Automatic Downfeed CNC Touch Screen Milling Machine (MG-1000)

Name: Automatic Downfeed CNC Touch Screen Milling Machine (MG-1000)
Brand: ibuyautoparts.com
SKU: 773377635
Availability: InStock
Rating: 4.6 (98 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Features

1. This machine is control by CNC touch screen. The operation contact surface, Simple and easy to get started. It can do automatic feed, automatic retraction after complete all program, also have memory processing trajectory.

2. Main spindle speed and feeding rate is stepless speed change. Suitable for different kinds of processing materials. Total piece of eight cutter folder, you can choose freely to improve processing efficiency.

3. The main spindle use NSK P4 level tapered roller bearing and cylindrical roller bearing to ensure that the spindle has good accuracy and rigidity.

4. Spindle sleeve is chrome plated and ground, with a shining and rust-proof surface, and improve the full rigidity of spindle.

5. Transmission parts: Taiwan ABBA Ball screw Accuracy class C7

6. Main spindle is derived by servo motor, to ensure a constant output torque at various speeds, so that the processing is more stable, efficient cutting, the work piece surface much more finish better.

7. This machine use head move structure, Has a small footprint, can be processed large volume of work piece, while the low table position, is conducive to the work piece clamping, etc.

8. High flatness, best bright finish, the milling that replaces normal grinding, and without the cooling box. Operation is faster, more convenient, work environment is more clean.

Parameters
Model	MG-1000
Control System	EasyTouch 3 Axis
Spindle Speed	200 - 1400 rpm stepless
Milling Plate Motor	4 kW
Milling Plate Traverse Motor	0.75 Kw
Downfeed Motor	0.4 kW
Max. Milling Length	1000 mm
Max. Milling Width	300 mm
Max. Milling Height of Work Piece	650 mm
Working Table Surface ( L×D )	1000×400 mm
Milling Plate Dia.	300 mm
Number of Milling Insert	8 piece
Vertical Movement of Milling Plate	150 mm
Milling Plate Traverse Speeds , Stepless	200 ~ 1800 mm / min
Length of Machine	2010 mm
Width of Machine	810 mm
Max. Height of Machine	1850 mm
Min. Height of Machine	1980 mm
Flatness for Grinding	0.01 mm / 300 mm
Surface Roughness for Grinding	Ra. 0.63
Package Size ( L×D×H )	2250×1100×2200 mm
N.W.	1500 Kg
G.W.	1800 Kg

Prod Model:	MG-1000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Control System:	Control System
Spindle Speed:	200 ~1400 Rpm Stepless
Max. Milling Length:	1000 mm
