Manufacturer's Direct Dealing Brake Cutting Lathe/Brake Drum/Disc Lathe (T8465)
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Specifications
High cost performance
2. Easy operation
3. Ideal for repair brake drum/disc of automobiles.
Features:
1. Brake drum lathe T8465 is a kind of lathe. It can fulfill the reparation of the brake drum, disc and shoe of automobiles from minicar to medium trucks.
2. The brake drum/shoe can be cut on the first Spindle and the brake disc can be cut on the second Spindle.
3. This lathe has higher rigidity, accurate workpiece positioning and is easy to operate.
4. If you adopt this brake drum lathe, there is no doubt for your enterprise to set up higher reputation due to better process quality and lower your process cost.
| Item | T8435 | T8445 | T8465 |
| Brake drum diameter | mm | 180-350 | 180-450 | 180-650 |
| Brake disc diameter | mm | ≤350 | ≤400 | ≤500 |
| Working travel | mm | 150 | 170 | 250 |
| Spindle rotation speed | rpm | 80,120 | 30,52,85 | 30,52,85 |
| Feeding capacity | mm/r | 0.16 | 0.16 | 0.16 |
| Main motor | Kw | 0.55 | 1.1 | 1.1 |
| Overall dimension(L*W*H) | mm | 544*627*640 | 690*890*880 | 1250*980*1110 |
| Net weight | Kg | 240 | 320 | 540 |
| Prod Model: |
T8465 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rotating Speed Of Workpiece: |
30/52/85r/Min |
| Max Travel Of Tool: |
250mm |
| Motor Power: |
1.1kw |
| N.W: |
580kg |
Brief introduction
Zaozhuang Make Machinery Co., Ltd., located at Zaozhuang city Shandong province, which is the midway between Beijing and Shanghai, closed to Qingdao port, has been focusing on manufacturing machine tools for more than 20 years. This is an integrated manufacturing company which includes design, machining, assembly, installation, commissioning and after-sales service. With a long time experience in exporting machines, we are specialized in servicing international customers, and in particular, familiar with the quality standards from different countries. This enables us to supply our customers consistent high-quality products, as well as providing excellent customer services. Zaozhuang Make Machinery Co., Ltd. is your ideal cooperative partner, with our continuing growth through dedicating ourselves to growth of our customers.
Strength
1. Dealing directly with the manufacture-----no middle man
2. The most competitive pricing in the market.
3. High-quality control standards, such as ISO, CE
4. Prompt attention to customer inquiries.
5. Diverse services for your needs, including sourcing other machinery and purchasing them as your agent, inspection goods for you by our engineers, the spare parts distribution, quality modifying, product process tracking and good delivery. The feedback to you will be within 24 hours.
6. Research and development to meet needs of customers and the market.
Product range
1. Plano miller: Series CNC Plano Miller, Series Plano Milling Machine, Series Gantry Milling Machine, Series Planer Milling machine
2. Series Guideway Grinding machine
3. CNC machine center
4. Series Conventional Milling Machine & Milling/ Drilling Machine
5. Drilling machine: Series CNC Drilling Machine, Series Radial Drilling Machine, Series Vertical Drilling Machine
6. Lathe: Series CNC Lathe, CNC Lathe-Inclined bed type
7. Hydraulic Press: Series Gantry Hydraulic Press, Series C-Type Hydraulic press, Series Hydraulic Bend
8. Garage equipment: Series Cylinder Boring Machine, Cylinder Honing machines, Series Brake Drum Boring Machine, Brake Lathe,
Brake Drum (Disc) Cutting Machine
9. Riveting Machine: Series Hydraulic Riveting Machine & Pneumatic Riveting Machine
10. Light Slotting Machine & Slotting Head
11. Bench Grinder & Vertical Grinding Machine
12. Series Arbor press
13. Accessories like Vice, Angle Clamp, Slotting Head, DRO, Dividing Head, Rotary Table, Grinding wheel balancer, Universal boring head, Clamp kits, etc.
Research and Development
Our products are based on research and development to ensure needs of customers and the changing market.
Quality Control
Quality control is the key principle for Zaozhuang Make Machinery Co., Ltd. Our manufacturing has adopted modernized ISO Quality Management Systems, sound operational procedures as well as effective product and customer service system.
These systems ensure all products produced under very strict quality control, maintaining our high standards to ensure your ongoing success by using our products.
Quality guarantee period
We guarantee all our products to be defect free for one year from the date of purchase. Our after-sales service will cover any issue that may occur promptly.
Customer service
We have professional technicians to provide ongoing support for customers, during and after the guarantee period. We will attend your requests including large-type CNC machine tools installation and adjustment.
Special order
With our extensive experience in this industry, we are in the best position to meet needs of our customers, for both normal standard commodities and special orders. We guarantee to have the best price for your product based upon your detail requirements.
YOUR GOAL, OUR GOAL.
