Bus and Truck Paint Booth Wld12000

Name: Bus and Truck Paint Booth Wld12000
Brand: ibuyautoparts.com
SKU: 706470405
Availability: InStock
Rating: 4.5 (57 reviews)

Price:	US $ 23600-27600/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	WLD-12000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	Wld-12000
External Size:	1215066005600mm
Internal Size:	1200050004800mm
Air Flow:	31000m3/H*2
Air Speed:	0.3-0.5m/S
Power:	41kw
Vehicle Suited:	Truck & Bus
Certification:	CE
Airflow Direction:	Fully Undershot-type
Heating Mode:	Diesel
Paint Mist Treatment:	Dry-type
Condition:	New
Substrate:	EPS
Brand:	Weilongda

Product Description

1. CE, ISO, AS certificate in bus spray booth
2. Real spray booth manufactory
3. Our factory cover over 15000 m³
4. Over 12 years experience in spray booth

Main features:

Model	WLD12000
External Size	12150×6600×5600mm
Internal Size	12000×5000×4800mm
Air Flow	31000m³/h
Air Speed	0.3-0.5m/s
Power	41KW
Vehicle Suited	Truck and Bus

1. Wallboard: Sandwich style EPS (epispastics polystyrene) 75mm thickness. Colorful steel skin boards 0.476mm thickness. Galvanized steel roof panel.

2. Door: 4 PCS of front doors with special rigid frame. Size: 4000(w) x 4800(h). 2 PCS of emergency doors.

3. Air Intake System (3sets): Each set consists of 2x4kw intake fan. Total 6 units of 4kw intake fan. BELIMO 20N electric damper.

4. Air Exhaust System (3sets): Each set consists of 1x5.5kw exhaust fan. Total 3 units of 5.5kw exhaust fan. Multi-layer fiberglass filter. Exhaust air from basement or two sides of wallboard.

5. Heating System (3sets): Each set consists of 1 unit Italy Riello G20 diesel burner, 200000Kcal/h. Total 3 units of burners, 600000Kcal/h. The heat exchanger is made of 1.5mm thickness stainless steel which features more heat dissipating surface, better heat exchange and better burner efficiency.

6. Lighting System: Ceiling light has 16 units x 4 PCS of 36W lamps. Side light has 22 units x 2 PCS of 36W lamps. Total 108 PCS of 36W lamps. 900 Lux.

7. Air Purification: Dual filtering structure. The primary filter can capture granules larger than 10μ M. Ceiling filter capture granules bigger than 5μ M. The air cleanliness in the working environment can reaches 98%.

Guangzhou Weilongda Electromechanical Equipment Co., Ltd., which established in 2000, is one of the first and largest automobile care and maintenance equipments manufacturers and suppliers in China. It manufactures spray booths, preparation stations, auto lifts and supplies body repair systems, car wash machine, wheel alignments, tire changers, wheel balancers and other relevant garage equipment to the clients all over the world.

Quality First, Service Highest is the policy carried by all Weilongda members. Quality and safety control system is applied throughout the whole produce procedures, from design and the raw material purchasing to parts fabrication, from welding to painting, from the product's factory assembling to packing and loading. All the products are produced strictly according to ISO9001: 2008 systems and CE standards.

After years of investment and management, WEILONGDA is a famous brand now. It enjoys high reputations among domestic customers as well as clients from England, Ireland, Poland, Sweden, Russia, Nigeria, Ghana, South Africa, America, Australia, Japan and other Asian countries.

Please feel free to contact members of Weilongda and start a happy and win-win cooperation.

With your join, the future is better.
