Ce Excellent Paint Booth Spray Booth Autobody Painting for Europe
| Price: |
US $ 3000-9800/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Money Gram |
| Prod Model: |
captain-12-45 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Outside Size:(Mm): |
12144X6396X4600mm(Lxwxh) |
| Inside Size:(Mm): |
12000X4500X4000mm(Lxwxh) |
| Front Door:(Mm): |
1unit, 3800X3900 Mm(Wxh) |
| Emergency Door:(Mm): |
1-Fold, 650X1800mm(W×h), |
| Wall Panel: |
75mm EPS, 0.5mm Steel Thickness |
| Ventilation System: |
Intake Fan:4X5.5kw, Exhaust Fan: 2X7.5kw |
| Heating System: |
Italian Riello Rg5s (260000 Kcal/H)Diesel )2 Sets |
| Filter System: |
Pre Filter, High Efficiency Filter (Ceiling Filter |
| Lighting System: |
Ceiling: 16X3X36W, Side:18X2X36W |
| Total Power: |
44 Kw |
| Certification: |
SGS |
| Airflow Direction: |
Fully Undershot-type |
| Heating Mode: |
Diesel |
| Paint Mist Treatment: |
Dry-type |
| Condition: |
New |
| Type: |
Spray Painting |
| Substrate: |
Sandwich Panel |
| Brand: |
Captain |
Product Description
Detailed Product Description 12M Heat Spraying, Baking Industrial Spray Booths
1. CE approved
2. German Technology
3. Spray booth professional manufacturer
4. Factory price, energy saving
5. High quality, best sell service, timely delivery
6. We can meet at customer's special requirement
| Items | Spec |
| Sketch | |
| Outside size:(mm) | 12144×6396×4600mm(LXWXH) |
| Inside size:(mm) | 12000×4500×4000mm(LXWXH) |
| Front door:(mm) | 1Unit, 3800×3900 mm(WxH) galvanized steel cover frame, with polystyrene(EPS) inside . |
| Emergency door:(mm) | 1-fold, 650×1800mm(W×H),There is two sets of pressure lock which will automatically open when the pressure inside is over the limit . |
| Cabin system | Wall panel :Double construction with insulations EPS , thickness 75mm,0.5mm steel thickness, width:950mm, tongue and groove interlock structure, with Polystyrene(EPS) insulation inside .
Basement and floor : Need to build the base construction , 2 rows of pits in the ground for exhaust air, dimension of each pit is10350×760mm((LxW),with galvanized grids made by twisted steel and flat bar above . |
| Ventilation system | Intake fan:4×5.5KW double-intake centrifugal fans for intake air, model YDW4.5S, total air capacity 65000m3/h
Exhaust fan: 2×7.5KW double-intake centrifugal fans for exhaust air, with motor outside, belt-drive, model TAE-560H, total air capacity 50000m3 |
| Heating system | Italian RIELLO RG5S (260000 kcal/h)Diesel )2 sets,heating-up time: 6~8 min. |
| Filter system | Pre filter, high efficiency filter (ceiling filter),floor filter, exhaust active carbon filter. |
| Lighting System | Ceiling light: 16Units, each 3×36 W, with electronic ballasts,
Side light:18Units, each 2×36W, with electronic ballasts, |
| Control system | Spraying, risen-temperature spraying, baking temperature, time setting,
lighting switch, emergency stop, failure indicator, limited-temperature device . |
| Total power | 44 KW |
| Container needed | 40 Feet container . |
| UNIT PRICE (FOB QINGDAO) | $ |
Qingdao Hua Yushun Commercial Co., Ltd belongs to Captain Auto Equipment Group, which is responsible for exporting for all the products of Captain Group. And Captain is a professional designer and manufacturer of mechanical equipment, which is developed from SK spray booth built in 1992. Captain developed day by day, and established Shandong painting production base and sandwich panel production base. Now it can produce painting equipments more than 3000 sets, about 2, 000, 000 square meters different kinds of sandwich panels, and various kinds of steel ducting 800, 000 meters one year. Also Captain established Zhucheng sandblasting production base in 2002, and injection pieces production base in 2005. And in 2006, Captain established Qingdao Commercial Center, which is operated by Qingdao Hua Yushun Commercial Co., Ltd who is responsible for all the global importing and exporting business. Formed a good industry pattern that is the sells presses to production, and production streghten sales.
· Now the products of Captain group refer to auto repair quipments, furniture spray booth, preparation bay, shot blasting machine, antiseptic treatment production line, injection pieces, all kinds of EPS panel, rock wool panel, glass fiber panel and decorative panel outside, commercial kitchen equipment, etc.
· After all these years, high-quality products and good service won wide reputation for our group from our buyers, and our products are exported to Germany, the United States, Sweden, the Netherlands, Denmark, Romania, South Africa, Australia, Canada, Italy, New Zealand, Nigeria, Zambia, Thailand, Chile and other countries and regions.
Face to the ever-changing market, Captain looks providing more secure, reliable, energy conservation and environmental protection products as it's responsibility, listens to the buyer's comments carefully, improve the quality of products and service, Continue to increase the research and development ability of enterprise innovation and equipment; We will paste with the future, and slipped through the waves.
