1 CE, SGS, ISO, TUV approved about baking booth
2 16 years experience of manufactory baking booth
3 Real baking booth factory in China
4 1 year warranty
Configuration:
| External Size:(mm) | 7000x5450x3480 | Front Door:(mm) | 3000(w)x2750(h) |
| Internal Size:(mm) | 6900x3900x2800 | Total Power:(kw) | 15 |
| Cabin System | Wallboard | Fire-retardant composite molding Sandwich style EPS (epispastics polystyrene) (Rock wool and PU are optional )50mm thickness, EPS foam Density is 14kg/m³ ; The Colorful steel skin boards have been HDG(hot dip galvanizing),service life can reach 20 years without rusting. It keeps high insulation performance. Four colors for your choice, including blue, red, orange and white. High quality galvanized steel roof panel. |
| Basement | 300mm high powder coated galvanized steel sheet and square steel pipe construction. 3 rows of checked plate and 2 row of grids, antirust and strong. The bearing capacity of driving grids up to 1000 kg per wheel; Basement frame is assembly formed by antirust steel square tube, the overall performance is good and strong. Powder coated full ramps. |
| Door | 3 pieces of luxury front doors, made of 0.8mm galvanized powder coated sheet, beautiful and strong. Size: 3000(w)*2750(h). 1 piece of emergency door. |
| Air Circulation System | Intake Fan | 1x7.5kw direct drive turbo fan, Air Flow is 25000m3/h.BELIMO 20N electric damper. Air flow: 24,000m3/h. The wire core of our fans is full cooper so our fans are very durable. |
| Exhaust Fan | 1x5.5kw direct drive turbo fan, Air Flow is 18000 m3/h. |
| Air Pipe | Made of Galvanized steel sheet consisted of 4 pieces of straight pipe750*750*1000, and 1piece of elbow. |
| Air circulation type | Full inner air circulation type, particularly rapid heating, insulation ability, especially energy,reflect its superior performance in a cold environment. |
| Filtering | Multilayer filtering structure. The primary pocket filter can capture granules larger than10μm. Ceiling filter capture granules bigger than 5μm. The floor filter and active carbon filter beside exhaust fan can capture paint and dust emission when painting. The air cleanliness in the working environment can reach 98%. |
| Heating System | Burner | Original Italy RIELLO RG5S diesel burner, 260000Kcal/h. The heating time 4-5min(20-60°C) Max temperature at 80°C. Fuel consumption is 4-5kg/ vehicle. |
| Heat Exchanger | Two layers. Made of stainless steel. The heat exchange rate can reach 85%.Two layers to make our heating system safer and get higher heat exchange rate. What is more, we make two wings to make the temperature rise more quickly and save energy. |
| Air make up cabinet | The surface plate is powder coated galvanized plate, antirust, strong and beautiful; The frame is treated by hot-dip, antirust and strong, more durable than ordinary surface treatment, more beautiful, nodes with no damage spot, rigidity. |
| Oil tank support | Tank carefully made of high quality steel, the powder coated treatment, beautiful and durable. |
| Fume pipe | Fume pipe made of galvanized pipe, diameter of 190mm, 4 pieces of 1000mm long straight pipe, two 90 ° elbows. |
| LED Lighting System | Light tube | Ceiling light has 32 pieces of 16w LED lamps. Side light has 16 pieces of 16kw LED lamps. 900 Lux. LED lamps are more bright and durable. The grade of lighting box's dustproof and waterproof reach IP54 grade. |
| Light box | Welded galvanized plate, powder coated treatment, surface brightness, color uniformity. |
| Filtering System | Pre-filter filter | Grade G2 plate type fiber glass filter; Dual filtering structure. The Pre-filter can capture granules larger than 10μm. |
| Ceiling filter | EU5 grade high efficient filter; Ceiling filter capture granules bigger than 5μm.The air cleanliness in the working environment can reach 98%. |
| Floor filter | Multilayer glass Fiber. The air cleanliness in the working environment can reach 98%. |
| Ceiling filter support | Made of tube steel frame, thickness of 1.2mm, epoxy powder coating, antirust and strong, rigid, beautiful and durable, can be repeated disassembly, not easy to damage, easy to replace filter cotton. |
| Pollution Control System | Special configure with M pattern active carbon pocket filter system to filter paint and dust emission. |
| Control system | Control panel | Luxury Standard Microcomputer control system |
| Function | Use high quality electronic component, the temperature and the drying time is accurately shown, equip with overheat, overload& short-circuit protected, safe and reliable. Use well-known brand products, reliable quality, stable performance, display accurate. Especially with over-temperature and over-pressure alarm device. The electricity will be cut off once alarm devices alert. It makes our booth very safe. |
Guangzhou Weilongda Electromechanical Equipment Co., Ltd., which established in 2000, is one of the first and largest automobile care and maintenance equipments manufacturers and suppliers in China. It manufactures spray booths, preparation stations, auto lifts and supplies body repair systems, car wash machine, wheel alignments, tire changers, wheel balancers and other relevant garage equipment to the clients all over the world.
Quality First, Service Highest is the policy carried by all Weilongda members. Quality and safety control system is applied throughout the whole produce procedures, from design and the raw material purchasing to parts fabrication, from welding to painting, from the product's factory assembling to packing and loading. All the products are produced strictly according to ISO9001: 2008 systems and CE standards.
After years of investment and management, WEILONGDA is a famous brand now. It enjoys high reputations among domestic customers as well as clients from England, Ireland, Poland, Sweden, Russia, Nigeria, Ghana, South Africa, America, Australia, Japan and other Asian countries.
Please feel free to contact members of Weilongda and start a happy and win-win cooperation.
With your join, the future is better.
