Underground Basement Scissor Parking Car Elevator

Name: Underground Basement Scissor Parking Car Elevator
Brand: ibuyautoparts.com
SKU: 678986992
Availability: InStock
Rating: 4.5 (104 reviews)

Price:	US $ 4500-6800/Piece
Trade Terms:	FOB,CFR,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	SJG
Markets:	North America,South America,Eastern Europe,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Load Capacity:	3000kg
Platform Size:	5500*2500mm
Lifting Height:	5000mm or Customized
Speed:	6m/Min
Power:	5.5 Kw
Control:	Button/Remote Control
Drive:	Hydraulic
Installation:	Pit installation
Color:	Black, Red, etc
Warranty:	12 Months
Type:	Double Cylinder Hydraulic Lift
Lifting Capacity:	3T
Certification:	CE
Design:	Scissor
Brand:	Moral

Product Description

Underground Scissor Parking Elevator for Car

Load capacity: 3000--6000kg
Platform size: 5.5*2.5m
Lifting height: 4m, 6m, 8, 10m and so on
Hydraulic drive system

1. Power supply 220 VAC, 3 Phases 60 Hz/ local power
2. Total capacity 3,000 kilograms
3. Size of platform 5500 X 2500 mms. Diamond steel sheet metal
4. Stops with limit switch control system

1) Scissor hydraulic car parking system can be used to lift cars with different levels, suitable for car moving between stairs, from basement to first floor, to second floor, or to third floor. Operation is easy, and the lifts run very smoothly. There are also explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The limit switch system helps the lift to stop at accurate position.
3) The hydraulic cylinders and hose are armed with explosion-proof lock valve to avoid a sudden drop once hydraulic pipe breaks, the work platform will be down slowly to ensure safety of car.
4) Emergency button is available on each control box, when emergency occurs, the immediate STOP can be realized.
5) Control system adopt elevator control system, very convenient and safety.
6) Custom-made products are done according to detailed request, please tell us load capacity, lift height, and platform size you need, our engineer will design a suitable lift for you soon.

Model	SJG3-5
Lifting capacity	3000kg
Lifting height	5000mm
Platform size	5500 X 2500 mms. ( Diamond steel sheet metal )
Motor power	5.5kw
Power supply	AC 220V/380V 50HZ/60HZ
Speed	6m/Min
Weight	1850KG

Welcome to the on-line home of Moral lift Machinery Co., Ltd. Our factory is one of the leading manufacturer of Disabled weelchair lifts & scissor lift &parking equipment&Work platform&Horse trailer in China. Our mainly product including wheelchair lift, car parking lift, car turntable, cargo lift(VRC and scissor lift), work platform and Horse trailer etc.

With over 4 decades of experience in the manufacture of materials handling products, Morallift' S skilled team of friendly personnel can provide fast responses and technical expertise. Our product has got ISO9001: 2000 Quality Certification and has passed the test of CE Quality system as well. We always provide our customers with the best quality products, competitive prices and excellent services.

Our customers from around the world, We regard "reasonable prices, efficient production time and good after-sales service' ' As our tenet, and hope to cooperate with more customers for mutual development and benefits. We welcome every potential customer to visit our factory!
