Duarble Quality Radiator Silicone Hose for autoWholesale of Silicone & braided Hoses, for coolant, water, fuel and oil. Also Aluminium pipes & fabricated tanks.
We are a China hose manufacturer known for unrivalled quality and service. A trusted leading brand of Silicone Hoses and associated fluid transfer product supplying Motorsport, Race teams, Marine, Military, Trucks, Buses, Bikes, Agricultural, Pharmaceutical, Machinery, Plant, Commercial vehicles, the Rail industry, and more
We do Intercooler hoses, Turbo hoses, Aluminium Induction pipes, Coolant & Radiator hoses, Breather hoses, Vacuum tubing, also Braided fuel and oil hoses, together with corresponding hose fittings, adaptors, fuel filters and other accessories for all professional fluid transfer applications.
- Made from Silicone and reinforced with polyester, can operate at higher temperatures and pressures than rubber hoses.
- High quality gloss finish, last longer, are easier to clean, Direct bolt on, OE fitment or replacement.
- One year replacement Warranty Against Manufacturing Defect.
Silicone Hose Features:
Working temperature: -60 ~ 260 degrees
Working Pressure: 0.3 to 0.9MPa
Bursting Pressure: 2MPa
Thickness: 4 to 5 mm, 3 ply
Size tolerance: +/-0.5mm
Email us your designs, we can make customized elbow silicone hose and special type for you.
| Type | Inner diameter(mm) | Layer | Thickness(mm) | Length(mm) |
| 45 degree elbow | 6.5 | 3 | 4.5 | 63 |
| 45 degree elbow | 8 | 3 | 4.5 | 63 |
| 45 degree elbow | 9 | 3 | 4.5 | 63 |
| 45 degree elbow | 11 | 3 | 4.5 | 63 |
| 45 degree elbow | 13 | 3 | 4.5 | 102 |
| 45 degree elbow | 16 | 3 | 4.5 | 102 |
| 45 degree elbow | 19 | 3 | 4.5 | 102 |
| 45 degree elbow | 22 | 3 | 4.5 | 102 |
| 45 degree elbow | 25 | 3 | 4.5 | 102 |
| 45 degree elbow | 28 | 3 | 4.5 | 102 |
| 45 degree elbow | 30 | 3 | 4.5 | 102 |
| 45 degree elbow | 32 | 3 | 4.5 | 102 |
| 45 degree elbow | 35 | 3 | 4.5 | 102 |
| 45 degree elbow | 38 | 3 | 4.5 | 102 |
| 45 degree elbow | 41 | 3 | 4.5 | 102 |
| 45 degree elbow | 45 | 3 | 4.5 | 102 |
| 45 degree elbow | 48 | 3 | 4.5 | 102 |
| 45 degree elbow | 51 | 3 | 4.5 | 102 |
| 45 degree elbow | 54 | 3 | 4.5 | 102 |
| 45 degree elbow | 57 | 3 | 4.5 | 102 |
| 45 degree elbow | 60 | 3 | 4.5 | 125 |
| 45 degree elbow | 63 | 3 | 4.5 | 125 |
| 45 degree elbow | 70 | 3 | 4.5 | 125 |
| 45 degree elbow | 76 | 3 | 5 | 125 |
| 45 degree elbow | 80 | 3 | 5 | 125 |
| 45 degree elbow | 83 | 3 | 5 | 125 |
| 45 degree elbow | 89 | 3 | 5 | 125 |
| 45 degree elbow | 102 | 3 | 5 | 152 |
