HLD-QZY-2R model Turbocharger Testing Machine,test speed,air flow, boost pressure,etc
General introduction:
This turbocharger test bench is applicable for testing performance of turbocharger on various models truck engines and can carry out dynamic test of boost pressure, air flow and lubrication of turbocharger and display measured data by digital instrument.
It can carry out contrast test of inlet & outlet air pressure difference of various turbochargers and read the values
Advantages:
1.It is with indicator lamp following each step and warn you the problems.
2.It possesses high control sensitivity and strong controllability.
3.It is easy to learn and operate.
4.It has a protective cover to avoid danger during test
5.It can test various kinds of turbochargers as long as they are with the same working principle
6.It is matched with PLC computer to operate, display, save & print test results and curves.
7.It adopts electrical heating to make high temperature test of the turbocharger, simulating the running state on the cars, the speed can reach hundred thousands r/min.
8.It uses high precision sensor,simulating the working state of the turbocharger on the vehicle
Test items:
1.Test speed of turbocharger
2.Test air flow of turbocharger
3.Test boost pressure of turbocharger
4.Test lubrication state of turbocharger
5.Test turbine inlet temperature of the turbocharger
6.Test turbine outlet temperature of the turbocharger
7.Test the temperature of the lubrication oil
8.Test the inlet pressure of the turbocharger
Technical parameter:
Model no | HLD-QZY-2R |
| Language | English |
| Material | Metal plate |
| Painting | Powder painting, durable and beautiful |
| Color | Blue |
| Voltage | 380V 50 Hz 3P |
| Power of air generator | 11KW |
| Frequency converter power | 15KW |
| Input air source | 1.0Mpa |
| Motor power of the oil pump | 370W |
| Rated pressure of the oil pump | 0-2.0Mpa(adjustable) |
| Maximum displacement of oil pump | 6L/min |
| Speed of the turbocharger | 0-100000r/min |
| Power of the heater | 57KW 0-500ºC adjsutable |
| Accessories: |
| Accessory wires, clamps, etc. |
| Others you may want to know: |
| MOQ | 1set |
| Warranty period | 12 months |
| Payment term | T/T 50% in advance, the balance should be paid before delivery (negotiable) |
| Delivery time | 35 days after receiving downpayment |
| HS code | 90312000.90 |
| Packing | Export plywood case |
Why Choose us:
1.32 years' design,development and produce experience
2.Professional R&D team
3.Strict QC
4.A good pre-sale and after-sale service
5.Can design and make according to customer's requests
Company introduction:
Established in 1984, Qingdao Haolida Automotive Equipment Manufacturing Co.,Ltd is a professional manufacturer and exporter that is concerned with the design, development and production of automobile maintenance and test equipment.
Our main products are automobile test benches, such as electric universal test bench, alternator/generator test bench, starter test bench, engine test bench, turbocharger test bench, air compressor test bench, braking system test bench, steering gear and power pump test bench, AC compressor test bench, clutch test bench, automatic gearbox/transmission test bench, etc, brake shoe riveting and grinding machines, electric/ manual hydraulic presses, auto pit jack/lift, and so on. We can also design and make specially according to customers' request.
Established in 1984, Qingdao Haolida Automotive Equipment Manufacturing Co., Ltd is a professional manufacturer and exporter that is concerned with the design, development and production of automobile maintenance and test equipment. We obtained tens of national patent on some related products. Our main products are automobile test benches, such as electric universal test bench, alternator/generator test bench, starter test bench, engine test bench, turbocharger test bench, air compressor test bench, braking system test bench, steering gear and power pump test bench, AC compressor test bench, clutch test bench, automatic gearbox/transmission test bench, etc, brake shoe riveting and grinding machines, electric/ manual hydraulic presses, auto pit jack/lift, and so on. We can also design and make specially according to customers' request.
We are located in Qingdao city, Shandong province, with convenient transportation access. Our factory is thirty minutes' drive to Qingdao airport, and two hours' drive to the loading port.
All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. We have passed the ISO9001-2008 international quality system authentication. We gained many honors in automobile maintenance and repair industry, we are a standing member of the China Automobile Maintenance and Repairing Equipment Trade Association, One of the ten most influential company in automobile maintenance and repair industry, we are also a designated factory by General Armament Department of CPLA.
Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. Our sales network covers North America, South America, European, South Africa, Russia, Asia, Middle East, etc.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are also sincerely looking for steady and long-term cooperative local agents in different areas. We are looking forward to forming successful business relationships with new clients around the world in the near future.
