Jingjiang E-Asia Bearing Co., Ltd. >> Iinear Bearing Lm8uu

Iinear Bearing Lm8uu

Iinear Bearing Lm8uu
Price: US $ 0.168/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Paypal,Money Gram
Deep groove ball bearings are the most widely used bearing type. It has deep, uninterrupted raceway grooves. These raceway grooves have the close osculation with the balls, enabling the bearings to accomodate radical and axial loads in both directions.
In addition to open type bearings, these bearings often have steel shields or rubber seals installed to one or both sides and are pre-lubricated with grease. Also, snap rings are sometimes used on the periphery. As to cages, pressed steel ones are the most common ones. For big deep groove ball bearings, machined brass cages are used. Machined cages are also used for high speed applications.

Maximum type ball bearings
These bearings are single-row deep groove ball bearings with a filling slot on both the inner and outer rings. They feature an enhanced radial load rating as they can contain more balls of larger diameter.
Not suitable for applications that involve axial loading or high-speed rotation.
When the bearing is installed, the filling slot on the fixed bearing ring should be in a no-load area
N0. Bore O.D Width Chamfer Load Rating Maximuum Seed Weight
mm mm mm mm Dynamic
Cr
Static
Cor
Grease
r/min
Oil
r/min
Kg/pcs
604 4 12 4 0.2 0.97 0.36 36000 44000 0.0021
605 5 14 5 0.2 1.33 0.505 32000 40000 0.0035
606 6 17 6 0.3 2.19 0.865 30000 38000 0.006
607 7 19 6 0.3 2.24 0.91 28000 36000 0.008
608 8 22 7 0.3 3.35 1.4 26000 34000 0.012
609 9 24 7 0.3 3.4 1.45 24000 32000 0.014
6000 10 26 8 0.3 4.55 1.96 22000 30000 0.019
6001 12 28 8 0.3 5.1 2.39 19000 26000 0.021
6002 15 32 9 0.3 5.6 2.83 18000 24000 0.03
6003 17 35 10 0.3 6.8 3.35 17000 22000 0.039
6004 20 42 12 0.6 9.4 5.05 15000 19000 0.069
6005 25 47 12 0.6 10.1 5.85 14000 18000 0.08
6006 30 55 13 0.6 13.2 8.3 12000 15000 0.116
6007 35 62 14 1.0 16 10.3 10000 14000 0.115
6008 40 68 15 1.0 16.8 11.5 8000 11000 0.19
6200 Series Miniature Deep Groove Ball Bearing
N0. Bore O.D Width Chamfer Load Rating Maximuum Seed Weight
mm mm mm mm Dynamic
Cr
Static
Cor
Grease
r/min
Oil
r/min
Kg/pcs
624 4 13 5 0.2 1.15 0.4 36000 45000 0.0032
625 5 16 5 0.3 1.76 0.680 32000 40000 0.0050
626 6 19 6 0.3 2.34 0.885 28000 36000 0.0080
627 7 22 7 0.3 3.35 1.400 26000 34000 0.0130
628 8 24 8 0.3 4.00 1.590 24000 32000 0.0170
629 9 26 8 0.3 4.55 1.960 22000 30000 0.0190
6200 10 30 9 0.6 5.10 2.390 19000 26000 0.0300
6201 12 32 10 0.6 6.10 2.750 18000 24000 0.0360
6202 15 35 11 0.6 7.75 3.600 17000 22000 0.0460
6203 17 40 12 0.6 9.60 4.600 16000 20000 0.0650
6204 20 47 14 1.0 12.80 6.650 14000 18000 0.1070
6205 25 52 15 1.0 14.00 7.850 12000 16000 0.1250
6206 30 62 16 1.0 19.50 11.300 10000 13000 0.2010
6300 Series Miniature Deep Groove Ball Bearing
N0. Bore O.D Width Chamfer Load Rating Maximuum Seed Weight
mm mm mm mm Dynamic
Cr
Static
Cor
Grease
r/min
Oil
r/min
Kg/pcs
6300 10 35 11 0.6 8.2 3.5 18000 24000 0.053
6301 12 37 12 1.0 9.7 4.2 17000 22000 0.06
6302 15 42 13 1.0 11.4 5.45 16000 20000 0.082
6303 17 47 14 1.0 13.5 6.55 15000 19000 0.115
6304 20 52 15 1.1 15.9 7.9 14000 17000 0.144

Prod Model: lm8uu
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Cage: Steel,Brass
Model Number: 608z 604z 605z 607z 609z
Bore Size: 3 - 2390 Mm
Outside Diameter: 9 - 2690 Mm
Presicion: P0,P6,P5,P4,P2
Fuction: Low Cost&Low Noise
Key Words: Ball Bearings
Structure: Single Row
Original: USA China
Certification: ISO9006
Type: Wheel Hub Bearing
Material: Chrome Steel
ABS: With ABS
Tolerance: P0
Clearance: C0
E-Asia was set up in 1996 and located at Jingjiang, a beautiful city in China. Our company is bearing manufacturer&bearing distributor. Since it was first established, E-AISA was dedicated in research, development and manufacture of bearings. Now, E-AISA has become main and one of the first grade suppliers of all kinds of bearings.

Our products include: Deep Groove Ball Bearings, Self-aligning Ball Bearings, Spherical Bearings, Tapered Roller Bearings, Cylindrical Roller Bearings, Needle Roller Bearings, Self-aligning Roller Bearings, Angular Contact Ball Bearings, Thrust Ball Bearings and Trust Roller Bearings and Special Bearings. We also provide OEM beaings.

E-Asia is a backbone enterprise for bearing production in China. With an area of 60, 000 square meters, more than 260 sets devices and machines, and around 200 employees, our company annually turns out more than 6 million sets bearings.

Our Bearings are exported to the USA, Canada, UK, Germany, Poland, Italy, Russia, the Middle East, Africa and other countries and regions of the world. E-Asia Bearing Co. Ltd. Is committed to the introduction of high-quality bearing products. Our company have more than 200 employees. Our brands include SKF bearings, NSK bearings, TIMKEN bearings, KOYO bearings, NTN bearings, IKO bearings and so forth.

Our belief is "Specialization is quality; Quality is the future. Any product with 0.01% defect is 100% reject" is our quality policy.
