Cylinder Boring Machine -Air Floating Automatic Centering (FT7)

Name: Cylinder Boring Machine -Air Floating Automatic Centering (FT7)
Brand: ibuyautoparts.com
SKU: 781157085
Availability: InStock
Rating: 4.5 (140 reviews)

Price:	US $ 5000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T,D/P

Contact Supplier

Showroom Product Company Profile

Cylinder Boring Machine (Air Floating Automatic Centering)

Features
FT7 is a new design cylinder boring machine.
Mainly used for repairing automobile and tractor cylinders...
The spindle of FT7 can be moved freely above the floating table, quickly move to the top of the cylinder you will work with.
4-point automatic centering system, make your work fast and precision.
Various of the tool holder fit this machine work from 39-180mm.
Together with the air floating V- Fixture make this machine available to work with 60° And 45° V cylinder.

Parameters
Model	Unit	FT7
Range of boring diameter:	mm	39-180
Max boring depth	mm	400
Max longitudinal travel of spindle	mm	1058
Max cross travel of spindle	mm	58
Spindle speed:	rpm	50-1000
Range of spindle feed	mm/s	0.42-0.80
Spindle move speed	mm/s	5.-16
Main motor	kw	1.1
Spindle feed motor	kw	0.4
Self-centering motor	kw	0.15
Pneumatic pressure	pa	0.6
Wheelhead feed per round	mm	0.5
Wheelhead feed per grad	mm	0.005
Overall size	mm	1600x950x2095
N.W/G.W	kg	1500 / 1800

Prod Model:	FT7
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
