Con-Rod and Grinding Machine (LFM75)

Name: Con-Rod and Grinding Machine (LFM75)
Brand: ibuyautoparts.com
SKU: 773450885
Availability: InStock
Rating: 4.6 (148 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Product Description
The machine is a new type used for grinding contact surface of connecting rods of automobiles & tractors.
High speed cutting, durable grinding wheel. When process one set of cap and rod, do not need shut down or start up the grinding wheel.
Quick fixture for cap and rod, is very convenience to use, just one movement, the cap and rod can be disentangle. This fixture is design for getting more clamp force, high efficiency and high precision.

Parameters
Model	Unit	LFM75
Width of connecting rods ground	mm	20-75
Grinding wheel spindle speed	r/min	3200
Spindle speed	mm/r	2
Motor power	Kw	0.75
Overall dimensions (L x W x H)	mm	690 x 490 x 565
Packing dimensions (L x W x H)	mm	790 x 800 x 740
N.W./G.W.	kg	95/115

Prod Model:	LFM75
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Width Of Connecting Rods Ground:	20-75 mm
Grinding Wheel Spindle Speed:	3200 R/Min

ACE MACHINE TOOLS Co., Ltd, is a specialized exporter and manufacturer of machine tools and accessories with a long history.

Our mechanical products cover more than 80 kinds including lathe, milling machine, drilling machine, grinding machine, power press, hydraulic guillotine, hydraulic press brake, CNC & automotive machines and so on.

Our customers are widespread in more than 30 countries including U. S. A., Germany, Spain, France, England, Greece, Finland, Norway, Canada, south America, Middle East, Australia, Africa and southeast Asia etc.

Our principle to all the customers is high quality and good service. We have quality control team who will carefully inspect every machine in workshop before packing.

Welcome you to visit our website and contact us. We will give you quick response upon any of your need.
