Brake Lathe (C9350C)

Name: Brake Lathe (C9350C)
Brand: ibuyautoparts.com
SKU: 773441125
Availability: InStock
Rating: 4.6 (44 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	C9350C
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Spindle Travel:	6.875" (175mm)
Rotor Diameter:	7"-15" (180mm-381mm)
Drum Diameter:	6"-28" (152-711mm)

Product Description

Feature
-The lathe uses precision electric DC servo motors designed to meet the demanding requirement of industrial motion control.
-The precision twin cutter tools and a quick drum to rotor changeover to help increase your service capability.
-Infinitely variable spindle and cross feed speed settings allow for quick rough and precision finish cuts.
-A convenient top storage tray means you can easy to take your favorite adapters and tools.
-Separate motors on the drum and rotor feed help maximize the main motor's efficiency.
-The variety of adapters lets you machine all standard and composite rotors for foreign and domestic cars and light trucks.
-Positive rake cutter tip angle provides for a one pass finish virtually every time, allowing you to complete your work fast.

Parameters
Model	C9350C
Spindle Travel	6.875" (175mm)
Rotor diameter	7"-15" (180mm-381mm)
Drum diameter	6"-28" (152-711mm)
Motor	110V/220V/380V.50/60Hz
Spindle speed	70,88,118 rpm
Rotor thickness	1.875" (48mm)
Drum depth	6.875" (175mm)
Shipping weight	290 kg
Dimension (L×W×H)	970mm×920mm×

ACE MACHINE TOOLS Co., Ltd, is a specialized exporter and manufacturer of machine tools and accessories with a long history.

Our mechanical products cover more than 80 kinds including lathe, milling machine, drilling machine, grinding machine, power press, hydraulic guillotine, hydraulic press brake, CNC & automotive machines and so on.

Our customers are widespread in more than 30 countries including U. S. A., Germany, Spain, France, England, Greece, Finland, Norway, Canada, south America, Middle East, Australia, Africa and southeast Asia etc.

Our principle to all the customers is high quality and good service. We have quality control team who will carefully inspect every machine in workshop before packing.

Welcome you to visit our website and contact us. We will give you quick response upon any of your need.
