VRC is car elevator to convey cars from one floor to another floor.
There are four post model(FP-VRC) and scissor model(S-VRC) for choice. It could be used to convey goods or cars vertically. Scissor lift with 2 platforms also could be used for pit parking lift.
Car transportation lift is the most humanized equipment among the series of lifting platform. Its platform, lifting height, capacity and control mode not only can be designed and manufactured based on customer's demand, but also can be produced with some special safety settings and can be designed as two floors platform for loading or parking.
Because of its diversity, this series platform is widely used in production line in industrial, mining enterprises or pharmaceutical industries. It also can be used in other industries or situation, as goods elevator to transport cargo, or as vehicle lift to transport vehicle, or as goods handling machinery in storage, logistics warehouse, etc. No need to build such platform or steel frame as ancillary facilities, the platform hoists directly from the ground, and homework finished, the platform drops to flush with the ground state.
Each unit lift has been tested and debugged in our factory, and all technical specifications meet the design requirements. Users only need to operate it as the following steps.
Necessary info for cost calculation:
| Model | S-VRC | Drive mode | Hydraulic |
| Lifting capacity | 2,000~30,000kg (upon request) | Operation | button switch |
| Lifting height | 3,000~15,000mm(upon request) | Power pack | 5.5Kw |
| Platform length | 2000~6000mm(upon request) | Lifting speed | 4m/min |
| Platform width | 2000~5000mm(upon request) | Finishing | Paint spray |
| Platform matrial | Diamond steel sheet | MOQ | 1 Piece |
| Platform material(optional) | 4mm Aluminum steel sheet | Warranty | 10 years to structure and 1 year to parts |
| No. of level | upon request | Package | standard shipping package |
Floor to Floor car elevator questionnaire :
1. Is this an existing building or future project?
2. What is the weight capacity of your vehicle?
3. What are your platform size requirements?
4. How many levels (floors) will the lift service?
5. What is the distance of the vertical travel between floors?
6. What is your load pattern to drive on, drive off? (C, Z)
7. Do you have any special requirements? (wash down, explosion proof, outdoors)
8. Will the lift be next to a mezzanine, through a floor or in a shaft?
9. Do you require enclosures? If yes, on how many sides?
10. How often will the lift be used? And is speed important?
11. What are your electrical requirements?
12. Would you prefer your lift to be surface mounted or pit-mounted? (surface mounting would require drive-on ramps)
13. Are there any obstructions above or around the lift area?
14. What are the measurements from the floor to the underside of the ceiling?
15. What is the clearance above the upper level? (this is very important)
16. Can you provide a sketch or drawing of the site or application?
17. What is your timeline for delivery?
18. What State or Country is this project in? (state codes may apply)
19. Will there be riders on this lift? (Class B elevator to meet safety codes if riders on Lift)
Our Service
Mutrade servicing department is dedicated to ensure professional assistance and quality technical support on the project layout, design, engineering, production, delivery, assemble, repair and maintenance.
Our Servicing and Engineering Departments provides service from Monday to Friday 9 am to 6 pm EST to ensure our customer satisfaction and superior quality maintenance on all made equipment.
THE SERVICING AND ENGINEERING DEPARTMENT SUPPORT YOU:
• Free Project layout and choosing consultancy
• Free layout drawing
• Free product modification engineering
• Professional logistic service
• Production QC and loading inspection
• Installation support (Free onsite engineer)
• Repair and Maintenance (Email, phone, pics, and videos)
Our Company
Qingdao Mutrade is a leading parking solution provider in China. We are committed to provide the most suitable and cost effective parking system solutions to our customers all over the world. We manufacture, install, and support the different types of car parking system in order to meet different requirements from our customers. The business consists of parking equipment selling, parking solution consulting,parking project undertaking etc. Our value is based on the competitive price, quality product, reliable support and sincere customer service.
Our parking system products include valet parking, automated parking, floor-to-floor car lift, etc. We are the only company which can manufacture high-end hydraulic lift sliding parking system in China. Our parking system adopts Japanese Kawasaki hydraulic technology which make the parking and retrieving speed three or more times faster than any other lift sliding parking system. 26 national patents, 38 senior and associate engineers, 55 major project experience, 90 sophisticated technicians guarantee our products and services can fully satisfy the needs of our customers.
Qingdao Mutrade Co., Ltd. is one of the earliest professional mechanical parking solution providers in China. We are committed to provide the most suitable and cost effective parking system solutions to our customers all over the world.
Hydro-Park is a subsidiary company and sub-brand built by Mutrade for high-end mechanical simple parking equipment. We develop, design and manufacture mechanical parking equipment with our own advanced technology and kept consistent high quality.
Our target is to become world class manufacturer with following competitive advantages:
Advanced Technology
Precise Manufacture Processing
Strong Service Support
Customer Oriented
For all the people who work in the mechanical parking business, if you are looking for a reliable partner in China, Mutrade is the one company you can not miss!
