| Prod Model: |
CLZ-3.2AT |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Lifting Height: |
1870mm |
| Equipment Height: |
2736mm |
| Lifting Time: |
30-40s |
| Distance Between 2 Post: |
2780mm |
| Power Supply: |
110V/220V/240V/380V,1pH/3pH |
| Motor: |
2.2kw |
| Dimension: |
2840mmx520mmx825mmx1 780mmx280mmx340mmx1 |
| Volume: |
1.5cbm |
| Color: |
Red, Grey, Blue |
| Type: |
Double Cylinder Hydraulic Lift |
| Certification: |
GS |
| Design: |
Two Post |
| Lifting Capacity: |
3.2t |
| Brand: |
Captain |
Product Description
Feature:
Two -side manual unlocking,
Asymmetrical arm, Screw up adjustment arm pad
Safe and Anti-explosion oil cylinder
Pump station with CE certification
Imported rubber seal from parker USA, High quality raw flat material
380v/220v voltage
Features
Cover plate design, convenient for repairing and operation, colours option
Duplex Cylinder two post
Aluminum shell motor prevents overheated
Automatic safety locks
Automatic arm restraints
Operating control system with 24V safety voltage
24V height limit switch provided
Preventing rubber pad and foot protection
Screw type support and height support
Hydraulic pressure pre-setting can avoid lifting exceed rated load.
Cable-equalization system
Wear-resistant, hear-resistant and high strength
Maintenance free load bearing
Plastic powder coat finish.
Pass 120% capacity dynamic load test and 150% capacity static load test
Italian oil seal to make sure no oil leakage
Optional manual pump on power unit in case of power off
Captain Spray Booth(Qingdao Hua Yushun Commercial Co., Ltd)
Is a professional leading factory in China, who is specializing in manufacture kinds of paint spray room system. And also offering full garage equipments, such as
Car care equipment.
Car spray&baking room system
Bus spray&baking room system
Furnitue spray&baking room system
Industrial painting&baking room system
High temperature baking room system
Customized spray&bake booth and Offer car spray baking booth accossories
Services We Supply
Customized service
More Than 90% Of Our Spraying Booth Is Customized.
1. We can design the machines according your requirements. At the same time, our engineers will give you our professional suggestions.
2. We can give you free technical support and consultation such as design your factory, make the factory layout drawing and so on.
After-sales service
1. Our fast and professional after service engineer team can go to your factory and install the machine, give you the operating guidance, and train your employees until they can operate the machine well.
2. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
3. We provide 2 years warranty.
Captain Advantages
*The same price higher quality, the same quality lower price! ! !
*2 years quality warranty! ! !
*Fast and stable supply capability! ! !
*Personalized design to meet customer various needs! ! !
Competitive Price and High Quality Spraying Booth with Perfect Service Is From Here.
SPECIFICATION
Model |
Lifting capacity |
Lifting height |
Equipment height | Width between
posts |
Motor power |
Power supply |
CLZ3.2AT |
3.2 T |
1870mm |
2736mm |
2780mm | 2.2
KW |
220v/380v/240v |
DEEEESSSSCCCCRRRRIIIIPPPPTTTTIIIIOOOONNNN
1. Two hydraulic cylinders driving, chain' sprocket driving, stable lifting.
2. Using two wire connecting, forcing the two synchronized slide move, effectively prevent the vehicle tilt.
3. Combination seals prevent oil imports.
4. The minimum lift height is 110mm, for easy maintenance high-end cars.
5. Two columns are equipped with safety devices. Features:
1. Strong column
2. Double hydraulic cylinders lift
3. Double-lock protection device
4. Automatic unlocking device
5. Chain lifting system
6. Balanced system of wire rope Supper chassis, security firm
