Europe Auto/Bus/Truck Car Spray Paint Booth for Sale
| Price: |
US $ 20000-58000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
CPYE18 001 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Outside Size:(mm): |
18156X7516X5800 |
| Inside Size:(mm): |
18000X6000X5000 |
| Front Door:(mm): |
4100(W)X4500(H) |
| Total Power:(Kw): |
85kw |
| Wallboard: |
75mm EPS Panel with 0.5mm Steel |
| Basement: |
Two Rows of Pits with Galvanized Grids |
| Intake Air System: |
6X7.5kw |
| Exhaust Air System: |
3X11kw |
| Heating System: |
3 Sets Rg5s Diesel Burners |
| Lights: |
112PCS Philips Lights |
| Certification: |
CE |
| Airflow Direction: |
Fully Undershot-type |
| Heating Mode: |
Used Oil |
| Paint Mist Treatment: |
Dry-type |
| Condition: |
New |
| Brand: |
Captain |
Product Description
Quick Details
Type:Spray Booths
Power:52kwExternal
Size:18156x7516x5850 mm
Internal Size:18000x6000x5000 mm
Voltage:220/380v 50HZ
Outside Size:(mm) 18156x7516x5800
Front Door:(mm)
4100(w)x4500(h)
Inside Size:(mm)
18000x6000x5000
Total Power:(kw)
85
Cabin System
Wallboard
EPS (epispastics polystyrene)Colorful Steel Skin Boards,75mm Thick, Tongue & Groove Style, Compound Construction, Aluminum-alloy Frame ,Anti-flame and Heat-Insulation with the strong support of powder coated pillars inbetween.
Basement
Two rows of pits with galvanized duty-bearing grids for air sucking
Air Circulation System
Inhaling
Ventilator
Type&Model:
YDW-5.6M
Exhaust Ventilator
Type&Model:
4-82-6.3E
Blower Capacity: 21000m3/h
Blower Capacity: 35000m3/h
Pressure: 800Pa
Pressure: 800Pa
Rolling Speed: 900rpm
Rolling Speed: 900rpm
Quantity: 6 sets
Quantity: 3 sets
Air Volume: 12000m3/h; Air Speed: 0.31m/s
Air Purification System
Dual Filtering Structure, The Primay Filter Can Capture Granules Larger than 10 μm. Inflammable Ceiling Filter Capture Granules Bigger than 4μm. The Whole Purification System Has Capacity of Large Volume of Dust. Its Filtering Rate Reaches 98%. Air Pressure Gauge, TSP≤1.4mg/m3
Heating System
Burner
Italy Riello Brand,RG5S Diesel Burner x 3 Sets, 260000Kcal/h, 20N Damp Motor
Heat Energy Converter
SUS304 Stainless Steel, Argon Arc Welding, The Heat Exchange Rate 85%
Max Temp:80.C, Heating Time: 15-20min(20-60°C), Fuel Consumption: 10-12kg/vehicle
Light System
Ceiling Light: 112 pcs 36w Philips Lamp; Side Light: 60 pcs 36w Philips Lamp, 900 Lux,
Electric Controlling System
Spray & Baking Switch, Light Switch, Emergency Stop, Breakdown Alarm, failure alarm, timer
Environmental System
Multi-Layer Fiber glasses Filter, active-carbon, and ensure a qualified exhaust according to the relevant state standards
Optional 3-Dimention trolley as an optional is available for easily painting work
