KOYO TIMKEN HRB 32208 bearing 32205 32206 32209 32210 32212 32215 32216 32218 32220 taper roller bearing
32205 bearing 32206 bearing 32208 bearing 32208 bearing 32209 bearing 32210 bearing
32211 bearing 32212 bearing 32213 bearing 32215 bearing 32216 bearing 32217 bearing
32218 bearing 32219 bearing 32220 bearing 32222 bearing 32224 bearing 32226 bearing
32228 bearing 32230 bearing 32232 bearing 32236 bearing 32238 bearing 32240 bearing
32303 bearing 32305 bearing 32307 bearing 32306 bearing 32308 bearing 32311 bearing
32309 bearing 32310 bearing 32313 bearing 32312 bearing 32314 bearing 32315 bearing
32316 bearing 32318 bearing 32317 bearing 32319 bearing 32320 bearing 32311 bearing
32322 bearing 32324 bearing 32326 bearing 32330 bearing 31304 bearing 31305 bearing
31306 bearing 31308 bearing 31310 bearing 31312 bearing 31315 bearing 31314 bearing
31316 bearing 31318 bearing 31319 bearing 31320 bearing 31324 bearing 31326 bearing
Suitable for high radial loads and thrust loads
Take up tilting moment
When in pairs, can take up thrust loads in both directions
Information about the taper roller bearing:
1. Type: Taper bearings N0: 30209 (sample available)
2. Market: All over the world
3. Material: Gcr15 Steel
4. Large stock of taper rollers bearings Stock order be ready in 3-4days
5. Feature: High speed, low voice, long life, high radial
6. Application: Automobiles, high-precision machine tool, high-frequency motor, centrifuge, gear spindle, agriculture, various axle systems, conveyance vehicles, gear box, engine motor ect.
7. We guarantee product Quality and Package are the same as your request.
8. Supply After sales and Professtional Technical consulting service!
boundary dimensions(mm) | basic load ratings(kn) | limiting speeds(rpm) | bearing no. |
d | d | t | r | r1 | cr | cor | grease lub. | oil lub. |
min. | min. |
45 | 75 | 20 | 1 | 1 | 62.8 | 86.5 | 5000 | 6600 | 32009 |
45 | 75 | 24 | 1 | 1 | 69.6 | 101 | 5000 | 6700 | 33009 |
45 | 80 | 26 | 1.5 | 1.5 | 87.5 | 120 | 4800 | 6400 | 33109 |
45 | 85 | 20.75 | 1.5 | 1.5 | 67.2 | 77.4 | 4600 | 6100 | 30209 |
45 | 85 | 24.75 | 1.5 | 1.5 | 84.2 | 104 | 4600 | 6100 | 32209 |
45 | 85 | 32 | 1.5 | 1.5 | 112 | 149 | 4600 | 6200 | 33209 |
45 | 100 | 27.25 | 2 | 1.5 | 113 | 128 | 4100 | 5400 | 30309 |
45 | 100 | 38.25 | 2 | 1.5 | 146 | 180 | 4100 | 5500 | 32309 |
50 | 80 | 20 | 1 | 1 | 65.7 | 94.5 | 4600 | 6100 | 32010 |
50 | 80 | 24 | 1 | 1 | 73 | 110 | 4600 | 6100 | 33010 |
50 | 85 | 26 | 1.5 | 1.5 | 89.4 | 127 | 4400 | 5900 | 33110 |
50 | 90 | 21.75 | 1.5 | 1.5 | 76.5 | 91.7 | 4300 | 5700 | 30210 |
50 | 90 | 24.75 | 1.5 | 1.5 | 85 | 105 | 4300 | 5700 | 32210 |
