PARAMETERS | MLDJ250 |
Rated Lifting Capacity | 25000Kg |
Maximum Lifting Height | 1750mm |
Equipment Minimum Height | 350mm |
Overall Length & Width after Installation | 12400mm*2680mm |
Width of Single Platform | 750mm |
Time of Full Rise | ≤120 sec |
Voltage(multiple options) | 220v, 3phase /380v, 3phase /400v, 3phase |
Motor Power | 7.5Kw |
Maximum Hydraulic Pressure | 18Mpa |
1. Unique Synchronization System: It ensures smooth up and down of the lift even when the two lifting platforms are unevenly loaded.
2. Human Engineering: Two lifting platforms function as the carrying agency and each lifting platform is equipped with two cylinders, one at each end. The lift also includes an independent electrical control system, a hydraulic power unit as well as an emergency descent device in case of power failure.
3. Unique structure: The Y-type lifting arm greatly enhances bearing rigidity of the platform and simplifies overall structure of the lift. Furthermore, the Y-type spares more repair space under the platform, thus ensuring free passage of servicing equipments underneath.
4. High Cost-effectiveness: The electronic and hydraulic control systems share one movable control box, which greatly compacts structural allocation and facilitates daily operation. The lift itself is easy to assemble and disassemble, and can be re-installed easily during factory relocation.
5. Safety Assurance: The lift has double safety guarantee under load status, i.e. hydraulic support and mechanical lock; it is also designed with limit switch, so that it can stop in no time when the ultimate position is reached. In case of any unexpected power failure, the lift can be descended simply by turning the manual lower knob. In addition, the lift is also equipped with overload over-flow protection device.
Company Profile
Founded in 1992, MIT Group has been focusing on automobile after-sales markets over the years and has grown to be the leader in the industry, supplying state-of-the-art products and services to our esteemed clients all over the world. The Group's brands include MAXIMA, Bantam, Welion, ARS and 999.
As a subsidiary under MIT Group, MAXIMA is a professional manufacturer of auto-body repair systems and heavy duty column lifts, ranking as No.1 in the industry in China over the years, as taking up 65% Chinese market and shipping to 40+ countries overseas. Proudly, MAXIMA is the unique company in China that can provide the most professional innovative solutions, technical development, training and customer support for auto-body repair and maintenance. We will look forward to building business cooperation with distributors and customers worldwide.
FAQ
Q1: What is your terms of payment?
A: 30% TT as deposit upon order confirmation, 70% TT as balance before delivery.
Q2: What is your standard leadtime?
A: For car bench, the standard leadtime is 30 days after order confirmation.
For electronic measurement system, the standard leadtime is 20 days after order confirmation.
For mobile column lift, the standard leadtime is 40 days after order confirmation.
For big platform and platform lift, the standard leadtime is 50 days after order confirmation.
Q3: What delivery terms do you offer?
A: EXW, FOB, CFR, CIF, DDU.
Q4: Do you test all your products before delivery?
A: Yes, all products are 100% tested before delivery.
Q5: Why do we choose MAXIMA?
A: MAXIMA is ISO certified manufacturer, CE certified, and the only one ALI certified brand in China, offering best quality products at a very competitive price.
We offer 2 years of free warranty for all products; we have an overseas after-sales engineer ready to fly to any site upon emergent request from customer.
Q6: What exhibitions do you attend?
A: Inside China, we attend AMR Beijing in Mar. and Automechanika Shanghai in Dec.
In overseas, we attend Autopromotec Bologna in May and Automechanika Frankfurt in Sep.
Warmly welcome to visit our factory in Yantai and our booth in the shows.
Q7: Do you have any branch in overseas?
A: We have a branch office in California, USA, covering the sales of North American countries including U.S, Canada, Mexico etc. MAXIMA U.S has ready stock and will make delivery to North American countries immediately upon order confirmed.
For all the rest countries and regions, we will do build-to-order, sales and delivery from MAXIMA China headquarters.
Contact with us
Please feel free to contact with us at any time via email or call.
Found in 1992, MIT group / MAXIMA has successfully become the leading supplier of auto aftersales services and equipments, and we are supplying to VW, GM, Honda, CITROEN, Toyota, Nissan, Zhonghua and some other car manufacturers.
In the past scores of years, MAXIMA has become No. 1 seller in domestic market by sharing 65% of total market, and also exporting to more than 35 countries, such as USA, UK, Spain, Australia, Norway, Brazil, South Africa...
As the first company in this industry passed the ISO 9001 certification in China, Maxima takes the advantage of state-of-the-art production line, world-class inspection systems, experienced R&D working team and perfect quality control management which set up a great and solid basis for us to pursue our aim: Providing the world-class auto repair equipments for our customers all over the world.
