3mx3mx3m Painting Oven Linking Booth
| Price: |
Negotiable/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
PC-CD-S |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Warranty Time: |
2 Years |
| Service Time: |
Lifelong Maintenance |
| Color: |
White, Blue, Orange, Red, Grey |
| Voltage Supply: |
380V/3p, 220V/3p Or220V/1p |
| Inner Size: |
3X3X3m and 5X3X3m |
| Wall Panel: |
EPS, Rock Wool or PU for Optional |
| Air Circulation System: |
3kw Centrifigual Fan |
| Illumination System: |
Philip and LED for Optional |
| Basement Surface: |
Twist Grill and Checkered Plate |
| Control System: |
PLC and Button Control for Optional |
| Certification: |
CE |
| Airflow Direction: |
Fully Undershot-type |
| Heating Mode: |
Diesel |
| Paint Mist Treatment: |
Dry-type |
| Condition: |
New |
| Type: |
Painting Oven Linking Booth |
| Brand: |
Paintcolor |
Product Description
Paintcolor Spray Booth Paint Booth(3mx3mx3m) linking Oven Booth(5mx3mx3m)Any booth size request can be met!!!Paintcolor company quantifies the production of standard spray booth; at the same time, "one-to-one" service is our important and special sale method and service. For different countries and the special requirements of different customers, we make the design and produce the booth based on the size of the site, the workpiece, the type of paint and the budget level. It really 100% stands on your point to solve all the problems. Paintcolor is the one specialty spray booth manufacturer you can not miss.
Total outside size: 8000×4550×3000mm(L×W×H)
Total inside size: 7900×2900×2500mm(L×W×H)
Paint booth:1) Outside dimension: 3000*3000*3000mm(L*W*H);2) Inside dimension: 2950*2900*2600mm(L*W*H);3) Basement: without, side air cycle;4) Front door: 2-fold( 2 leaf), 2000*2500mm(W*H);
Back door: 2-fold( 2 leaf), 2000*2500 mm (W*H);5) Wall Panels: thickness is 50 mm, and insulation is flame-resistant and heat-preserving EPS panel;0.426mm double skinned sheet;galvanized sheet roof plate;6) Lighting: Ceiling Lights: 2Groups*4Pcs=8Pcs *36W;Side Lights: 4Groupsx2Pcs=8Pcs x36W; Philip tube;7) Glass: all glass is toughened glass;8) Generator: side air cycle, quadrate steel frame, coated steel, the size is 1800*1106*350mm (L*W*H);9) Intake and exhaust air system: Intake fan: 1 centrifugal fan, YDW-4.5M, 3KW motor, capacity: 10000m3/h;Extract fan: 1 centrifugal fan, YDW-4.5M, 3KW motor, capacity: 10000m3/h;Air exhaust pipe: with 3m straight pipe and 1pcs elbow, with manual damper;The empty load air speed: 0.25m/s;10) Heating system: without;11) Filtering system: Pre-filter, high efficiency filter (ceiling filter), fiber glass filter, extract filter;12) Control box: manual button with paint, light switch, emergency stop, failure warning, timer etc;13) Total power: 7KW;14) The voltage require 380V,3P, 50Hz; Baking booth:1) Outside dimension: 5000*3000*3000mm(L*W*H);2) Inside dimension: 4950*2900*2600mm(L*W*H);3) Basement: without, side air cycle;4) Front door: Linking with paint booth, 2-fold( 2 leaf), 2000*2500 mm (W*H); Back door: 2-fold( 2 leaf), 2000*2500 mm (W*H), with pressure lock;5) Wall Panels: thickness is 50 mm, and insulation is flame-resistant and heat-preserving EPS panel;0.426mm double skinned sheet;galvanized sheet roof plate;6) Lighting: Ceiling Lights: 4Groups*4Pcs=16Pcs *36W;Philip tube;7) Glass: all glass is toughened glass;8) Generator: side air cycle, quadrate steel frame, coated steel, the size is 2200*1106*350mm (L*W*H);9) Intake and exhaust air system: Exhaust fan: 1 centrifugal fan, YDW-4.5M, 3KW motor, capacity: 10000m3/h;Air exhaust pipe: with 3m straight pipe and 1pcs elbow, with manual damper;The empty load air speed: 0.15m/s;10) Heating system: G20 diesel burner, with 180000kcal heating;11) Filtering system: Pre-filter, high efficiency filter (ceiling filter), fiber glass filter, extract filter;12) Control box: manual button with baking, light switch, emergency stop, failure warning, timer and temperature limited etc;13) Total power: 3.5KW;14) The voltage require:380V,3P, 50Hz;15) The highest working temperature: 80°;
