Deutz Bf6m2012c Bf4m2012 Engine for Bus, Truck and Construction Machine
| Price: |
US $ 10000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T |
TECHNOLOGY FEATURES:
1. Adopt the unit pump structure tested for 12 years in European markets, stable performance, reliable and average heavy repair mileage is 100, 000 kilometers higher than other kind products, with 30 days more attendance in a year.
2. Adopt structures off the unit pump with the highest injection pressure and top built intake duct, short and high pressure pipe, met the emission standard, save 2 to 3 liters fuel per one hundred kilometers compared with other kind products.
3. Unique single injection pump fuel supplying system, low requirements for fuel quality, adaptable to Chinese fuel quality and guaranteed the reliability of the complete engine.
4. Noise lower than 96 decibels, the only one engine met the standard without assistant approaches in China.
| MODEL | BF4M1013 -16 | BF4M1013 -18 | BF4M1013 -19 | BF6M1013 -24 | BF6M1013 -26 | BF6M1013 -28 | BF6M1013 -30 | BF4M2012 -14 | BF4M2012 -16 | BF4M2012 -12 | BF6M2012 -16 | BF6M2012 -18 | BF6M2012 -20 | BF6M2012 -21 | BF6M2012 -23 |
| BORE/STROKE | 108/130 | 108/130 | 108/130 | 108/130 | 108/130 | 108/130 | 108/130 | 101/126 | 101/126 | 101/126 | 101/126 | 101/126 | 101/126 | 101/126 | 101/126 |
| DISPLACEMENT(L) | 4.76 | 4.76 | 4.76 | 7.14 | 7.14 | 7.14 | 7.14 | 4.04 | 4.04 | 4.04 | 6.06 | 6.06 | 6.06 | 6.06 | 6.06 |
| FUEL INJECTION PUMP | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH | EUP/BOSCH |
| RATED POWER/SPEED(kW/rpm) | 118/2300 | 132/2300 | 140/2300 | 177/2300 | 192/2300 | 206/2300 | 220/2300 | 103/2500 | 118/2500 | 90/2500 | 118/2500 | 1322500 | 147/2500 | 155/2500 | 170/2500 |
| MAX TORQUE/SPEED(Nm/rpm) | 590/1400 | 650/1400 | 700/1400 | 850/1400 | 950/1400 | 1050/1400 | 1100/1400 | 530/1500 | 590/1500 | 410/1500 | 590/1500 | 650/1500 | 743/1500 | 750/1500 | 850/1500 |
| MINIMUM FUEL CONSUMPTION(g/Kw. H) | 193 | 193 | 193 | 192 | 192 | 192 | 192 | 197 | 197 | 197 | 197 | 197 | 197 | 197 | 197 |
| COMPRESSION RATIO | 18.1 | 18.1 | 18.1 | 18.1 | 18.1 | 18.1 | 18.1 | 0.792361 | 0.792361 | 0.792361 | 0.792361 | 0.792361 | 0.792361 | 0.792361 | 0.792361 |
| NOISE(SOUND POWER LEVEL) dB(A) | & le; 92.5dB(A) | | & le; 96dB(A) | | | & le; 92.5dB(A) | | & le; 92.5dB(A) | | | |
| SIZE OF THE WHOLE ENGINE | 912*660*975 | | 1146*622*897 | | | 799*601*832 | | 1027*595*907 | | | |
| WEIGHT OF THE WHOLE ENGINE(kg) | 510 | | | 650 | | | |
| Deutz BF6M2012 Engine for industry and vehicle |
| Monarch Power Limited |
| Engine type | BF6M2012 |
| Number of cylinders | 6 |
| Induction system | Turbo charged |
| Type | In-line, 4-Stroke,water cooled, inter-cooled, direct injection |
| Fuel injection pump | P/BOSCH |
| Fire Order | 1-5-3-6-2-4 |
| Direction of Rotation | clockwise(facing blower fan) |
| Bore*stroke | mm | 101*126 |
| Displacement | L | 6.06 |
| Rated speed | rpm | 2500 |
| Rated power | kw | 118~170 |
| Max Torque | (N.m) | 590~850 |
| Oil Consumption | (g/kw.h) | 197 |
| Idle speed | (r/min) | 800+-50 | 700+-50 |
| Net Dry Weight | (kg) | 509 |
| Noise (Sound power level) | dB(A) | ≤92.5 |
|
| Emission | | Euro II | Euro III |
| Overall Dimension | (mm) | 1027*595*907 |
| Prod Model: |
Deutz BF6M2012C BF4M2012 |
| Markets: |
Eastern Europe,Africa,Mid East |
| Intake Pressure Impulse: |
Supercharged |
| Speed: |
High Speed |
| Piston Movement: |
Reciprocating |
| Ignition Mode: |
Electric Ignition |
| Number Of Cylinders: |
Multi-Cylinder Machines |
| Cooling Cylinder: |
Water-Cooled |
| Number Of Strokes: |
Four-Stroke |
| Cylinder Arrangement Form: |
V |
| Fuel: |
Diesel Engine |
Shanghai Monarch Power Engineering Limited has already established very close relationships with Cummins, Deutz, Isuzu, Lovol, Iveco, Nissan, Toyota and other manufacturers. We can also provide you with the complete series of engines with the brands above. The engines are used for marine propulsion, marine generators, industrial generators, construction engines, vehicle engines, agriculture engines, etc.
We has already established cooperation relationships with customers all over the world, with an experienced and professional staff group, as well as senior engineers, technicians and salesmen. Now our company is known as a leading manufacturer in supplying of diesel generators (for both industrial use and marine use).
We can provide you with generators which are approved by China Classification Society CCS. Our marine generator can be approved by CCS, ABS, BV, DNV, GL, LR, GL, RS, etc. With steady quality, quick and professional service, our company gains the general recognition from users at home and abroad.
We are sincerely looking forward to establishing business relationships with you for our mutual benefit.
Products of Monarch Power Limited dealing with
1) Diesel engine: CUMMINS B, C, ISBe, ISDe, ISLe, L, ISF2.8/3.8 and DEUTZ BFM1015, FL413 & FL513, TBD234 and 226B for vehicle; CUMMINS B, C, KTA, N and DEUTZ TBD234, 226B for marine; CUMMINS B, C and DEUTZ FL413&FL513, FL912&913, TBD234 and 226B for genset; CUMMINS B, C, M11 and DEUTZ FL413&FL513, FL511, FL912&FL913, 226B, BF4M1013&BF6M1013, BF1015, TBD234 for industry.
2) Engine spare parts and machinery components: Genuine, OEM and aftermarket parts for the CUMMINS, DEUTZ, KOMATSU and some Japanese serial car. Genuine and Chinese-made machinery parts for the heavy machine. Cummins Marine Engine Parts.
3) Generator set: CUMMINS diesel generator set for landuse and marine; CUMMINS natural gas and biogas generator set. DEUTZ diesel generator set
Monarch Power Limited welcome to customers from all around the world to visit and expect to build long and friendly business relations with you and your company in the near future!
