material: NBR , silicon, FKM are available.
We have thousands of moulds
custom-made is welcome
We have all specs in stock, so small order is available, and delivery fast.
| NO. | spec. | | NO. | | | | () | |
| 1 | 5x1.9 | 1.7 | 0.07 | 26 | 40x3.1 | 34.5 | 0.32 | |
| 2 | 6x1.9 | 2.7 | 0.07 | 27 | 45x3.1 | 39.5 | 0.35 | |
| 3 | 7x1.9 | 3.7 | 0.07 | 28 | 50x3.1 | 44.5 | 0.35 | |
| 4 | 8x1.9 | 4.7 | 0.08 | 29 | 55x3.1 | 49.5 | 0.45 | |
| 5 | 9x1.9 | 5.7 | 0.08 | 30 | 60x3.1 | 54.5 | 0.45 | |
| 6 | 10x1.9 | 6.7 | 0.09 | 31 | 63x3.1 | 57.5 | 0.50 | |
| 7 | 11x1.9 | 7.7 | 0.10 | 32 | 65x3.1 | 59.5 | 0.50 | |
| 8 | 12x1.9 | 8.7 | 0.10 | 33 | 68x3.1 | 62.5 | 0.60 | |
| 9 | 13x1.9 | 9.7 | 0.10 | 34 | 70x3.1 | 64.5 | 0.60 | |
| 10 | 14x1.9 | 10.7 | 0.10 | 35 | 75x3.1 | 69.5 | 0.65 | |
| 11 | 14x2.4 | 9.6 | 0.12 | 36 | 80x3.1 | 74.5 | 0.65 | |
| 12 | 15x2.4 | 10.6 | 0.13 | 37 | 85x3.1 | 79.5 | 0.70 | |
| 13 | 16x2.4 | 11.6 | 0.13 | 38 | 90x3.1 | 84.5 | 0.70 | |
| 14 | 18x2.4 | 13.6 | 0.14 | 39 | 95x3.1 | 89.5 | 0.80 | |
| 15 | 19x2.4 | 14.6 | 0.15 | 40 | 100x3.1 | 94.5 | 0.80 | |
| 16 | 20x2.4 | 15.6 | 0.15 | 41 | 105x3.1 | 99.5 | 0.85 | |
| 17 | 22x2.4 | 17.6 | 0.18 | 42 | 110x3.1 | 104.4 | 0.85 | |
| 18 | 24x2.4 | 19.6 | 0.20 | 43 | 115x3.1 | 109.5 | 0.90 | |
| 19 | 25x2.4 | 20.6 | 0.22 | 44 | 120x3.1 | 114.5 | 0.90 | |
| 20 | 26x2.4 | 21.6 | 0.22 | 45 | 125x3.1 | 119.5 | 1.00 | |
| 21 | 28x3.1 | 22.5 | 0.28 | 46 | 130x3.1 | 124.5 | 1.10 | |
| 22 | 30x3.1 | 24.5 | 0.28 | 47 | 135x3.1 | 129.5 | 1.15 | |
| 23 | 32x3.1 | 26.5 | 0.30 | 48 | 140x3.1 | 134.5 | 1.20 | |
| 24 | 35x3.1 | 29.5 | 0.30 | 49 | 145x3.1 | 139.5 | 1.25 | |
| 25 | 38x3.1 | 32.5 | 0.32 | 50 | 150x3.1 | 144.5 | 1.30 | |
| (),(,). | |
| | | | () | | | | () | |
| 51 | 155x3.1 | 149.5 | 1.35 | 76 | 60x5.7 | 49.4 | 0.60 | |
| 52 | 160x3.1 | 154.5 | 1.40 | 77 | 63x5.7 | 52.4 | 0.62 | |
| 53 | 165x3.1 | 159.5 | 1.50 | 78 | 65x5.7 | 54.4 | 0.65 | |
| 54 | 28x3.5 | 21.6 | 0.30 | 79 | 70x5.7 | 59.4 | 0.70 | |
| 55 | 30x3.5 | 23.6 | 0.30 | 80 | 73x5.7 | 62.4 | 0.72 | |
| 56 | 31x3.5 | 24.6 | 0.31 | 81 | 75x5.7 | 64.4 | 0.75 | |
| 57 | 32x3.5 | 25.6 | 0.32 | 82 | 80x5.7 | 69.4 | 0.80 | |
| 58 | 34x3.5 | 27.6 | 0.33 | 83 | 85x5.7 | 74.4 | 0.85 | |
| 59 | 35x3.5 | 28.6 | 0.34 | 84 | 90x5.7 | 79.4 | 0.90 | |
| 60 | 36x3.5 | 29.6 | 0.35 | 85 | 95x5.7 | 84.4 | 0.95 | |
| 61 | 38x3.5 | 31.6 | 0.36 | 86 | 100x5.7 | 89.4 | 1.00 | |
| 62 | 40x3.5 | 33.6 | 0.38 | 87 | 105x5.7 | 94.4 | 1.05 | |
| 63 | 41x3.5 | 34.6 | 0.40 | 88 | 110x5.7 | 99.4 | 1.10 | |
| 64 | 42x3.5 | 35.6 | 0.42 | 89 | 115x5.7 | 104.4 | 1.15 | |
| 65 | 44x3.5 | 37.6 | 0.43 | 90 | 120x5.7 | 109.4 | 1.20 | |
| 66 | 45x3.5 | 38.6 | 0.44 | 91 | 125x5.7 | 114.4 | 1.25 | |
