Smart GPS Tracking System for Fleet Management (GP6000)

Name: Smart GPS Tracking System for Fleet Management (GP6000)
Brand: ibuyautoparts.com
SKU: 674222452
Availability: InStock
Rating: 4.9 (21 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	100/Piece
Pay Type:	T/T,D/P,Western Union

Contact Supplier

Showroom Product Company Profile

GP6000 is an advanced GPS/GSM/GPRS vehicle tracking device, which can fully satisfy the complicated needs of mobile asset management, it can support 3 different sensors at the same time, which enable the unit to suit customer's advanced application requirements.

SMS, GPRS, and TCP/UDP communication
Fuel consumption monitor
14-channel vehicle signal alarm
Blind area data re-report, supports 360-point blind area data and 21, 600 pieces history data
Data transmitted unvarnished
Remote control fuel and power break
Initiative anti-theft
Remote configuration

Real-time tracking (time, distance interval or intelligent mode)
Intelligent power management
Power low/lost alarm, backup battery low alarm
Built-in voice wiretapping
16 geofencing reports
Journey report wireless download
GPS mileage report/electronic mileage report
GPS antenna disconnect/cut/short-circuit alarm
Up to 120, 000 data log storage

Hardware specifications:
Dimension: 121 x 82 x 29mm
Weight: 0.85kg
GPS receiver: 20-channel or above GPS receiver
Datum: WGS-84
Power source: 10 to 33V DC
Power consumption: Less than 100mA at 12V DC in operating mode
Operating temperature: -40 to +85
Communications:
GSM 850/900/1800/1900MHz
SMS, GPRS, and TCP/UDP
Serial port: 3 RS-232 serial ports

Programmable input port:
Port A: Power and vehicle control
Port B: Detecting 14-channel vehicle signal
Port C: Connect to additional peripheral, such as RFID, scanner, and sensor
Input: 14 channels
Output: 8 channels
Buffer memory: 128KB, 2MB built-in memory
Default baud rate: 9, 600BPS
Backup battery: 350mAh
Peripherals: Supports at most 2 additional peripherals at the same time
Optional items:

Mobile data terminal
RFID reader
Thermal sensor (at most 12 channels)
CCD camera (at most 8 channels)
Scanner
Microphone Applications:
Vehicle tracking
Vehicle data warehouses
Fleet management
Vehicle securities/recoveries/anti-hijacks
Mobile asset tracking
Location based services
Taxi groups.

Basic Function	TCP/UDP/SMS Transmission Mode	TCP/UDP/SMS
	Date automatic upload	Time interval/Distance interval
	Date flow control/power saving mode	Factory setting
		Definition by user
		GPS module power off
		GPS and GSM module power off
	Management time of uploading	Time/Day/Week
	Mileage statistics	GPS/Electronic
	Remotely listen-in	build in
	Geo-fence	64 kinds
	Alarm kinds	GPRS/SMS/Email
	Domain name supporting	IP/domain name
	Blind are data storage(43200 pcs)
	GPS antenna open/short detection
	Self-check, signal input, power consumption
External device function	Dispatch screen	Message exchange between driver and centre
		two-way voice call
	Fuel sensor(Analog/Digital)	Single signal/Multi-signal
	CCD Camera
	RFID Device
	Password Keypad/Bar-Code Scanner/Temperature Sensor
Control Function	Cut fuel supply
I/O Port	6 Switch signal input(4 high level trigger, 2 low level trigger)
	1 Analog signal input(0~5V)
	1 Pulse signal input(< 3.8V, 2K Hz trigger
	5 Switch signal output(< 500mA)
	3 Serial port(support more than 3kinds of different extend device at the same time
	2 Intelligent programmable port(I/O, A/D)

Prod Model:	GP6000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Material:	Aluminium Alloy
Dimensions(LWH):	1218229mm
Weight:	820g(Including Standard Accessories
Power Consumption:	60ma~100ma
Input Voltage:	10~30V
Backup Power:	8.4V 400mAh Ni-MH Battery
GPS:	Sirf Star 3
GSM:	850/900/1800/1900 MHz
