China Factory High Quality Glass Window Cleaning Wiper

Name: China Factory High Quality Glass Window Cleaning Wiper
Brand: ibuyautoparts.com
SKU: 778566665
Availability: InStock
Rating: 5 (82 reviews)

Price:	Negotiable/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

China Factory High Quality Glass Window Cleaning Wiper

Product Description

Main Technical Data:
1.Power supply: AC 220V, AC 10V, DC 24V
2.Frequency:50Hz/60Hz
3.Wipe Speed:0.5-1.2m/sec
4.Consumed power of motor:≤120w
5.Consumed power of heater:≤300w
6.Protection grade:IP56
7.Outline dimension of control box
(Only for reference): Box(mm):130x100x132
Faceplate(mm):150x120x4
8.Power box external dimensions:
Box(mm):250x200x145
Mounting dimensions:280x170
9.Installation:Main unit is mounted above outdoor side scuttle with the rod swinging downwards. If needing other installation method, both parties should confirm a special design and note it in technical specification.
10.Weight:≤26kg
11.Optional parts:heater, waterworks, automatic resetting

Type	Power supply	Body length L (mm)	Wipe stroke St (mm)	Arm length A (mm)	Blade length E (mm)
WGP2-JR	AC 220V	1000-3000	500-2700	400-800 (according to the height of center)	400-1000 (according to the height of window)
	AC 110V
WGP2-ZR	DC 24V

All different dimensions of wiper can be customized according to customer's requirements.

Note:
Wipping speed refers to wiping cycles per mimute, be subject to single-trip.

Notes when ordering:
1.When placing an order, pls advise model, rod length and blade length.
2.If any special requirements on size or others, both parties should confirm technical specification when placing an order and the production shall be subject to design requirement.

Prod Model:	Window Wiper
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Body Length:	1000-3000mm
Wipe Stroke:	500-2700mm
Arm Length:	400-800mm
Blade Length:	400-1000mm
Wipe Speed:	0.5-1.2m/S
Power Supply:	AC 220V, AC 110V, DC 24V
Frequency:	50Hz/60Hz
Operation Parts:	Heater, Waterworks, Automatic Resetting
Name:	High Quality Glass Window Cleaning Wiper
Keywords:	Cleaning Wiper
Part:	Windscreen Wiper
Material:	Aluminum Alloy
Range:	Double Side
Sweep Angle:	80??
Driving Type:	Electrical
Application:	Ship,Boat
Type:	Horizontal
Bone:	Custom
Size:	Custom
Brand:	Trust
