1.Automobile air conditioner used for long-distance coaches and tourist buses
2 Small dimension
3 Low cost
4 Size: 4600*1826*230mm
Cooling Capacity:34-38kw
We Hebei Chang En Trading Co.Ltd are speciailized in bus parts and assy, we have been in this market for many years and we can offer you the better quality and better price bus parts like the Chang An, Yutong, Kinglong, Higer and so on.
By the way , we are the professional Chang An Bus parts exporter.
1. The adventage of the SZD series:
(a) The roof-mounted unit owns a streamline outline, taking on a nicer and more handsome apperance.
(b)The heat-exchanger adopts tube-fin type heat exchanger of 7mm insind screw thread copper tube, therefore making high energy efficiency ratio and low oil comsumption.
(c) Dighital-displayed automatic temperature control.
(d) Good servicing inerchangeablity and accessibility.
2.. The type BBP-V-Dis for the city buses which the length is between 11.5~12.5meters.
3.. The detail attribute of the BBP-V-D auto bus air conditioning.
No |
Description |
Brand |
Feature |
1 |
compressor |
BITZER |
Famous brand, Beijing Bitzer, high reliability |
2 |
Evaporator blower |
SONGZ |
Imported axletree,high efficiency,long life time with 6000 hours |
3 |
Condenser fan |
SONGZ |
Imported axletree,high efficiency,low noise,long life time with 6000 hours |
4 |
Expansion valve |
DANFOSS |
First-class brand, high reliability |
5 |
Dryer |
SONGZ |
Completely radial sealing,complete radial direction seal |
6 |
Pressure security device |
SONGZ |
Protecting the elements and components from being damaged by abnormal pressure,high precision |
7 |
Plug-in connector |
AMP |
Wholly silver coated, corrosion-resistant to acid, alkali and salt, water and dust proof. |
8 |
Heat exchanger |
SONGZ |
φ7 inside screw-thread copper tube |
9 |
Manipulator |
SONGZ |
Digital-displayed temperature type, trouble direction |
10 |
Pipeline |
SONGZ |
Copper and complete stainless steel bellows |
11 |
Shell |
SONGZ |
High-strength stainless aluminum LF21 bottom and high strength fiber glass cover. |
12 |
Belt(optional) |
GATES/DONGIL |
The aluminum alloy botton shell raises the intensity glass fiberreionforced plastic lid. |
13 |
Compressor bracket(optional) |
SONGZ |
Limiting 5 degree of freedom with vibration absorbing design to reduce the vibration of generator and dramatically lengthen the life. |
14 |
Air-returning grill(optional e) |
SONGZ |
Large air-returning area design structure, press forming by mold, attractive and handsome appearance, with high efficiency filter net |
15 |
Fresh air system(optional) |
SONGZ |
Driven by the y imported motor |
16 |
Generator |
PRESTOLITE |
Manufactured by Sino-America joint venture PRESTOLITE Co. ,stable and reliable performance |
17 |
Refrigerant(optional) |
R134a |
Hebei Chang En Trading Co., Ltd. is a professional supplier of auto parts for bus, coaches, passenger bus parts and other vehicles parts.
We strive to develop and innovate according to the demand of domestic and overseas market and based on high tech industries. Till now our business has been involved in machineries, industrial materials, etc. We pursue the excellence of production, processing, sales and aftersales service so that our company is bigger and stronger and get good reputation from the customers. Our products are exported to many countries and areas such as Russia, Middle East, Ethiopia, South Africa, India, Pakistan, South America etc.
Meanwhile, our company actively expand the one stop agency service by virtue of foreign trade experience and position and act as agent for custom, inspection, international freight, international economic and trade consulting, international business cooperation as well as general trade special products agency service.
Mainly manufacturing products: Brake shoes, radiator, filters, wiper blade, clutch, light, medium and heavy commercial vehicle auto parts wholesaling and retailing. Operation brands including: CHANG AN, HIGER, YUTONG, KINGLONG, ZHONG TONG, JAC, DONGFENG, FOTON, JMC, FAW, YUEJIN, HAFEI, CAMC series.
" Outstanding idea, excellent team, high quality service". We sincerely hope: You and me work together for better future!
