Specifications- Electric Car Seal Lead Acid Battery
- Super Starting power and powerful long life
- Product are with pass ISO certificate,CE quality certificate and SASO,SONCAP test certificate
- OEM service
- Warranty:12 months
- Packing:Black Housing , Black lid
- Surperior Starting Power
- Material: Lead-acid starter battery
- Minimizing waters loss
- Extended battery's life,
- Application scope: Starting batteries of auto/automobile,cars, trucks, motorcycles, ships,marine boats and other vehicles.
- Stable performance in different temperature working environment
- provide greater vibration resistance;
- Size:505*180*208*231
- Capacity:120AH
- CCA(EN):870
- R.C(mins.)204
- Lay-out:3
- Terminal:B
Quanlity Warranty:Electric Car Seal Lead Acid Battery The quality guarantee is 12 months from our manufacture date or B/L date. We will replace any defective batteries by new ones. CertificationISO9001:2000, CE, SASO,SONCAP,etcStrict Production Procedures Control and Responsible staff, 5 Tips To Maintenance Your Car Battery
Your car battery is the heart of your car and if it's not beating with power, your car will only sit still. So take care of your battery and it will keep your car running for a long time. There are some fairly simple tips for taking care of your car battery.
Test Your Battery
· Regularly test your battery, particularly before a long trip and after it's been recharged. You don't want the battery to fail to start your car when you are far from home.
Park Your Car in a Garage
· An insulated garage helps keep your battery warm in the winter. This means it will be easier for your battery to start your car. If you don't have an insulted garage, then insulate the battery itself with a blanket.
Keep the Battery Clean
· When you test your battery, you might also want to clean it. This means removing the clamps and cleaning off the dirt and grease from the clamps and terminals. You want a clean connection so as not to weaken the charge. Clean the battery case itself with baking soda dissolved in warm water. Dirt can conduct electricity and discharge electricity.
Check the Fluid Levels
· When you clean your battery, check the fluid level as well. If it is low, add distilled water to top it off. Keeping the fluid levels full, will help extend the life of the battery. If you don't see any fluid, you may want to replace the battery. The lack of fluid is an indicator that the battery is near the end of its life.
Secure the Battery
· Secure the battery in the mounting bracket. A loose battery can slide around and become damaged. It might also cause a short circuit in some cases.
|
OLD JIS NO. |
NEW JIS NO. |
CAPACITY |
CCA
(-180C)
SAE |
DIMENSION(MM) |
TERMINAL |
QTY/Pallet |
20HR
(AH) |
R.C
(MIN) |
L |
W |
H |
T.H |
LAY-OUT |
TYPE |
|
NS40Z |
36B20R |
36 |
52 |
330 |
205 |
130 |
200 |
220 |
1 |
A/B |
224 |
|
NS40ZL |
36B20L |
36 |
52 |
330 |
205 |
130 |
200 |
220 |
0 |
A/B |
224 |
|
NS60 |
50B24R |
45 |
80 |
390 |
240 |
130 |
200 |
220 |
1 |
B |
175 |
|
|
55D23L |
60 |
99 |
550 |
230 |
173 |
201 |
220 |
0 |
B |
126 |
|
N50Z |
55D26R |
60 |
99 |
550 |
268 |
173 |
202 |
224 |
1 |
B |
126 |
|
NX120-7 |
95D31R |
80 |
153 |
650 |
310 |
175 |
204 |
225 |
1 |
B |
119 |
|
N100 |
95E41R |
100 |
170 |
800 |
404 |
171 |
199 |
219 |
1 |
B |
84 |
|
N120 |
135F51 |
120 |
204 |
870 |
505 |
180 |
208 |
231 |
3 |
B |
63 |
|
N150 |
160G51 |
150 |
255 |
1000 |
506 |
221 |
210 |
233 |
3 |
B |
56 |
|
N200 |
210H52 |
200 |
340 |
1400 |
515 |
265 |
215 |
238 |
3 |
B |
42 |
|
N70Z |
75D31R |
75 |
126 |
600 |
310 |
175 |
204 |
225 |
1 |
B |
119 |
Guangzhou Tiger Head Battery Group Co., Ltd. is situated in the Huangpu road, Tianhe District, Guangzhou, with its east neighboring to the Huangpu Port, its west to the Guangzhou East Train Station, the Exit to the Huanan Express Trunk Way, and its south facing the Pearl River. Thus it boasts of convenient transportation in both highways and waterways.
Guangzhou Tiger Head Battery Group Co., Ltd. is an export-oriented enterprise specializing in battery production and management, with the largest scale in Chinese battery industry. It realizes annual output of 2 billion pieces of dry batteries and earns over 308 million U. S. Dollars of foreign exchange per year, which makes it the leading battery enterprise in China.
The company' S main products are "555", "Tiger Head" and " TIHAD" brand all kinds of dry batteries, lead-acid storage batteries, Ni-MH batteries, polymer Li-ion batteries and some battery-related appliances.
The trademark "Tiger Head" of the company is the first "Chinese Well-known Trademark" in Guangzhou as well as in the country' S battery industry, and the trademark "555" the "Famous Trademark" in Guangzhou city as well as in Guangdong province. "555" brand R20S batteries have won National Excellent Quality Silver Award, while"555" brand LR6 alkaline batteries have won National Excellent Quality Gold Award. Moreover, "555" brand zinc-manganese alkaline batteries have been rewarded as "Chinese Top Brand Products" and "National Inspection Exemption Products".
Based on strengthening quality control and seeking development via technical progress, Tiger Head Battery Group Co., Ltd. Has been making persistent efforts to excel. As the first company using computer-controlled automatic discharging detection facility among the same business in China, the company has had a strict quality monitoring system in production. Thus for years running, the company has been evaluated as the "Advanced Enterprise of Quality and Profit" by the Ministry of Foreign Trade and Economic Cooperation, PRC, the State Bureau of Light Industry, and the Quality Control Association of Guangdong Province.
Since the year 1999, the company has been performing series of reforming with a capital outlay of RMB 400 million, introducing the most advanced production line of mercury free zinc-manganese alkaline battery, thus providing the consumers with environment friendly batteries of high performance. The company adopts in production the special explosion-proof structure, new material, new formula, new technique and the special sealing technology, all in the leading position in the world, which makes true the Mercury-free and Pollution-free in battery production fives years ahead of the national schedule. Recently, the company invested RMB 1.5 million independently developing the Real-time Monitoring Management System via IT new technology, which includes several parts of on-the-spot production management, operation instruction, and figures analysis, etc. This system, via visual image transformation and vivid industry control charts, can help monitoring persons to get accurate first-hand information about the production, even they are not on the production spot. Thus, it helps to improve management efficiency and reduce management cost. Today, a modernized Battery City has been set up in the new factory zone with the area of 170 thousand square meters.
