Truck, Trailer Bearings, Center Support Bearing 88505, 88510, 88512

Name: Truck, Trailer Bearings, Center Support Bearing 88505, 88510, 88512
Brand: ibuyautoparts.com
SKU: 762532705
Availability: InStock
Rating: 4.7 (129 reviews)

Price:	US $ 4/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Deep Groove Ball Bearing

Boundary dimensions(mm)				Locking Ring dimension(mm)			Mass (kg)		Bearing No.
d	D	B	C	d 1	D 1	T	Bearing	Ring
25	52	16.8	15						88505
30	62	24	16				0.26		88506
35	72	25	17				0.35		88507
40	72	22	17				0.32		88508
40	80	27	21				0.45		88508A
45	85	27	21				0.5		88509
50	90	30	22				0.55		88510
55	100	31	23				0.76		88511
60	110	36	22				0.97		88512
35	72	25	17				0.35		88107
38.894	80	27.5	21				0.48		88128
38.894	80	27.5	21	38.77	54	9.86	0.48	0.09	88128R
38.894	80	27.5	21	38.77	58	16.45	0.48	0.16	88128RA
35	72	21.46		34.93	50	10	0.35	0.08	RW207CCR
35	69.789	17.78	16.7	34.93	50	15.4	0.3	0.1	RV\507CR
34	68	24	21	33.92	47.7	8.6	0.26	0.065	RWF34R
36.373	73.05	23.62	17.7	36.29	50.5	9.65	0.36	0.07	RWC35YYR

center support bearing 88505,88107,88128,88512,88507,88511

Bearing NO.	I.D		O.D		W
	d		D		B
	mm inch		mm inch		mm inch
87500	10	0.3937	30	1.1811	9	12.7
87501	12	0.4724	32	1.2598	10	12.7
87502	15	0.5906	35	1.378	11	12.7
87503	17	0.6693	40	1.6535	12	14.288
87504	20	0.7874	47	1.8504	14	15.875
87505	25	0.9843	52	2.047	15	15.875
87506	30	1.1811	62	2.4409	16	20
87507	35	1.3779	72	2.8346	17	21
87508	40	1.5748	80	3.1496	21	24
87509	45	1.7716	85	3.3465	21	24
87510	50	1.9685	90	3.5433	22	26
87602	15	0.5906	42	1.6535	13	15
87603	17	0.6693	47	1.8504	14	16
87604	20	0.7874	52	2.0472	15	19
87605	25	0.9843	62	2.4409	17	21
87606	30	1.1811	72	2.8346	19	23
87607	35	1.3779	80	3.1496	21	25
87608	40	1.5748	90	3.5433	23	27
87609	45	1.7716	100	3.937	25	30
88505	25	0.9843	52	2.0472	15	16.8
88506	30	1.1811	62	2.4409	16	24
88507	35	1.378	72	2.8346	17	25
88508	40	1.5748	80	3.1496	21	27
88509	45	1.7716	85	3.3465	21	27
88510	50	1.9685	90	3.5433	22	30
88511	55	2.1654	100	3.937	23	31
88512	60	2.362	110	4.3307	22	36

Prod Model:	88505, 88510, 88512
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Delivery:	Stock
Type:	Wheel Hub Bearing
Material:	Chrome Steel
Tolerance:	P5
Certification:	ISO9001
Clearance:	C3
