Model: YS-MR-BInside dimention: 2230*3480*2500-5680*3480*2500mm L*W*H
Any Size Requirements Can Be Met
Environmental friendly
A. Paint mixing room provides a controlled area to safely mix paints.
B. Paint mixing room contained an automatic fire extinguishing system.
C. Paint mixing rooms are available in a range of sizes and specifications; Nonstandard sizes can be manufactured to suit a specific area.
WarrantyThe goods are guaranteed for 12 months from the date of receipt, but the filters and lamps are not guaranteed. It cannot be applied for damages caused by negligence of operations or mishandling of the machine.
| Model | YS-MR-B1 | YS-MR-B2 | YS-MR-B3 | YS-MR-B4 |
| Inside Dimension | 2230 × 3480× 2500 mm(L× W× H) | 3380 × 3480× 2500 mm(L× W× H) | 4530 × 3480× 2500 mm(L× W× H) | 5680 × 3480× 2500 mm(L× W× H) |
| Outside Dimension | 2330 × 3580 × 2550 mm (L× W× H) | 3480 × 3580 × 2550 mm (L× W× H) | 4630 × 3580 × 2550 mm (L× W× H) | 5780 × 3580 × 2550 mm (L× W× H) |
| Escape Door | 1 unit, 650× 2000 mm(W× H) |
| Room Body | Wall panels and roof panels are double skinned, tongue and groove structure, thickness: 50mm, made by 0.376mm color steel with polystyrene(EPS) inside, color: white. |
| Lighting System | Ceiling lights 2 units× 4pcs=8pcs36W, with electronic ballasts. | Ceiling lights 3 units× 4pcs=12pcs36W, with electronic ballasts. | Ceiling lights 4 units× 4pcs=16pcs36W, with electronic ballasts. | Ceiling lights 5 units× 4pcs=20pcs36W, with electronic ballasts. |
| Ventilation System | Exhaust air from bottom of back wall panels, with exhaust fan , air capacity: 2200m3/h. Generator is with galvanized steel molding frame and white coated steel cover. | Exhaust air from bottom of back wall panels, with exhaust fan , air capacity: 2800m3/h. Generator is with galvanized steel molding frame and white coated steel cover. | Exhaust air from bottom of back wall panels, with exhaust fan , air capacity: 3800m3/h. Generator is with galvanized steel molding frame and white coated steel cover. | Exhaust air from bottom of back wall panels, with exhaust fan , air capacity: 5000m3/h. Generator is with galvanized steel molding frame and white coated steel cover. |
| Filtering System | Pre-filter, exhaust fiberglass filter. |
| Control System | Power supply switch, electrical outlet, fan operation and lighting switch. |
Guangzhou YOKISTAR Co., Ltd. (YOKI STAR for short) is specialized in spray booths, infrared lamps, prep stations, equipments for industrial painting, high temperature drying which can supply design as well as manufacturing service.
Located in BaiYun district of GuangZhou city, YOKI STAR occupies 25000 square meters area, owns around 200 employees which is convenient to the new Baiyun airport (20 minutes by car) and the railway station (30 minutes).
As a professional designer and manufacturer with target in 'To be the best, but not to be the biggest', YOKI star succeeds to international advanced design standards and manufacturing technologies, follows international quality management and control system, produces first-class professional products of the world and shares with friends all over the world.
The products of YOKISTAR can be used widely for automobile maintenance, vehicles manufacturing, machinery manufacturing as well as trains, planes and furniture. Our products are popular in European Union, North America, South America, Middle East, East and South Asia, Africa, and have established completely sales system all around the world. YOKISTAR aims to be the spraying and baking equipments manufacturer with leading brand in the world, and to become modernized enterprise with international competitive advantage.
YOKISTAR is an ideal cooperator who deserves your reliance.
