| Prod Model: |
W12x28 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Agricultural Tractor |
| Fitted Tyre: |
13.6-28/14.9-28 |
| Material: |
Steel |
| Type: |
Rim |
| Wheel Accessories: |
Wheel Cover |
| Certification: |
DOT |
| Wheel Hub Diameter: |
28'' |
| Finishing: |
Painted |
Product Description
Product detail:
1. Steel wheels within diameters from 12" up to 54", and width from 4.25" up to 36"
2. Wheels for speeds up to 65km/h
3. The high quality of manufactured wheel is comply to TRA, TROTA standard
4. Wheel rims for tractors, trailers, harvesters etc applications
Wheel sizes
| Dia | Wheel Size | Tire Size | Dia | Wheel Size | Tire Size |
| 12'' | 5J*12 | 7.00*12 6.00-12 | 26" | W12*26 | 13.6-26 14.9-26 |
| 7.00*12 | 10.0/75-12 10.0/8-12 23/8.50*12 | W13*26 | 14.9-26 |
| 8.50*12 | 11.0/65-12 23/9.50*12 | W15*26 | 16.9-26 |
| 10.50*12 | 26*12.0-12 | W16*26 | 18.4-26 |
| 13'' | 4J*13 | 5.50-13 165RS13 | DW20*26 | 23.1-26 24L-26 |
| 4.5J*13 | 5.50-13 | DW25*26 | 30.5L-26 28L-26 |
| 14'' | 4.5J*14 | 6.5-14 | 26.5" | 16.00*26.5 | 500/60-26.5 |
| 6.00*14 | 9.5L*14 | 20.00*26.5 | 600/55-26.5 |
| 7.00*14 | 9.5L*14 | 24.00*26.5 | 700/50-26.5 |
| 15" | 4J*15 | 5.00-15 | 28.00*26.5 | 800/45-26.5 |
| 5J*15 | 6.5/80-15 | 28" | W8*28 | 9.50-28 |
| 6LB*15 | 7.5L-15 | W10*28 | 11.2-28 |
| 7J*15 | 8.0/75-15 | W11*28 | 12.4-28 |
| 8LB*15 | 27*10.5-15 11L-15 | W12*28 | 13.6-28 |
| 9LB*15 | 11L-15 | W13*28 | 14.9-28 |
| 10LB*15 | 12.5L-15 29*12.5-5 31*15.5-15 | W14L*28 | 16.9-28 |
| 13LB*15 | 33*15.5-15 31*15.5-15 | DW15L*28 | 16.9-28 |
| 15.3" | 15.3*9.00 | 10.0/75-15.3 11.5/80-15.3 12.5/80-5.3 | W16*28 | 18.4-28 |
| 15.5" | 15.5*13.00 | 400/60-15.5 | DW18*28 | 21L-28 |
| 16" | 4.5E*16 | 6.00-16,6.50-16 | DW20*28 | 600/50-28 |
| 5.50E*16 | 7.50-16 | 30" | W12*30 | 13.6-30 |
| 6.50*16 | 8.25-16 | W14L*30 | 16.6-30 |
| W7*16 | 210/85R16 | DW14*30 | 16.9-30 |
| W8*16 | 10.0/75-16 19.0/65-16 10.00-16 | W15L*30 | 18.4-30 |
| W9*16 | 285/70R16 11.00-16 | DW16L*30 | 18.4-30 23.1*30 |
| 9.00*16 | 11L-16 | DW20*30 | 23.1*30 |
| 11.00*16 | 14.0/65-16 | 30.5" | 20.00*30.5 | 600/50-30.5 800/60-30.5 |
| 16.1" | 11.0*16.1 | 14L-16.1 | 24.00*30.5 | 650/80-30.5 700/50-30.5 750/60-30.5 |
| 14.00*16.1 | 16.5-16.1 | 28.00*30.5 | 800/45-30.5 800/55-30.5 |
| 850/50-30.5 |
| 16.00*16.1 | 21.5-16.1 | 32" | W7*32 | 8.30-32 |
| 16.5" | 8.25*16.5 | 10-16.5 | W10*32 | 12.4-32 |
| 9.75*16.5 | 12-16.5 | W12*32 | 13.6-32 |
| 12.00*16.5 | 33/15.5-16.5 | DW20*32 | 23.1-32 |
| 17" | 17*13.00 | 15.0/55-17 | DW21*32 | 24.5R32 680/70R32 680/75R32 |
| 17*16.00 | 19.0/45-17 500/50-17 | DW27*32 | 30.5L-32 800/65R32 |
| 17.5" | 10.75*17.5 | 14-17.5 | 34" | DW10*34 | 12.4-34 |
| 11.75*17.5 | 14-17.5 | W14L*34 | 16.9-34 |
| 18" | 9.00*18 | 10.5/80-18 12.5/80-18 | W15L*34 | 18.4-34 |
| W9*18 | 10.5/80-18 12.5/80-18 | DW15*34 | 16.9-34 |
| 11.00*18 | 13.00/65-18 | DW16*34 | 18.4-34 |
| 13.00*18 | 15.0/70-18 15.5/60-18 405/70-18 | DW20*34 | 23.1-34 |
| 19" | 3.00*19 | 4.50*19 | 36" | W8*36 | 9.50-36 |
