Insulation Fire Protective Cap Glazed Spark Plug 95% Alumina Ceramic Ignition Spark

Name: Insulation Fire Protective Cap Glazed Spark Plug 95% Alumina Ceramic Ignition Spark
Brand: ibuyautoparts.com
SKU: 695092645
Availability: InStock
Rating: 4.3 (73 reviews)

Price:	US $ 2/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Specifications

1. SGS factory
2. Best price, good quantity
3. Short delivery time
4. long working life

1. Material: 95% alumina ceramic

Performance For Alumina Ceramic
Item		Unit	95 Al₂O₃	99 Al₂O₃
Physical Characteristics	Bulk density	g/cm³	3.6	3.8
Physical Characteristics	Water absorption	%	0	0
Mechanical Characteristics	Flexural strength	Mpa	340	400
	Hardness Vickers	Gpa	13.5	15.6
	Elastic modulus	Gpa	320	370
	Poisson's ratio	-	0.23	0.23
Thermal Characteristics	Linear expansion coefficient	(20⁰C-500⁰C) 10^-6/⁰C	6.2-8.5	6.8-8
	Thermal conductivity	w/(m.k)	24	32
	Specific Heat	10^-3J/(kgK)	0.78	0.9
Electrical Characteristics	Dielectric constant (1MHZ)	-	9.4	9.9
	Dielectric loss angle	*10^-4	5	1
	Dielectric strength	*10⁶V/m	15	15

2. Advantages:

1).High temperature resistance.

2).Corrosion resistance,

3).Anti-high voltage,

4).Stable electrical property,

5).And high insulation functions.

6).Ignition sensitivity

3. Application:

Gas cooker,Water heater,Gas oven, Gas boiler,Air-conditioning and so on.

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Bulk Density:	3.6-3.9g/cm3
Flexural Strength:	340-400MPa
Hardness Vickers:	13.5-15.6gpa
Certification:	ISO9001: 2000
Component:	Ignition Lock Cylinder

Lianyungang Zhong Ao Aluminium Co. Ltd (AIZA)

Our Products:
Alumina Ceramic Ball
Alumina Ceramic Lining
Alumina Ceramic Cylinder
Alumina Wear Tile
Alumina Ceramic Beads
Alumina Ceramic Nozzle
Alumina Ceramic Ring
Insulation Ceramic
Customized Heterotypic Technical Ceramics

AIZA is a Lianyungang based Sino-Foreign joint venture corporation. It is a Chinese producer of calcined alumina and a manufacturer of alumina ceramics, such as alumina ceramic ball, alumina ceramic cylinder, alumina wear tile, ceramic insulator, ceramic element, ceramic beads, and other insulation ceramics with self-prepared material as well as German and Japanese material.

Since its creation, AIZA has served most of Chinese customers, Nanjing Huade, Zhuzhou Xianghuoju, and Chaozhou Sanhuan, which are eminent manufacturer of spark plug and advanced ceramic in China. Its "TCH" brand calcined alumina is well accepted by our customers.

In 2008, AIZA purchased 70 key equipment from Shanghai Morgan Matroc after its closure in China. The equipment includes isostatic press machine, dry press machine, hot press cast machine, ball mill, alumina spray prilling tower (centrifugal and pressure), polishing machine, etc. The equipment has been successfully installed in our factory by the end of 2008. Now, AIZA have succeeded in establishing itself as sole Chinese manufacturer of ceramic nozzle by isostatic dry bag pressing process. Besides, the most experienced technical engineer of former Shanghai Morgan Matroc also joined us, which is the precious source of our confidence of ensuring products quality.

TQC Procedures and ISO 9001: 2000- Certification

Our experienced QC will supervise the production and check the quality before delivery. We conduct TQC procedures according to ISO 9001: 2000-certified guidelines. In order to ensure better quality, we carry out five processes below:
1. Material inspection
2. Semi-manufactured goods inspection
3. Itinerary inspection
4. Finished products inspection
5. Shipment inspection.

Material Adopted:
Alumina
Zirconia
Steatite
Alumina-Zirconia

Technologies Adopted:
Dry Pressing
Isostatic Pressing
Heat Press Cast

Flowchart of Customized Service: Drawing Received---Researching and Tooling---Sample Collecting and Testing---Sample Accepted---Order Confirming.
