Pls note the specifications as following:
1.External Locking Rim Dimensions: 300mm-510mm (10″- 20″)
2.Internal Locking Rim Dimensions: 355mm-615mm (12″- 24″)
3.Max Tyre Diameter: 1040mm
4.Max Tyre Width: 410mm
5.Bead Breaker Force (10bar) : 2500Kg
6.Working Pressure: 8-10bar(116-145Psi)
7.voltage: 110/220V (1ph) 380V (3ph)
8.Motor Power: 0.75Kw-1.1Kw
9.noisy: <70dB
10.Technical features:
Pneumatic Bead Breaker blade
controlled pressure gage
11. Net weight: 256kgs
Gross weight: 298kgs
| External Locking Rim Dimensions | 300mm-510mm (10″- 20″) |
| Internal Locking Rim Dimensions | 355mm-615mm (12″- 24″) |
| Max Tyre Diameter | 1040mm |
| Max Tyre Width | 410mm |
| Bead Breaker Force (10bar) | 2500Kgs |
| Working Pressure | 8-10bar(116-145Psi) |
| voltage | 110/220V (1ph) 380V (3ph) |
| Motor Power | 0.75Kw-1.1Kw |
Features:
1. The equipment can be used for different purposes of demounting, mounting and inflating tyres.
2. The machine adopts the parkerising bead breaker cylinder having bead breaker power 2500KG to bead break the tire from rim easily.
3. Pneumatically controlled tilting system saves the effort and time of the operation. Pneumatic lift device can be smoothly and steadily in any position, so that the disassembly of tire more convenient and easy.
4. The steel mount/demount is cast from excellent ,material with special shape and durable performance.
The supplied plastic mount/demount head with the equipment is made from special engineering plastic that has enough intensity and not damage the tyre and rim.
5. The two clamping cylinder ensures accurate central alignment, so that the wheels can be held tightly.
6. Moving up and down of the hexagonal column and locking of the horizontal arm is controlled by a button, which save operation time and make operation safe.
7.Human design of the mount/demount help greatly reduces work-intension of the operator, making tyre-mount and tyre-demount operations convenient and easy.
8.The quick-inflating device keeps tyre bead close to the rim tightly, avoiding over-long time inflation or difficult inflation when the gun inflator is used for the empty tyre.
9.The bead breaker shoe can be adjusted to match tyres with different widths
10.Mount/demount help device and quick-inflating device features simple operation and
reliability. It is a great help in car repair garage and tyre dealers.
