Anti-Static Solid Forklift Tire 11.00-20, Heavy Duty Forklift Tire
Price: |
US $ 360-388/Piece |
Trade Terms: |
FOB,CFR,CIF |
Min Order: |
2/Piece |
Pay Type: |
L/C,T/T,Western Union,Paypal |
Prod Model: |
11.00-20 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Size: |
11.00-20 |
Rim: |
7.50 8.00 |
Section Width: |
277mm |
Overall Diameter: |
1049mm |
Weight: |
195kg |
MOQ: |
2PCS |
Type: |
Solid Tire |
Diameter: |
≥22" |
Certification: |
ISO |
Product Description
anti-static solid forklift tire 11.00-20,heavy duty forklift tire
Product Description:
- B102 series solid tires, models are 15×4.5-8 / 5.00-8 / 16×6-8 / 18×7-8 / 6.00-9 / 7.00-9 / 21×8-9 / 6.50-10 / 23×8-9
- solid tire is no need inflation,no hidden dangers and low maintenance cost,loading capacity higher than ordinary tires,suitable for low speed vehicles like forklift,engineering trucks,etc.
- tread pattern designed to perform in different climate and work place.
- three layers structure helps reducing heat build-up so that makes tire life longer and increasing driving comfort!
Features:
good ground grasping capacity,large loading capacity,suitable for general forklift, low speed vehicles in port
Specifications:
model | standard rim | tire size(mm) |
loading capacity
|
overall diameter | section width | tread surface width | balance forklift | other vehicles |
10km/h | 16km/h | 25km/h | 6km/h | 10km/h | 25km/h |
drive | steer | drive | steer | drive | steer |
15×4.5-8 | 3.00 | 370 | 115 | 107 | 1005 | 775 | 915 | 705 | 850 | 665 | 850 | 775 | 655 |
5.00-8 | 3.0/3.5 | 454 | 122 | 108 | 1255 | 965 | 1145 | 880 | 1060 | 815 | 1060 | 960 | 815 |
16×6-8 | 4.33 | 400 | 147 | 137 | 1545 | 1190 | 1410 | 1085 | 1305 | 1005 | 1305 | 1185 | 1005 |
18×7-8 | 4.33 | 450 | 166 | 150 | 2430 | 1870 | 2215 | 1705 | 2060 | 1585 | 2060 | 1870 | 1585 |
6.00-9 | 4.00 | 525 | 148 | 130 | 1975 | 1520 | 1805 | 1390 | 1675 | 1290 | 1675 | 1520 | 1290 |
7.00-9 | 5.00 | 552 | 162 | 146 | 2670 | 2055 | 2440 | 1875 | 2260 | 1740 | 2260 | 2055 | 1740 |
21×8-9 | 6.00 | 510 | 190 | 170 | 2890 | 2225 | 2645 | 2035 | 2455 | 1890 | 2455 | 2230 | 1890 |
6.50-10 | 5.00 | 573 | 156 | 150 | 2715 | 2090 | 2485 | 1910 | 2310 | 1775 | 2310 | 2095 | 1775 |
23×9-10 | 6.50 | 572 | 198 | 182 | 3730 | 2870 | 3405 | 2620 | 3160 | 2430 | 3160 | 2865 | 2430 |
200/50-10 | 6.50 | 456 | 195 | 168 | 2910 | 2240 | 2665 | 2050 | 2470 | 1900 | 2470 | 2240 | 1900 |
7.00-12 | 5.00 | 653 | 176 | 162 | 3105 | 2390 | 2835 | 2180 | 2635 | 2025 | 2635 | 2390 | 2025 |
27×10-12 | 8.00 | 650 | 240 | 224 | 4595 | 3535 | 4200 | 3230 | 3900 | 3000 | 3900 | 3540 | 3000 |
7.00-15 | 5.50 | 725 | 184 | 163 | 3700 | 2845 | 3375 | 2595 | 3135 | 2410 | 3135 | 2845 | 2410 |
7.50-15 | 6.50 | 777 | 201 | 180 | 4490 | 3455 | 4100 | 3155 | 3810 | 2930 | 3810 | 3455 | 2930 |
28×9-15 | 7.00 | 700 | 227 | 200 | 4060 | 3125 | 3710 | 2855 | 3445 | 2650 | 3445 | 3125 | 2650 |
8.25-15 | 6.50 | 800 | 210 | 205 | 4305 | 3310 | 3925 | 3020 | 3540 | 2800 | 3640 | 3305 | 2800 |
250-15 | 7.0/7.5 | 705 | 230 | 212 | 5220 | 4015 | 4770 | 3670 | 4425 | 3405 | 4425 | 4015 | 3405 |
300-15 | 8.00 | 810 | 260 | 236 | 6895 | 5305 | 6300 | 4845 | 5850 | 4500 | 5850 | 5310 | 4500 |
7.50-16 | 5.50 | 777 | 201 | 180 | 4035 | 3105 | 3685 | 2835 | 3425 | 2635 | 3425 | 3110 | 2635 |
9.00-16 | 6.50 | 840 | 220 | 208 | 4480 | 3445 | 4090 | 3145 | 3795 | 2920 | 3795 | 3445 | 2920 |
8.25-20 | 6.50 | 950 | 222 | 200 | 5335 | 4445 | 4870 | 4060 | 4525 | 3770 | 4900 | 4110 | 3770 |
9.00-20 | 7.00 | 1000 | 239 | 218 | 6365 | 5305 | 5815 | 4845 | 5400 | 4500 | 5850 | 4905 | 4500 |
10.00-20 | 8.00 | 1030 | 258 | 238 | 7300 | 6085 | 6670 | 5560 | 6200 | 5165 | 6715 | 5630 | 5165 |
11.00-20 | 8.00 | 1060 | 274 | 253 | 7715 | 6430 | 7045 | 5870 | 6540 | 5450 | 7085 | 5940 | 5450 |
12.00-20 | 8.50 | 1098 | 304 | 275 | 9190 | 7660 | 8390 | 6990 | 7795 | 6495 | 8445 | 7080 | 6495 |
