(22.5X8.25, 9.00X22.5) Forged Aluminum Truck Wheels, Aluminium Wheel rims, Alloy wheel, Steel Truck WheelsAdvantage of aluminum truck wheel: 1.Surface treatment : machined finish,polished inside,polished outside,polished both sides
2.Strong point : Fuel-efficient,beautiful appearance ,
Environment-protective durable,Reliable security, High strength,
Tire longevity,Save energy,Best quality with competitive price.
3. Certificate: SABS,Smithers,DOT,VIA,ISO ,TS16949.
4. After-sales service: our quality guarantee is five years.
5. Exported area: North American South Africa, USA, Canada.
Feature of steel truck wheel1. Surface: painting different colors according to request
2. Cost: cheaper
3. Certificate: DOT ISO TUV..
4. After-sales service: 2years warranty
Application: Truck, Bus, Trailer
Specifcation:
WHEEL SIZE | TIRE SIZE | P.C.D | C.B.D | BOLT HOLE NO. | ET/OFFSET(mm) |
| 22.5x8.25 | 11R22.5 | 335 | 281 | 10 | 165 |
| 12R22.5 | 335 | 281 | 10 | 165 |
| 335 | 281 | 10 | 0 |
| 275/80R22.5 | 275 | 221 | 8 | 0 |
| 295/80R22.5 | 285 | 221 | 8 | 163 |
| 315/70R22.5 | 285.75 | 221 | 10 | 165 |
| 295/70R22.5 | 285.75 | 221.6 | 10 | 168 |
| 285.75 | 220 | 10 | 168 |
| 335 | 281 | 10 | 171.5 |
After Service: We will offer 5 year warranty for Aluminum wheels. 2years for steel wheel
Quality Control: All our wheels will be with EU standard
More Sizes:| 17.5x6.00 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 01 | 6 | φ32 | φ222.25 | φ164 |
| 17.5x6.75 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 02 | 6 | φ32 | φ222.25 | φ164 |
| 03 | 10 | φ26 | φ225 | φ176 |
| 04 | 10 | φ26 | φ225 | φ176 |
| 19.5x6.00 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 05 | 6 | φ32 | φ222.25 | φ164 |
| 06 | 8 | φ24 | φ275 | φ221 |
| 19.5x6.75 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 07 | 8 | φ24 | φ275 | φ221 |
| 08 | 6 | φ32 | φ222.25 | φ164 |
| 19.5x7.50 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 09 | 8 | φ24 | φ275 | φ221 |
| 22.5x6.75 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 10 | 8 | φ32 | φ275 | φ214 |
| 11 | 8 | φ32 | φ285 | φ221 |
| 12 | 10 | φ26 | φ285.75 | φ220 |
| 13 | 10 | φ32 | φ285.75 | φ222 |
| 22.5x7.50 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 14 | 8 | φ32 | φ275 | φ214 |
| 15 | 8 | φ32 | φ275 | φ214 |
| 16 | 8 | φ32 | φ285 | φ221 |
| 17 | 8 | φ32 | φ285 | φ221 |
| 18 | 10 | φ26 | φ285.75 | φ220 |
| 19 | 10 | φ32 | φ285.75 | φ222 |
| 20 | 10 | φ26 | φ335 | φ281 |
| 21 | 10 | φ27 | φ335 | φ281 |
| | | | | |
| 22.5x8.25 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 1 | 8 | φ32 | φ275 | φ214 |
| 2 | 8 | φ24 | φ275 | φ221 |
| 6 | 8 | φ32 | φ285 | φ221 |
| 7 | 10 | φ26 | φ285.75 | φ220 |
| 8 | 10 | φ26 | φ285.75 | φ220 |
| 12 | 10 | φ26 | φ335 | φ281 |
| 13 | 10 | φ27 | φ335 | φ281 |
| 15 | 8 | φ32 | φ285 | φ221 |
| 22.5x9.00 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 1 | 8 | φ32 | φ275 | φ214 |
| 4 | 8 | φ32 | φ285 | φ221 |
| 5 | 10 | φ26 | φ285.75 | φ220 |
| 8 | 10 | φ32 | φ285.75 | φ222 |
| 9 | 10 | φ26 | φ335 | φ281 |
| 22.5x9.75 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 1 | 10 | φ26 | φ335 | φ281 |
| 2 | 10 | φ26 | φ285.75 | φ220 |
| 3 | 10 | φ26 | φ335 | φ281 |
| 22.5x11.75 |
| NO. | bolt hole | bolt dia | PCD | Center hole |
| 1 | 8 | φ32 | φ275 | φ214 |
| 2 | 8 | φ24 | φ275 | φ221 |
| 3 | 8 | φ32 | φ285 | φ221 |
| 4 | 10 | φ26 | φ285.75 | φ220 |
| 5 | 10 | φ32 | φ285.75 | φ222 |
| 6 | 10 | φ26 | φ335 | φ281 |
| 11 | 10 | φ27 | φ335 | φ281 |
| 22.5x13.00 |
| 1 | 10 | φ26 | φ335 | φ281 |
| 3 | 10 | φ27 | φ335 | φ281 |
| 22.5X14.00 |
| 1 | 10 | φ27 | φ335 | φ281 |
| 2 | 10 | φ26 | φ335 | φ281 |
Oasisland International is one of the fast-growing tyre and wheel rim supplier in China specializing in the agricultural, trailer, construction, material handling, industrial, mining and other specials
All products we supply will be with quality and guarantee...
For the tyres we supply will be with certificates, such as CCC, DOT, ECE, GCC, SONCAP for different market.
For the Wheels, it will be engineering standards of the TRA and the ETRTO, as well as the testing standards established by SAE and EUWA. Further more, for some special market, our wheels will manufacture according to the local standard, such as Australia. That will guarantee all wheels can suit for different request of different markets.
Now we already provide some products to OEM client in some markets. We do sure our OEM market will be larger after testing our quality products. However we are small now, we will grow to be larger and stronger soon basic on our clients' support.
