Specification
Item Name: Racing Connecting Rod (forged steel con rod)
Application for: Porsche, Audi, Chevy, Volvo, Opel, BMW, Mercedes Benz, VW, Toyota, Nissan, Honda, Mitsubishi, Suzuki, Ford, Peugeot, Volvo etc.
Material: Forged steel/40Cr/20Cr/aluminum
Production capacity: 10,000 Set/month
Warranty: 2 years
Delivery Day: about 30 days
Beam Style: I beam/H beam
| Chevy 454 : "H" &"I" Style Beam Con Rod |
| No. | Car model | Engine model | pcs/set | (mm)c-c | B/E bore | S/E bore | B/E W | S/E W | bolt |
| 51b | Chevrolet454 BIG BLOCK | 6.385" | 8 | 162.18 | 58.927 | 25.09 | 25.268 | 28.69 | 7/16" |
| 50 | 6.135" | 8 | 155.83 | 58.901 | 26.386 | 25.146 | 28.575 | 7/16" |
| 50 | 6.135" | 8 |
| 58.9 | 24.86 | 25.2 | 28.66 | 7/16" |
| 51 | 6.385" | 8 | 162.18 | 58.901 | 26.386 | 25.146 | 28.575 | 7/16" |
| 51 | 6.135" | 8 | 155.83 | 58.9 | 24.8 | 25.2 | 28.68 | 7/16" |
| 52 | 6.535" | 8 | 165.99 | 59.05 | 25.15 | 28.69 | 28.69 | 7/16" |
| 52 | 6.535" | 8 | 165.989 | 58.94 | 25.14 | 25.26 | 28.6 | 7/16" |
| 53 | 6.7" | 8 | 170.18 | 58.901 | 26.386 | 25.146 | 28.575 | 7/16" |
| 54 | 6.8" | 8 | 195.58 | 58.901 | 26.386 | 25.146 | 28.575 | 7/16" |
| 55 | 7.1" | 8 | 180.34 | 59.05 | 25.15 | 28.69 | 28.69 | 7/16" |
Chevy 350
| No. | Car model | Engine model | pcs/set | (mm)c-c | B/E bore | S/E bore | B/E W | S/E W | bolt |
| 56b | Chevrolet350 SMALL BLOCK | 350 6.0" | 8 | 152.4 | 56.385 | 23.47 | 23.876 | 26.92 | 7/16" |
| 56b | Chevy 5.627 | 8 | 142.93 | 65.53 | 23.55 | 23.876 | 26.92 | 7/16" |
| 56c | 6.125" | 6 | 155.58 | 56.515 | 22.987 | 25.273 | 25.273 | 3/8" |
| 56d | 6" | 6 | 152.4 | 56.515 | 22.987 | 21.844 | 21.844 | 3/8" |
| 56 | 6" | 8 | 152.4 | 56.515 | 23.55 | 23.876 | 26.92 | 7/16" |
| 57 | 5.850" | 8 | 148.59 | 56.515 | 23.55 | 23.876 | 26.92 | 7/16" |
| 58 | 6.125" | 8 | 155.58 | 56.515 | 23.55 | 23.876 | 26.92 | 7/16" |
| 59 | 5.565" | 8 | 141.35 | 56.515 | 23.55 | 23.876 | 26.92 | 7/16" |
| 60 | 5.7" | 8 | 144.78 | 56.515 | 23.55 | 23.876 | 26.92 | 7/16" |
| 61 | 6.2" | 8 | 157.48 | 56.515 | 23.55 | 23.876 | 26.92 | 7/16" |
| 62 | 6.25" | 8 | 158.75 | 56.515 | 23.55 | 23.876 | 26.92 | 7/16" |
| 60b | 350 5.7" | 8 | 144.78 | 56.358 | 23.47 | 23.876 | 26.92 | 7/16" |
| 240 | 350 5.744" | 8 | 145.898 | 55.067 | 22.0091 | 22.91 | 20.93 | 7/16" |
| 243 | 5.850" | 4 | 148.59 | 45 | 21 | 22.91 | 26.92 | 3/8" |
| 308a | 5.700",5.900" | 6 | 144.8 | 53.97 | 21.005 | 22.86 | 22.86 | 3/8" |
| 308b | 5.700",5.900" | 6 | 149.86 | 53.97 | 21.005 | 22.86 | 22.86 | 3/8" |
| 308e | 5.5 | 6 | 139.7 | 53.97 | 21.005 | 22.86 | 22.86 | 3/8" |
| 308c | 5.680" | 6 | 144.27 | 53.97 | 21.005 | 22.86 | 22.86 | 3/8" |
