Bosch Laboratory Instrument Diesel Fuel Injector Pump Test Bench

Name: Bosch Laboratory Instrument Diesel Fuel Injector Pump Test Bench
Brand: ibuyautoparts.com
SKU: 718158542
Availability: InStock
Rating: 4.4 (79 reviews)

Price:	US $ 7000-7500/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

BOSCH Laboratory Instrument Diesel Fuel Injector Pump Test Bench

Advantages
1. Large inertia flywheel.
2. Automatic oil unloading device.
3. Automatic flap oil collect device.
4. High precision test of rack travel.
5. Optional installation with lubrication oil system.
6. Automatically and manually double control system.
7. Optional installation with temperature control system.

Functions
. Test feeding pump.
. Test the return volume of distributor pump.
. Test the solenoid valve of distributor pump.
. Test the cavity pressure of distributor pump.
. Test theperformance of pressure compensator.
. Test the sealing performance of the injection pump.
. Test the oil supply amount and uniformity in each cylinder.
. Test the performance of air film mechanical speed governor.
. Test and adjust the performance of mechanical speed governor.
. Test the interval angle in each cylinder and commencement of oil supply under the static state.

Technical parameter

Motor power	5.5,7.5,11,15,18.5,22,30kw
Power supply voltage	415,380,220v
Power supply frequency	50/60 HZ
Protection level	IP54
Speed range	0-4000 rpm
Counter setting range	0-9999
Temperature setting range	0-80°C
Center height of driving shaft	125mm
DC power	12/24V
Diameter of the Driving connector	120mm
Measuring tube	45ml,150ml,260ml(optional)
Number of Measuring cylinder	6,8,12
Fuel Supply pump	10L/min
Fuel supply pressure	High pressure:0-40bar;low perssure:0-4bar
Fuel tank cubage	60L
Pressure meter	Low pressure:0-6bar;high pressure:0-60bar;inner pressure:0-16bar;Vacuum pressure:-1-2.5bar;Oil meter:0-10bar
Heat Power	2kw
Temperature controlled range	30-65ºC
Size	220011001750mm
Weight	1100kg

Prod Model:	EPS611
Test Function:	Diesel Fuel Injection Pump
Testing:	Pump Injection Measurance
Output Power:	7.5kw, 11kw, 15kw, 18.5kw
Voltage:	380V 220V 415V
Power Phase:	3-Phase
Equipment:	Bosch Laboratory Instrument Diesel Fuel Injector P
Certification:	ISO
Update Method:	by Hard Disk

Our company was established in 1978 as one of the oldest Chinese agricultural and construction equipment supplier in the overseas market and ISO9001 approved. Annual turn over is over 100 million US Dollars per year.

We supply 18HP-280HP tractor and tractor implements; construction equipment including LIUGONG wheel loader, XCMG wheel loader, truck crane, motor grader, skid steer loader, HC forklift, SD bulldozer, backhoe loader, reach stacker, etc. and its spare parts.

All products are not only well sold in China, but also to Southeast Asia, Middle East, Australia, Africa, Europe and America. In order to meet the requirement of international market, FOTMA will strive to upgrade our products and keep on innovation so as to provide perfect products and best service to the customers both from domestic and abroad.