| 67 | 46x3.5 | 39.6 | 0.45 | 92 | 130x5.7 | 119.4 | 1.30 | |
| 68 | 48x3.5 | 41.6 | 0.45 | 93 | 135x5.7 | 124.4 | 1.35 | |
| 69 | 50x3.5 | 43.6 | 0.45 | 94 | 140x5.7 | 129.4 | 1.45 | |
| 70 | 51x3.5 | 44.6 | 0.45 | 95 | 145x5.7 | 134.4 | 1.50 | |
| 71 | 54x3.5 | 47.6 | 0.45 | 96 | 150x5.7 | 139.4 | 1.55 | |
| 72 | 55x3.5 | 48.6 | 0.50 | 97 | 155x5.7 | 144.4 | 1.60 | |
| 73 | 56x3.5 | 49.6 | 0.50 | 98 | 160x5.7 | 149.4 | 1.65 | |
| 74 | 50x5.7 | 39.4 | 0.55 | 99 | 165x5.7 | 154.3 | 1.70 | |
| 75 | 51x5.7 | 44.4 | 0.55 | 100 | 170x5.7 | 159.3 | 1.80 | |
| (),(,). | |
| | | | () | | | | () |
| 101 | 175x5.7 | 164.3 | 1.90 | 130 | 240x8.6 | 224.1 | 3.80 |
| 102 | 180x5.7 | 169.3 | 2.00 | 131 | 245x8.6 | 229.1 | 3.90 |
| 103 | 185x5.7 | 174.3 | 2.20 | 132 | 250x8.6 | 234.1 | 4.00 |
| 104 | 190x5.7 | 179.3 | 2.30 | 133 | 255x8.6 | 239.1 | 4.10 |
| 105 | 195x5.7 | 184.3 | 2.40 | 134 | 260x8.6 | 244.1 | 4.20 |
| 106 | 200x5.7 | 189.3 | 2.50 | 135 | 265x8.6 | 249.1 | 4.40 |
| 107 | 210x5.7 | 199.3 | 2.80 | 136 | 275x8.6 | 259.1 | 4.60 |
| 108 | 220x5.7 | 209.3 | 3.00 | 137 | 280x8.6 | 264.1 | 4.80 |
| 109 | 230x5.7 | 219.3 | 3.20 | 138 | 290x8.6 | 274.1 | 5.00 |
| 110 | 240x5.7 | 229.3 | 3.40 | 139 | 295x8.6 | 279.1 | 5.20 |
| 111 | 250x5.7 | 239.3 | 3.60 | 140 | 300x8.6 | 284.1 | 5.40 |
| 112 | 260x5.7 | 249.3 | 3.80 | 141 | 305x8.6 | 289.1 | 5.60 |
| 113 | 270x5.7 | 259.3 | 4.20 | 142 | 315x8.6 | 299.1 | 5.80 |
| 114 | 280x5.7 | 269.3 | 4.50 | 143 | 320x8.6 | 304.3 | 6.00 |
| 115 | 290x5.7 | 279.3 | 4.80 | 144 | 330x8.6 | 314.3 | 6.20 |
| 116 | 300x5.7 | 289.3 | 5.10 | 145 | 335x8.6 | 319.3 | 6.40 |
| 117 | 170x8.6 | 154.1 | 2.30 | 146 | 350x8.6 | 334.3 | 6.60 |
| 118 | 175x8.6 | 159.1 | 2.40 | 147 | 355x8.6 | 339.3 | 6.80 |
| 119 | 180x8.6 | 164.1 | 2.60 | 148 | 360x8.6 | 344.3 | 7.00 |
| 120 | 185x8.6 | 169.1 | 2.70 | 149 | 370x8.6 | 354.3 | 7.20 |
| 121 | 190x8.6 | 174.1 | 2.80 | 150 | 375x8.6 | 359.3 | 7.40 |
| 122 | 195x8.6 | 179.1 | 2.90 | 151 | 380x8.6 | 364.3 | 7.60 |
| 123 | 200x8.6 | 184.1 | 3.00 | 152 | 390x8.6 | 374.3 | 7.80 |
| 124 | 205x8.6 | 189.1 | 3.10 | 153 | 395x8.6 | 379.3 | 8.00 |
| 125 | 210x8.6 | 194.1 | 3.20 | 154 | 400x8.6 | 383.3 | 8.50 |
| 126 | 220x8.6 | 204.1 | 3.40 | 155 | 415x8.6 | 399.3 | 9.00 |
| 127 | 225x8.6 | 209.1 | 3.50 | 156 | 420x8.6 | 404.3 | 9.50 |
| 128 | 230x8.6 | 214.1 | 3.60 | 157 | 460x8.6 | 434.3 | 10.0 |
| 129 | 235x8.6 | 219.1 | 3.70 | 158 | 500x8.6 | 484.3 | 11.0 |
| (),(,). |
|
We are specialized in manufacturing rubber seal ring, oil seal, special rubber gasket ring, non-standard rubber parts and plastic products with more than 20-year experience.
You can get more information from our website. We are factory, so small quantity is acceptable. Samples are available!