| 19.5" | 14*19.5 | 15.0*19.5 | W10*36 | 11.2-36 |
| 20" | 5.50*20 | 7.50*20 | W11*36 | 14.9-36 |
| W7*20 | 8.3-20 | W12*36 | 14.9-36 |
| W8*20 | 9.50-20 | 38" | W10*38 | 11.5*38 |
| 20*8.00 | 9.5-20 10.00-20 | W11*38 | 13.6-38 14.9-38 |
| W9*20 | 11.2-20 | W12*38 | 13.6-38 14.9-38 |
| 10.00*20 | 12.00-20 | W15L*38 | 16.9-38 540/65*38 |
| W11*20 | 12.4*20 | W16*38 | 18.4-38 |
| 13.00*20.00 | 405/70-20 425/65R20 425/75R20 | DW16*38 | 18.4-38 |
| 14.00*20.00 | 38/18-20 | DW20*38 | 650/65-38 |
| 20.5" | 14*20.5 | 465/65R20.5 | DW23*38 | 710/70R38 |
| 21" | 18.00*21 3pcs | 24R21 | | W8*42 | 8.30-42 |
| 22.5" | 11.75*22.5 | 15R22.5 365/70R22.5 385/65R2.5 | 42" | W10*42 | 11.2-42 |
| 13.00*22.5 | 16.5R22.5 425/65-22.5 415/45R22.5 | DW16*42 | 18.4-42 |
| 14.00*22.5 | 18R22.5 465/65R22.5 | DW18*42 | 20.8-42 |
| 16.00*22.5 | 500/60-22.5 550/60-22.5 550/45-22.5 | W20*42 | 620/70*42 |
| 20.00*22.5 | 600/50-22.5 650/50-22.5 600/55-22.5 | DW23*42 | 710/70*42 |
| 24.00*22.5 | 700/50-22.5 | DW27*42 | 900/60*42 |
| 24" | W7*24 | 8.3-24 | 44" | W8*44 | 10.00*44 |
| W8*24 | 9.50-24 | W10*44 | 12.4*44 |
| W10*24 | 11.2-24 | 46" | DW10*46 | 11.2-46 |
| W12*24 | 13.6-24 14.9-24 | DW12*46 | 12.4-46 |
| W14L*24 | 16.9-24 | DW13*46 | 14.9-46 |
| DW15L*24 | 16.9-24 | DW16*46 | 18.4-46 520/85-46 |
| DW16L*24 | 19.5L-24 18.4-24 | 48" | W8*48 | 9.50-48 |
| DW18L*24 | 20.5-24 | W10*48 | 11.2-48 |
| 24.5" | 24.5*8.25 | 11R24.5 | W12*48 | 16.3-48 |
| 24.5*11.75 | 385/55R24.5 | 50" | W10*50 | 12.4-50 |
| 24.5*13.00 | 16.5R24.5 425/65R24.5 | W16*50 | 18.4-50 |
| 25" | 36.00*25 | 66/43-25 | 52" | W10*52 | 12.4-52 |
| Marks: We have daily stocks for the wheel size in Yellow |
With presence in over 70 countries across 6 continents, Qingdao J&G International Trading Co., Ltd has fastly grown up an One-stop professional supplier of a wide range of tires & wheels, and axles in China. We are to deliver superior value to our customers through focus on products, innovation, technology and cost efficient manufacturing and distribution practices.
The main component of Qingdao J&G's business is to supply the Mulitstar brand tires & wheels, and axles for the global "OEM" and aftermarkets, particularly for the farming applications, comerical vehicles, construction & earthmover equipments. Meanwhile, we are also supply a full specifications of steel wheels for mining, port handlings, Off-the-Road construction equipments. As well Alloy truck wheels are also available by us.
We have a well stocked warehouse in the Harbor of Qingdao now. A new bigger warehouse owned us is under construction, which is more than 2, 000 square meters. We can not only meet the demands of prompt shipment but also meet the demand of wheel assembly of tyres and rims for "OE" manufactures for the domestic and overseas markets.
Our extensive inventory of over 3000 units of complete wheel assemblies, and various range of tyres and rims, and also inner tubes and valves, clearly separaters them from our competition.
