| Prod Model: |
CSZ-3.5T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Lifting Height: |
1700mm-2000mm |
| Between Post: |
2716mm |
| Width Of Each Platform: |
560mm |
| Min Height Of Platform: |
175mm |
| Pressure: |
16MPa |
| Power Supply Voltage: |
220V/380V/240V,50/60Hz |
| Motor Power: |
2.2kw |
| Lowering Time (Loaded): |
30s |
| Lifting Time (Loaded): |
40s |
| Color: |
Grey, Blue, Red |
| Type: |
Four Cylinder Hydraulic Lift |
| Lifting Capacity: |
3.5T |
| Certification: |
GS |
| Design: |
Four Post |
| Brand: |
Captain |
Product Description
Specifications
Model: CAPTAIN-PCL5500 4 Post car lift parking
Come with Rolling jacks and Side Slipping plate.
Features:
The best choice for parking and simple repair
Hydraulic driven, cable lifting system
Manual or electric single point release
Automatic lock system ensure safety at different heights
Maintenance free load bearing
Immovable runway
Stop blocks in all posts for added safety
Moveable drip trays prevent pollution of vehicle on floor
Caster kit for moving the lift easily
Mold machining through the whole process
120% capacity dynamic load test and 150% capacity static load test
Italian oil seal to make sure no oil leakage
Solenoid valve with emergency manual drop function
Optional manual pump for lock release in case of power off.
Optional 24V control box and solenoid valve
Features:
Ø Flat deck design
Ø Maintenance free load bearing
Ø Automatic safety locks
Ø Strong hydraulic cylinder
Ø Adjustable runway
Ø Hydraulic rolling jack (optional)
Ø 4 point leveling system
Ø Automatic safety release
Ø Powder coat finish
Captain Spray Booth(Qingdao Hua Yushun Commercial Co., Ltd)
Is a professional leading factory in China, who is specializing in manufacture kinds of paint spray room system. And also offering full garage equipments, such as
Car care equipment.
Car spray&baking room system
Bus spray&baking room system
Furnitue spray&baking room system
Industrial painting&baking room system
High temperature baking room system
Customized spray&bake booth and Offer car spray baking booth accossories
Services We Supply
Customized service
More Than 90% Of Our Spraying Booth Is Customized.
1. We can design the machines according your requirements. At the same time, our engineers will give you our professional suggestions.
2. We can give you free technical support and consultation such as design your factory, make the factory layout drawing and so on.
After-sales service
1. Our fast and professional after service engineer team can go to your factory and install the machine, give you the operating guidance, and train your employees until they can operate the machine well.
2. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
3. We provide 2 years warranty.
Captain Advantages
*The same price higher quality, the same quality lower price! ! !
*2 years quality warranty! ! !
*Fast and stable supply capability! ! !
*Personalized design to meet customer various needs! ! !
Competitive Price and High Quality Spraying Booth with Perfect Service Is From Here.
Specification
| Model | Lifting | Lifting | Width | Motor | Hydraulic | Power supply |
| | capacity | height | between
posts | power | pressure | |
CSZ3.5T |
3.5 T |
1700mm |
2716mm | 2.2
KW |
16Mpa |
220v/380v/240v |
Features:
1. Hydraulic rolling jack
2. second lift system
3. automatic safr locking system
4. Maintainance free load bearing
5. Open coat finish
Description
1, hydraulic drive, rope drive, smooth, no noise. 2, wide working space, easy operating.
3, with the second car lift, can contribute to the rails at any position. 4, the front turntable (optional) adjustable, flexible skateboarding.
5, the machine is equipped with self-locking process, protection t from rope broken. 6, the level of positioning is precious, ideal device for four wheel alignment
Requirements:
1, the ground surface level difference should be less than 5mm.
2, the thickness of concrete foundation should be more than 150mm, strength should be greater than 200 #, under this conditions, the anchor bolts can be directly nailed up.
Qingdao Hua Yushun Commercial Co., Ltd belongs to Captain Auto Equipment Group, which is responsible for exporting for all the products of Captain Group. And Captain is a professional designer and manufacturer of mechanical equipment, which is developed from SK spray booth built in 1992. Captain developed day by day, and established Shandong painting production base and sandwich panel production base. Now it can produce painting equipments more than 3000 sets, about 2, 000, 000 square meters different kinds of sandwich panels, and various kinds of steel ducting 800, 000 meters one year. Also Captain established Zhucheng sandblasting production base in 2002, and injection pieces production base in 2005. And in 2006, Captain established Qingdao Commercial Center, which is operated by Qingdao Hua Yushun Commercial Co., Ltd who is responsible for all the global importing and exporting business. Formed a good industry pattern that is the sells presses to production, and production streghten sales.
· Now the products of Captain group refer to auto repair quipments, furniture spray booth, preparation bay, shot blasting machine, antiseptic treatment production line, injection pieces, all kinds of EPS panel, rock wool panel, glass fiber panel and decorative panel outside, commercial kitchen equipment, etc.
· After all these years, high-quality products and good service won wide reputation for our group from our buyers, and our products are exported to Germany, the United States, Sweden, the Netherlands, Denmark, Romania, South Africa, Australia, Canada, Italy, New Zealand, Nigeria, Zambia, Thailand, Chile and other countries and regions.
Face to the ever-changing market, Captain looks providing more secure, reliable, energy conservation and environmental protection products as it's responsibility, listens to the buyer's comments carefully, improve the quality of products and service, Continue to increase the research and development ability of enterprise innovation and equipment; We will paste with the future, and slipped through the waves.
