| Prod Model: |
cxp-2 |
| Size: |
Outside Size: 7000*5260*3400 mm |
| Voltage: |
380V50Hz3pH for Motors, 220V50Hz1pH for Lights |
| Power: |
25kw |
| Certification: |
CE |
| Airflow Direction: |
Fully Undershot-type |
| Heating Mode: |
Diesel |
| Paint Mist Treatment: |
Dry-type |
| Condition: |
New |
| Brand: |
Caixin |
Product Description
Product DescriptionSpray booth manufacturer(economy model, CE, 2 years warranty time)
1. CE approved
2. German Technology
3. Spray booth professional manufacturer
4. Factory price, energy saving
5. High quality, best sell service, timely delivery
6. We can meet at customer's special requirement
About Car Tools Co., Ltd:
Our company is a global supplier in the automotive aftermarket offering a full range of equipment and service solutions for workshops. Our goal is to offer the high-quality products and excellent services at a reasonable price. Our quality meets the requirement of European market--- CE approved auto maintenance tools painting camera China paint room
Model: cx 7600
| Outside Size:(mm) | 7130 x 5800x 3810(L x W x H) | Inside Size:(mm) | 7000 x 4000 x 2800(L x W x H) |
| Foundation and Floor | Basement | Full metal foundation, full grids, the grids are suppressive type of steel grating instead of traditional twisted steel for the cross bar steel grating. The biggest features for it are beautiful, durable and better force bearing. |
| Surface area of foundation | 27M²(Full Galvanized Grids ) |
| Metal Basement | 350mm height, the ventilation effect is better than traditional spray booth |
| Drive-in Ramps | 3Units,each size:2000×1030 mm(B×H),diamond plate construction |
| Wall and Door | Wallboard and Roof Panel | Adopt high quality double construction fireproof rock wool insulation materials, thickness is 50mm |
| 3-Folded Entrance Door With Safety Glass Window | 1 set, size of opening:3200x2700 mm(B x H), large tempering glass observation window, size is bigger and view is better than traditional spray booth |
| Operator's Door With Safety Glass Window | Large opening size: 800x2000mm(B x H) hand-made, tempering glass observation window |
| Spray gun hanging system | Install hanging arm in cabin, convenient for operators to hang spray gun, etc. |
| Lighting System | Ceiling Lighting | 8Units, each4×58W, Total 1856W, grade of lighting box's dustproof and waterproof reach IP54 grade. |
| Side Lighting | 8Units, each2×58W, Total 928W, grade of lighting box's dustproof and waterproof reach IP54 grade. |
| Brightness | ≥ 1500 LUX |
| | Pre-filters | EU3 grade pocket filter system, filtration effect is much better |
| Filtration | Ceiling Filters | EU5 grade high efficient filter |
| | Bottom filter & exhaust filter | Fibreglass paint-stop filter, G2 Grade |
| Air | Inlet fan (Direct Drive Motor) | Adopt big impeller turbo fan 11KW , 6-pole motor, 970RMP, 380V, 50HZ, CE, SIEMENS brand motor |
| Ventilation System | Outlet fan (Direct Drive Motor) | Adopt big impeller turbo fan 11KW , 6-pole motor, 970RMP, 380V, 50HZ, CE, SIEMENS brand motor |
| | Painting and baking exchange system | Solenoid valve+ pressure adjustment control cylinder driven damper exchange |
| | Fan Capacity | 32.000m³/h |
| | Air Flow Speed | 0.30m/s , Inverter control |
| Heating System | Heating exchanger | Adopt high efficient heat-resistant stainless steel as cycling heat exchanger |
| Heating exchange capacity | 315KW(340.000Kcal/H) |
| Burner Model | Adopt Italy RIELLO diesel burner RL34 , (340.000kcal/H), quicker heating and much better effect, more rest assure for quality |
| Heating Time | 2-4 minutes (from 20 to 60ºC) under baking status, max baking temperature is 80°C |
| Control Board | Control System | Inverter control system |
| PLC controller | Yes, PLC control system, more reliable, lower breakdown rate |
| Human-computer interface touching screen control system | Yes, touching screen control |
| Inverter control | Inverter control , more energy-saving, more economic |
| Function | Painting, warm painting, baking, leveling, emergency stop switch, inverter, failure indication, over-temperature alarm indication, baking delay stop protection |
Other conditions and terms:
1. Payment term: T/T 50% advanced after order confirmed, T/T 50% balance paid before delivery.
2. Delivery date: 10-15 days after order confirmed.
3. Warranty: 2 years. During the warranty time, any problem caused by products' quality, BTD has responsibility to offer free spare parts to customers freely and bear the delivery cost for DHL or TNT Carrier.
4. Quality: Our products are welcomed in Europe, our quality meets the requirement of European market.
5. Service time: Life long maintenance
