Prod Model: |
PSP SERIES |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Main Features:
1. Primary motor variable-frequency speed regulation.
2. Fuel temperature, rotation speed, count, advanced angle LCD, digital display.
3. Inspecting control rack travel and Lubrication oil circuit (optional. )
4. Speed presetting, Count and temperature setting.
5. VE pump performance inspection.
6. Fuel temperature auto-control.
7. With internal air supply and vacuum.
8. With test bench troubleshooting diagnosis and protection.
9. Available for testing fuel injection pump types: All in-line pump and rotary(VE) pump.
PSP-A: Industrial computer work station, Windows XP operation system. LCD display.
PSP-AC: Industrial computer work station, DOS operation system, LCD display & digital display.
PSP-AH: Laptop computer, Windows XP operation system, LCD display & digital display.
PSP-C: Desktop computer, Windows XP operation system, LCD display & digital display.
PSP-D: Industrial computer work station, DOS operation system, LCD display.
PSP-B, PSP-BH, PSP-BW, PSP-F: Digital display.
Main Functions:
Checking of the advance device in dynamics.
Measurement of each cylinder's delivery at any speed.
Checking of each cylinder's injection timing with static.
Measurement of rack travel at any speed.
Checking of the LDA.
Checking of the mechanical governor.
Checking of the pneumatic governor.
Checking of the vacuum capacity of governor.
Measurement of the internal pressure of VE pump body.
Measurement of the reflux delivery of VE pump.
Testing of the electro-magnetic valve of VE pump.
Checking of the feed pump.
Checking of the sealing of injection pump body.
Model | PSP |
Dragging power | 5.5/7.5/11/15/18.5kw |
Length×width×height | 2050×960×1750mm |
Weight | 800kg-1300kg |
Voltage / 3 phase | 380/220V(on request) |
Frequency | 50/60hz |
Speed range | 0-4000rpm/min |
Speed presetting range | 0-4000rpm/min |
Speed control accuracy | <±1 rpm |
12v External DC supply 12v | 6A |
24v External DC supply 24v | 3A |
Center distance height | 125mm |
ISO driving shaft coupling | 120mm |
Measurement points | 12cyl |
Graduate tubes capacity | 45/150/260ml |
Feeding pump | 8 L/min |
Oil tank capacity | 60L |
Advanced angle measurement(optional) | 0-180° |
Control rack travel measurement(optional) | 0-30mm |
Low pressure | 0-0.4mpa |
High pressure | 0-4mpa |
Air pressure | -0.03-0.3mpa |
Pump internal pressure | 0-1.6mpa |
Vacuum | -0.1-0mpa |
Heater power | 2 KW |
Fuel temperature regulation range /auto control | 30-65 ºC |
Test oil cooling | Heater exchanger |
