Common rail injector tester bench NTS200 EPS200 China Lutong Parts Plant, is a professional OEM & aftermarket parts supplier which specialized in high quality
diesel fuel injection parts & locomotive diesel engine parts with a long history, Our main products include Head Rotor(VE Head Rotor,Perkins Head Rotor),Diesel Nozzle,Diesel Plunger,Diesel Elements,Diesel Injectors,Delivery Valve,Cam Disk,Drive Shaft,Repair Kits,Feed Pump,Roller Ring,VE Pump Parts,Nozzle Tester,Test Bench,Common Rail Injector,Common Rail Nozzle,Common Rail Injector Control Valve.and so on.
As being in the business line for years,we always keep our steps with the international standard and technics and absorb the advanced producing system.So our products are exported to wide client-base spread across the world.
We serve our customers in a courteous and professional manner.In pursuit of excellence,we also establish an efficient logistics and reaction system.We ensure that all the questions could be answered in the shortest time with satisfaction,all the products be delivery in stipulated frame of time.In general,we are not only producing our products,but also provide the full after-sale service and complete solution.
Product DescriptionEPS200/NT200 test bench is our latest indepentent researched special device to test the performance of high-pressure common rail injector, controlled by industrial computer, Windows operating system. The oil quantity is measured by sensor and displayed on computer screen(Electronic fuel delivery system). All data can be searched and saved. It adopts BOSCH original common rail pump to provide 0~2000 bar for rail pressure. The rail pressure can be adjusted automatically, and it also provide pressure overload protect. It can test common rail injector of BOSCH, SIEMENS, DELPHI, DENSO. Advanced technology, steady performance, precise measurement and
>>>CHARACTERISTIC1. Controlled by industrial computer in real time, Windows operating system.
2. Oil quantity is measured by sensor and displayed on 10.4 tactile LCD screen;
3. More than 700 kinds of injecotors data can be searched and used.
4. It is installed BOSCH common rail pump to provide 0~2000 bar
5. Rail pressure can be tested in real time,
6. Provide pressure overload protect
7. Pulse and frequency of the injector can be adjusted.
8. Injection time can be set.
9. Protection function of short-circuit.
10. Precise measurement, easy operation, low noise.
11.Frequency converter inside to keep the RPM.
>>>FUNCTION1.Test injector brands:BOSCH, SIEMENS, DELPHI, DENSO.
Piezo injector testing(option function)
2. Test 1 piece of injector.
3. Test the Leakage performance of common rail injector.
4. injection oil quantity and back oil quantity(pre-injection, Idling, emissions, full load)
5. Electronic fuel delivery measuring, automatic testing and detection.
6. Data can be searched and saved.
| TECHNICAL PARAMETER |
| 1. output power: 1.5KW |
| 2. power voltage: 220V 1phase |
| 3. motor speed: 0-3000RPM |
| 4. Oil pressure: 0-2000bar |
| 5. flow measure range: 0-600ml/1000times |
| 6. flow measurement accuracy: 0.1ml |
| 7. temperature control range: 40+-2 |
China Lutong Parts Plant is a manufacturer specialist in diesel engine parts. The majored products are Head Rotor (VE Pump Parts) Nozzle, Plunger, Delivery Valve and so on. As an elder manufacturer for diesel engine parts, VE pump parts, we keep step with the international standard and techniques. And we absorb the advanced producing and testing technique. The quality of our products is in the same class with other overseas famous manufacturers.
China Lutong is a manufacturer specialist in diesel injection parts for about 25years. We adjust our step, in draught the advanced producing techniques and high precision equipment to improve our quality with the opportunity and challenge brought by WTO. The quality of us is in the advance in Auto Parts field.
Our majored products is VE Pump and the interrelated products (such as Head Rotor, Feed Pump, Cam Plate, Drive Shaft, Magnet Valve, etc. ), Plunger (A, AS, P, PS7100, P8500, MW type, etc. ), Nozzle (DN, DNOPDN, S, SN, PN and so on. ), Delivery Valve, Cat Pencil Nozzle, Head Rotor Lucas...
If you have any interested in our products or have any inquiry, Please don't hesitate to contact us. We will do our best to offer you our high quality products and best service to satisfy you.
