The IFT205 is used for testing nozzle-and-holder assemblies and nozzle holders of unit injectores, common rail injectors with a solenoid valve for passenger and commercial vehicles. With the IFT205 it is possible by way of an automatic test procedure to determin whether or not a tested component is still fit for use.
Technology Specifications:
1)Usage:
after sale common rail injector inspection repair and re manufacture
2)Test content :
BOSCH CP1,CP2,CP3,CB18,CB28;
DENSO HP0,HP3,HP4;
DELPHI DFP1.1/1.2;
CAT 320D;
Chongqing oil pump factory CB2B916A.
3)Main index:
Max. rail pressure: 180Mpa
Precision of rail pressure regulation: ±1Mpa
injection volume of test precision:±0.5%;
Return oil volume of test precision:±2.5%;
Volume:L*W*H=550*500*1370;
Weight: 90Kg.
4) Characteristic:
Imported flowmeter
Can test common rail pump from BOSCH,DENSO, DELPHI, CAT, CUMMINGS, ,customer can also choose customized composition.
Using the power system of original mechanical pump test bench, saving costs; With the oil tank and pipeline, no need to transform the original test bench.
PFT105 is a precise test bench for after sale high pressure common rail pump which can test almost all the common rail pump in current market like BOSCH,DENSO, DELPHI, CAT, CUMMINS...
Unique graft design, use the power system of the original mechanical pump test bench with the tank and pipeline, no need to transform the original test bench. Easy to operate, safe and reliable. Accurate measurement of starting, return oil, maximum oil volume, zero oil supply, idle and other oil points.
Full industrial touch screen, select the common rail pump model, and then start to work automatically, can also choose the manual test, the operation is extremely simple, the design is humanizing.
It can help anyone in just a few minutes to get used to the operation of PFT105.
PFT105 control software has been containing more than 900 kinds of common rail injector test data like BOSCH, Delphi, Denso, Carter320D and Cummings. Covering AT3 AT4 common rail pump in the market , with the test conditions of AT5, the maximum pressure up to 1800 kg, software and database upgrade regularly, remote download, convenient and quickly.
Accurate=Effective | 1% system test accuracy | Stably control rail pressure error value within ±1Mp , the Max. rail pressure up to 1800bar |
Precision test oil control system within ±2ºC |
Imported precision gear flowmeter + unique precision control of flow dividing |
Stable=Trustable | 8 years focus on common rail test | 7 inch industrial touch screen, embedded operating system to adapt to a variety of harsh maintenance environment. |
Domestic and foreign first-line brand components, all the new parts |
Expert R & D team, high standard production quality control |
Reliable=Save money | No fault is low price | Reasonable structure, modular design |
1 years of free warranty, life-long maintenance, no worries |
24 hours fast response, if necessary, 72 hours up to the scene |
Easy-to-use=Practical | Easy to maintain , easy to control, high efficiency | More than 600 kinds of fuel injector data + custom function, BOSCH,DENSO, DELPHI, CAT, CUMMINS...... |
5μm filter accuracy, convenient maintenance |
The original mechanical pump equipment only provide speed drive, all lines do not need any transformation, plug and easy to operate. |
Services provided from Wabtec for customer
1)The latest version of the control software and drivers
2)Equipment instructions and all kinds of injector maintenance manual
3)One year free warranty, efficient after-sales service.
4)Provide professional training in factory.
WABT is committed to provide advanced technical solutions for electronic fuel injection and after treatment system.
WABT has two main business scopes:
1. Intelligent Equipment: Proffessional testing bench and manufacturing equipment for diesel common rail fuel injection system and after-treatment system.
2. Engineering service: Engine&Vehicle consulting and calibration service, precise maintenance intergration solution for after-sales.
WABT is recognized ad a leading enterprise in this area of China.
WABT firmly believe: Accurate testing → Lean production→ Precise matching → Efficient maintenance is a key chain needed for fuel injection manufacturers, engine and vehicle manufacturers, maintenance service station, car owners and even the energy saving and environment-friendly society.
