Repair Tools Hydraulic Lift Cheap Car Lifts Car Parking Lift

Repair Tools Hydraulic Lift Cheap Car Lifts Car Parking Lift
Price: US $ 4750-6800/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T
Prod Model: SJG3-2.5
Item: Car Parking Lift
Power: 4.0kw - 11kw
Drive Type: AC, Hydraulic
Safety Device: Explosion Proof Lock Valve, Emergency
Drive Mode: Hydraulic + Motor: Safe
Power Supply: 220V/240V/380V/415V
Capacity: 2-15ton(on Request)
Application: Garage Car Lifts Table
Motor: Customer Required Brand or Chinese Famous Brand
Height: 2.5m-10m
Type: Double Cylinder Hydraulic Lift
Lifting Capacity: 3T
Certification: ISO
Design: Scissor
Brand: Sdlift

Product Description

Repair tools hydraulic lift cheap car lifts car parking lift
Shandong Lift Machinery 2 Years Warranty

Application:
- The car parking lift can be used to lift car with different levels, suitable for car moving between stairs, from basement to first floor, to second floor, or to third floor.
- Operation is easy.There are 2 sets control system installed on the hydraulic car elevator garage car elevator, 1 control box below, and 1 hand controller on safety rail that can be operated on work platform.



The models we supplied for clients:

MODEL

LOAD CAPACITY

PLATFORM SIZE

LIFT HEIGHT

PIT DEPTH

POWER

SJG2.5-3

2.5T

5.2m x 2.6m

3m

750mm

220V, 240V, 380V or 400V

SJG2-6.5

2T

5.2m x 2.8m

6.5m

800mm

220V, 240V, 380V or 400V

SJG2.5-3.5

2.5T

5.2m x 2.6m

3.5m

800mm

220V, 240V, 380V or 400V

SJG2.5-5

2.5T

5.6m x 3m

5m

800mm

220V, 240V, 380V or 400V

SJG3-2.5

3T

5m x 2.3m

2.5m

750mm

220V, 240V, 380V or 400V

SJG3-3

3T

5.2m x 2.6m

3m

800mm

220V, 240V, 380V or 400V

SJG3-3.5

3T

5.6m x 2.7m

3.5m

800mm

220V, 240V, 380V or 400V

SJG5-10

5T

4.5m x 2.5m

10m

1150mm

220V, 240V, 380V or 400V

SJG8-2.5

8T

6.5m x 4.5m

2.5m

850mm

220V, 240V, 380V or 400V

SJG12-3

12T

5.5m x 2.8m

3m

950mm

220V, 240V, 380V or 400V

SJG15-4.5

15T

8m x 2.2m

4.5m

1150mm

220V, 240V, 380V or 400V

SJG20-5

20T

6m x 3m

5m

1200mm

220V, 240V, 380V or 400V

The carparking lift can be customized as your detailed size.


Configuration:
1) Platform Material:120mm*60mm rectangular tube +6mm checkered iron
2) Scissor material:200mm*100mm*10mm high strength Manganese Steel.
3) Hydraulic system:380V/5.5Kw
4) High Precision Hydraulic Cylinder:110*4sets
5) Piston Rod:80*4 hard chromium plating surface.
6) High-pressure oil pump
7) Hydraulic oil:Summer 46#, winter 32#
8) Controller:1 control box below, 1 control panel above platform


Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The safety rails to guarantee safety of the cars above the platform.
3) The limit switch system helps car parking lift to stop at accurate position.
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the car parking lift are passed 1.2 times loading test before leaving factory.


Company information:
We are a specialized manufacture in the production of all kinds of lift tables.Includes stationary scissor lift table, hydraulic scissor car lift, double car park lift, guide rail cargo lift, wheelchair lift, trailing scissor lift, trailing aluminum alloy mast lift, trailing articulated boom lift, self-propelled scissor lift table, and mobile and fixed dock ramp etc.

Our services:
1) We can design the car parking lift as per your requirement.
2) The most suitable car parking lift will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 years warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) We could reply you in 2 hours after received your any questions even on weekend and
Holiday.Engineers are available to your country if necessary.
