricity failure happens?
Without electricity the FP-VRC cannot work, so a back-up generator may be needed if electricity failure happens often in your city.
5. What is the warranty?
It's ve years for main structure and one year for moving parts.
6. What is the production time?
It's 30 days after prepayment and nal drawing conrmed.
7. What is the shipping size? Is LCL acceptable, or it must be FCL?
As FP-VRC is a fully customized product, the shipping size depends on the specications you need.
As there are some electrical parts and hydraulic parts, and the packages for components are in different shapes, LCL cannot be used. 20 feet or 40 feet container is necessary as per the lifting height.
