Unbraked Agricultural Trailer Axles for 16ton 8ton 11ton

Name: Unbraked Agricultural Trailer Axles for 16ton 8ton 11ton
Brand: ibuyautoparts.com
SKU: 806505845
Availability: InStock
Rating: 4.4 (48 reviews)

Price:	US $ 120-200/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

6 ton 8 ton agriculture trailer axle for farm implement

Features:

1. Capacity: 1T-8T

2. Track: can be made according to customers' request
3. Used in: Tractor, Small Trailer, Agriculture Trailer

4. Axle Beam: Square 40/50/60/70/80mm

5. With Brake or Without Brake

6. High quality, Competitive price, Fast delivery

7. Certificate: ISO9001:2000/TS16949

SO 9001:2000 and TS 16949 manufacture of axles

providing all kinds of suspension system and other trailer parts

--holds the notice all the time"frist -class goods,reasonable price.

--perfect after - service', we always think of your demand ahead of time never.

--ignore every bit demand of clients during the service.Let our sincereness and specialized technique be always with you!

SHAFT SIZE	LOAD CAPACITIES	STUD PATTERN
SIZE	LENGTH				#	C/BORE	PCD	STUD SIZE
50mm	350mm	1650kg	1950kg	1350kg	6	161mm	205mm	M16x1.5mm
60mm	350mm	2400kg	2850kg	2000kg	6	161mm	205mm	M18X1.5mm
70mm	360mm	3500kg	4250kg	3250kg	6	161mm	205mm	M18x1.5mm
70mm	400mm	3500kg	4250kg	3250kg	6	161mm	205mm	M18x1.5mm
80mm	560mm	4500kg	5400kg	4000kg	8	220mm	275mm	M18x1.5mm
90mm	560mm	5000kg	6000kg	4500kg	8	220mm	275mm	M20x1.5mm
90mm	560mm	5000kg	6000kg	4500kg	10	280mm	335mm	M22X1.5mm
100mm	560mm	6500kg	7000kg	5750kg	10	280mm	335mm	M22X1.5mm

Specification:

Item No.	Capacity (Ton)	Track(mm)	Axle Beam(mm)	Wheel Fixing(mm)	Bearing	Weight (Kg)
OSA01-AG01	1	200	40	4 x M14 x dia.130 x 84	30205-20207	15
OSA03-AG01	3	200	50	6 x M18 x dia205 x 160	30206-30209	20
OSA05-AG01	5	200	60	6 x M18 x dia205 x 160	30207-30211	32
OSA06-AG01	6	200	70	6 x M18 x dia205 x 160	30208-30213	43
OSA08-AG01	8	200	80	6 x M18 x dia205 x 160	32211-30215	65

Application:

Prod Model:	40x40mm, 50x50mm, 60x60mm, 70x70mm, 80x80mm
Brake:	Without Brake
Type:	Stub Axle

Oasisland International is one of the fast-growing tyre and wheel rim supplier in China specializing in the agricultural, trailer, construction, material handling, industrial, mining and other specials

All products we supply will be with quality and guarantee...

For the tyres we supply will be with certificates, such as CCC, DOT, ECE, GCC, SONCAP for different market.

For the Wheels, it will be engineering standards of the TRA and the ETRTO, as well as the testing standards established by SAE and EUWA. Further more, for some special market, our wheels will manufacture according to the local standard, such as Australia. That will guarantee all wheels can suit for different request of different markets.

Now we already provide some products to OEM client in some markets. We do sure our OEM market will be larger after testing our quality products. However we are small now, we will grow to be larger and stronger soon basic on our clients' support.
