| Prod Model: |
QFY-2 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
380V 50Hz |
| Motor Power: |
7.5kw |
| Name: |
Power Steering Pump Test Bench |
| Certification: |
ISO |
| Update Method: |
by Hard Disk |
Product Description
QFY-2 model Power Steering Pump Test Bench, test pressure,flow,speed
General introduction:
This power steering pump test bench is used for testing and repairing hydraulic steering pumps of various trucks in steering system. Regulating speed by frequency converter to drive the pump work. Adopting high precision press regulating valve and sensor, it possesses convenient operation and reliable data.
Advantages:
1.It uses variable frequency speed regulation to drive the pump work.
2.It displays result by pointer instruments.
3.It adopts high-precision pressure regulator valve and sensor.
4.It is with indicator lamp following each step and warn you the problems.
5.It is easy to learn and operate.
Test items:
1.pressure of the power pump, can preinstall the rated pressure and disassembling automatically
2.the flow of the power pump
3.the rotating speed of the power pump
Technical parameter:
| Model no | QFY-2 |
| Language | English, etc |
| Material | Metal plate |
| Painting | Powder painting, durable and beautiful |
| Color | Blue |
| Voltage | 380V 50Hz |
| Motor power of power steering pump | 7.5KW |
| Frequency converter power | 7.5KW |
| Speed | 0-2400rpm(frequency regulation) |
| Direction | Clockwise, anti-clockwise |
| Working pressure range of power pump | 0-18Mpa |
| Accessories: |
| Accessory wires , etc. |
| Others you may want to know: |
| MOQ | 1set |
| Warranty period | 12 months |
| Payment term | T/T 50% in advance, the balance should be paid before delivery (negotiable) |
| Delivery time | 30 days after receiving downpayment |
| HS code | 90312000.90 |
| Packing sizes | 1140x860x1630mm=1.6CBM
N.W:250kgs
G.W:295kgs |
