Dent Pulling Machine & Spot Welder and MIG Welder Spot Welding machine

Name: Dent Pulling Machine & Spot Welder and MIG Welder Spot Welding machine
Brand: ibuyautoparts.com
SKU: 812286725
Availability: InStock
Rating: 4.3 (108 reviews)

Price:	US $ 1-2/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Multifunctional Resistance Spot Welder

Description:

FY8000-250 is a multi tasking welder which combines a variety of functions into one unit. The system caters to all your welding needs such as spot welding, MIG welding, dent pulling, sheet metal welding, carbon heating and shrinking and triangle washer welding. Despite its size and many functions it is still simple to operate and easy to manoeuver. Your work can be done quickly and easily with one of the best tools in the auto collision repair industry.

Features:

All in one design for high quality spot welding and MIG welding in one unit

Suitable for dent pulling of different kinds of car steels such as conventional steel and stainless steel

A welding gun test function to evaluate the usage status of the welder

A variety of welding procedures are available such as shrinking, washer, direct-pulling, spot welding, flattening, waveform wire, stud welding, OT washer and triangle washer

Complete with pneumatic vacuum cupule

Complete with rotatable gun cable support arm

Complete with heated gas regulator

MIG welder with welding current 250A, spot welder with maximum welding current 5400A and input voltage 380V

Complete with VPOWER wire feeder

Taiwan TIANWEI switch

With the world famous EMIR brand welding gun

Separated wire feeder and welding gun with extendable cable is available as an option

Specifications:

Input voltage:

Input power:

Input current:
Max welding current:
One-side welding thickness:
Cable length:

Input voltage:

Rated maximum supply current:

Maximum effective supply current:

Output current /voltage:

No-load voltage:

Welding current range:

Weldable wire:

Dimensions:

Weight:

AC 200-240V or 380-440V 50/60Hz

21KVA
55A
5400A
0.8+1.2mm
2300+1900mm

AC220V or 380V

16.8A

12.5A

35A/17V - 250A/26.5V

20-37V

35-250A

Low carbon steel solid wire φ0.8-1.0mm

870 x 460 x 1650mm

138kg

Prod Model:	FY-8000-250
Demension:	870 X 460 X 1650mm
Weight:	140kg
Usage:	Welding
Voltage:	AC 200-240V or 380-440V 50/60Hz
Power(W):	21kVA
Certification:	ISO9001:2000
Warranty:	3 Years
After-Sales Service Provided:	Overseas Service Center Available
Color:	Gray
