4.3 Night Vision HD Car TFT-LED Monitor
Price: |
US $ 10.6-16/Piece |
Min Order: |
100/Piece |
Pay Type: |
T/T,Paypal |
4.3 night vision hd car TFT-LED Monitor 1.Product Features: 1) Original fitting by replacing the shelf of license light or Universal installation
2) Smart size for hidden installation.
3) 1/3"CCD
4) Lens: 170 degrees
5) Waterproof and dust-proof (IP68) CCD camera
6) With car reversing reference line(optional)CCD camera.
7) License light available on partial models.
8) Night vision available and high definition CCD camera.
9) Day /Night sensor for automatic adjustment, minimum illumination auto fill light.2.Technical Parameters
Image Sensor | 1/3color digital sensor |
Image Format | NTSC 50HZ/PAL 50HZ |
Effective Pixel | 656*492 |
Waterproof Index | IP67 |
Viewing Angle | 170degrees |
Mimimum Illumination | 0.1Lux |
Storage temperature | -40ºC-85ºC RH95% MAX |
Working Temperature | -30ºC-80ºCRH95% MAX |
Working Humidity | 0%-90% |
Resolution | 420 TV Lines |
Power supply | DC12V+10% |
Current consumption | No more 150mA |
S/N radio | More than 48dB |
Sync system | Internal |
Warranty | 12 months |
Scanning system | 2:1 interlace |
Horizontal sync frequency | 15625KHZ |
AGC | AUTO |
BLC | AUTO |
Video output | 1.0Vp-p, 75Ω |
3.Installation Guides: 1) Get out the license light;
2) Get the rear view lens lines across the license light original position;
3) Fasten the camera with the buckle which place in the two sides of the camera;
4) Connect the lens built-in license light power lines to the original license light power lines;
5) Connect the reverse lens switching lines;
6) Connect the camera's signal line to the signal extension line;
7) Connect the car's reverse light line to camera's video cable;
8) Check if all lines are correct connected and arranged;
9) Debug the working effects of the camera and the license light;
10) Cover the car trunk. Finished.4.complete set of equipment Accessories: 1) Mirror
2) Extention wire
3) A User Manual
4) Package box
Prod Model: |
WMR-659 |
Mimimum Illumination: |
0.1lux |
Working Temperature: |
-30ºC-80ºCrh95% Max |
Storage Temperature: |
-40ºC-85ºC Rh95% Max |
Working Humidity: |
0%-90% |
Power Supply: |
DC12V |
Current Consumption: |
150mA |
Warranty: |
12 Months |
Sizes: |
14.5mm 16.5mm 18.5mm |
Wire Selection: |
Universal Wire ; BMW Wire |
Accessories: |
Extention Wire; Screws; Shell;Package Box |
Mirror Type: |
Spherical Mirror |
Position: |
Inside |
Controlling Type: |
Electrical |
View Angle: |
120?? |
Mirror Material: |
Glass |
Pixel: |
130Million |
Certification: |
FCC |
Brand: |
Wemaer |
Size: |
4.3 |
Color: |
Black |