50 | 90 | 32 | 1.5 | 1.5 | 119 | 167 | 4300 | 5700 | 33210 |
50 | 110 | 29.25 | 2.5 | 2 | 137 | 152 | 3700 | 4900 | 30310 |
50 | 110 | 42.25 | 2.5 | 2 | 176 | 220 | 3700 | 5000 | 32310 |
| | | | | | | | | |
55 | 90 | 23 | 1.5 | 1.5 | 84.6 | 121 | 4100 | 5500 | 32011 |
55 | 90 | 27 | 1.5 | 1.5 | 96.5 | 145 | 4100 | 5400 | 33011 |
55 | 95 | 30 | 1.5 | 1.5 | 116 | 161 | 4000 | 5300 | 33111 |
55 | 100 | 22.75 | 2 | 1.5 | 94.6 | 113 | 3900 | 5200 | 30211 |
55 | 100 | 26.75 | 2 | 1.5 | 107 | 133 | 3900 | 5200 | 32211 |
55 | 100 | 35 | 2 | 1.5 | 142 | 189 | 3900 | 5200 | 33211 |
55 | 120 | 31.5 | 2.5 | 2 | 149 | 170 | 3300 | 4500 | 30311 |
55 | 120 | 45.5 | 2.5 | 2 | 200 | 250 | 3400 | 4500 | 32311 |
60 | 95 | 23 | 1.5 | 1.5 | 86.1 | 127 | 3900 | 5200 | 32012 |
60 | 95 | 27 | 1.5 | 1.5 | 101 | 162 | 3900 | 5200 | 33012 |
60 | 100 | 30 | 1.5 | 1.5 | 118 | 170 | 3700 | 5000 | 33112 |
60 | 110 | 23.75 | 2 | 1.5 | 106 | 127 | 3500 | 4700 | 30212 |
60 | 110 | 29.75 | 2 | 1.5 | 132 | 167 | 3500 | 4700 | 32212 |
60 | 110 | 38 | 2 | 1.5 | 174 | 239 | 3600 | 4700 | 33212 |
60 | 130 | 33.5 | 3 | 2.5 | 173 | 201 | 3100 | 4100 | 30312 |
60 | 130 | 48.5 | 3 | 2.5 | 244 | 315 | 3100 | 4200 | 32312 |
65 | 100 | 23 | 1.5 | 1.5 | 90 | 137 | 3600 | 4800 | 32013 |
65 | 100 | 27 | 1.5 | 1.5 | 103 | 169 | 3600 | 4800 | 33013 |
65 | 110 | 34 | 1.5 | 1.5 | 152 | 223 | 3400 | 4600 | 33113 |
65 | 120 | 24.75 | 2 | 1.5 | 128 | 156 | 3200 | 4300 | 30213 |
65 | 120 | 32.75 | 2 | 1.5 | 157 | 203 | 3200 | 4300 | 32213 |
65 | 120 | 41 | 2 | 1.5 | 200 | 277 | 3200 | 4300 | 33213 |
65 | 140 | 36 | 3 | 2.5 | 204 | 239 | 2800 | 3800 | 30313 |
70 | 110 | 25 | 1.5 | 1.5 | 108 | 163 | 3300 | 4400 | 32014 |
70 | 110 | 31 | 1.5 | 1.5 | 134 | 208 | 3300 | 4400 | 33014 |
70 | 120 | 37 | 2 | 1.5 | 181 | 266 | 3100 | 4200 | 33114 |
70 | 125 | 26.25 | 2 | 1.5 | 138 | 173 | 3100 | 4100 | 30214 |
70 | 125 | 33.25 | 2 | 1.5 | 169 | 225 | 3100 | 4100 | 32214 |
70 | 125 | 41 | 2 | 1.5 | 206 | 294 | 3100 | 4100 | 33214 |
70 | 150 | 38 | 3 | 2.5 | 230 | 273 | 2600 | 3500 | 30314 |
70 | 150 | 54 | 3 | 2.5 | 317 | 414 | 2700 | 3600 | 32314 |
75 | 115 | 25 | 1.5 | 1.5 | 110 | 169 | 3100 | 4200 | 32015 |
75 | 115 | 31 | 1.5 | 1.5 | 141 | 225 | 3200 | 4200 | 33015 |
75 | 125 | 37 | 2 | 1.5 | 186 | 280 | 3000 | 4000 | 33115 |
75 | 130 | 27.25 | 2 | 1.5 | 142 | 181 | 2900 | 3900 | 30215 |
75 | 130 | 33.25 | 2 | 1.5 | 174 | 234 | 2900 | 3900 | 32215 |
75 | 130 | 41 | 2 | 1.5 | 212 | 310 | 2900 | 3900 | 33215 |
75 | 160 | 40 | 3 | 2.5 | 260 | 311 | 2500 | 3300 | 30315 |
75 | 160 | 58 | 3 | 2.5 | 363 | 481 | 2500 | 3300 | 32315 |
