Cylinder Honing Machine (3M9814A)

Name: Cylinder Honing Machine (3M9814A)
Brand: ibuyautoparts.com
SKU: 773925925
Availability: InStock
Rating: 4.5 (59 reviews)

Price:	US $ 1-6000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T,D/P

Contact Supplier

Showroom Product Company Profile

Product Description

The machine tool is mainly used for honing automobile and tractor cylinders with diameters from Φ40 to Φ40 arter boring precess. The machine tool is small in size, light in weight. The machine tool proper can be slid longitudinal at will to facilitate operation. The up-and-down reciprocating. Motion of which can be adjusted randomly. Honing process can be carried out arter the cylinder block to be honed is placed on the worktable, abjusted to centre position and secured.

Parameters
Model	Unit	3M9814A
Dia. of hole honed	mm	Φ40- Φ1400
Max. depth of hole honed	mm	320
Spindle speed	r/min	128; 240
Longitudinal travel of honing head	mm	720
Spindle lifting and lowering speed (stepless)	m/min	0 - 10
Power of honing head motor	Kw	0.75
Overall dimensions (L x W x H)	mm	1440 x 960 x 1655
Packing dimensions (L x W x H)	mm	1800 x 1140 x 1280
N.W/G.W.	kg	510/680

Prod Model:	3M9814A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Max. Depth Of Hole Honed:	320mm
Longitudinal Travel Of Honing Head:	720mm

ACE MACHINE TOOLS Co., Ltd, is a specialized exporter and manufacturer of machine tools and accessories with a long history.

Our mechanical products cover more than 80 kinds including lathe, milling machine, drilling machine, grinding machine, power press, hydraulic guillotine, hydraulic press brake, CNC & automotive machines and so on.

Our customers are widespread in more than 30 countries including U. S. A., Germany, Spain, France, England, Greece, Finland, Norway, Canada, south America, Middle East, Australia, Africa and southeast Asia etc.

Our principle to all the customers is high quality and good service. We have quality control team who will carefully inspect every machine in workshop before packing.

Welcome you to visit our website and contact us. We will give you quick response upon any of your need.
